200W Single Output with PFC Function
Features :
Universal AC input / full range
SP-200
series
Built-in active PFC function, PF>0.93
Protections:Short circuit/Over load/Over voltage/Over temperature
Built-in cooling fan speed control
Built-in constant current limiting circuit
Built-in fan speed control
Remote ON-OFF control(Optional)
LED indicator for power on
100% full load burn-in test
Fixed switching frequency at PFC:67KHz PWM:134KHz
3 years warranty
SPECIFICATION
MODEL
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
RATED POWER
OUTPUT
SP-200-3.3
3.3V
40A
0 ~ 40A
132W
SP-200-5
5V
40A
0 ~ 40A
200W
SP-200-7.5
7.5V
26.7A
0 ~ 26.7A
200.2W
100mVp-p
2.0%
0.5%
R
SP-200-12
12V
16.7A
0 ~ 16.7A
200.4W
100mVp-p
2.0%
0.5%
0.5%
SP-200-13.5 SP-200-15
13.5V
14.9A
0 ~ 11.2A
201.1W
100mVp-p
2.0%
0.5%
0.5%
SP-200-24
24V
8.4A
0 ~ 8.4A
201.6W
150mVp-p
1.0%
0.5%
0.5%
SP-200-27
27V
7.5A
0 ~ 7.5A
202.5W
150mVp-p
1.0%
0.5%
0.5%
SP-200-48
48V
4.2A
0 ~ 4.2A
201.6W
250mVp-p
1.0%
0.5%
0.5%
15V
13.4A
0 ~ 13.4A
201W
100mVp-p
2.0%
0.5%
0.5%
RIPPLE & NOISE (max.)
Note.2
100mVp-p
100mVp-p
VOLTAGE ADJ. RANGE
3.14 ~ 3.63V 4.75 ~ 5.5V
VOLTAGE TOLERANCE
Note.3
LINE REGULATION
2.0%
0.5%
7.13 ~ 8.25V 11.4 ~ 13.2V 12.8 ~ 14.9V 14.3 ~ 16.5V 22.8 ~ 26.4V 25.7 ~ 29.7V 45.6 ~ 52.8V
2.0%
0.5%
LOAD REGULATION
SETUP, RISE, HOLD TIME
VOLTAGE RANGE
FREQUENCY RANGE
POWER FACTOR
INPUT
EFFICIENCY (Typ.)
AC CURRENT
INRUSH CURRENT (max.)
LEAKAGE CURRENT
OVER LOAD
PROTECTION
OVER VOLTAGE
1.0%
1.0%
1.0%
600ms, 30ms, 20ms at full load
85 ~ 264VAC
47~63Hz
PF>0.93/230VAC
65%
120 ~ 370VDC
PF>0.98/115VAC at full load
76%
79%
80%
81%
83%
83%
84%
71%
3.5A/115VAC
1.7A/230VAC
COLD START 40A/230VAC
<2mA / 240VAC
105 ~ 150% rated output power
Protection type : Constant current limiting, recovers automatically after fault condition is removed
3.63 ~ 4.46V 5.5 ~ 6.75V 8.25 ~ 10.13V 13.2 ~ 16.2V 14.85 ~ 18.2V 16.5 ~ 20.25V 26.4 ~ 32.4V 29.7 ~ 36.45V 52.8 ~ 64.8V
Protection type : Shut down o/p voltage, re-power on to recover
OVER TEMPERATURE
FUNCTION
95
5 (TSW1 : Detect on heatsink of power transistor)
Protection type : Shut down o/p voltage, recovers automatically after temperature goes down
REMOTE CONTROL(OPTION)
CN1:4 ~ 10VDC POWER ON, <0 ~ 0.8VDC POWER OFF
-10 ~ +60 (Refer to output load derating curve)
WORKING TEMP.
20 ~ 90% RH non-condensing
WORKING HUMIDITY
ENVIRONMENT
STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
SAFETY STANDARDS
WITHSTAND VOLTAGE
SAFETY & ISOLATION RESISTANCE
EMC
(Note 4)
-20 ~ +85 , 10 ~ 95% RH
0.05%/ (0 ~ 50
10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
UL60950-1, TUV EN60950-1 and S-MARK J60950 Approved
I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC
EMI CONDUCTION & RADIATION
Compliance to EN55022 (CISPR22) Class B
HARMONIC CURRENT
Compliance to EN61000-3-2,-3
EMS IMMUNITY
MTBF
OTHERS
DIMENSION
PACKING
NOTE
Compliance to EN61000-4-2,3,4,5,6,8,11; ENV50204, EN55024, Light industry level, criteria A
183.8K hrs min. MIL-HDBK-217F (25
199*99*50mm (L*W*H)
0.85Kg; 20pcs/17.9Kg/1.28CUFT
)
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets
EMC directives.
