MBR4035PT, MBR4045PT, MBR4050PT, MBR4060PT
www.vishay.com
Vishay General Semiconductor
Dual Common Cathode Schottky Rectifier
FEATURES
• Power pack
• Guardring for overvoltage protection
• Lower power losses, high efficiency
• Low forward voltage drop
• High forward surge capability
• High frequency operation
3
2
1
• Solder dip 275 °C max.10 s, per JESD 22-B106
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
TO-247AD (TO-3P)
PIN 1
PIN 3
PIN 2
CASE
TYPICAL APPLICATIONS
For use in low voltage, high frequency rectifier of switching
mode power supplies, freewheeling diodes, DC/DC
converters, or polarity protection application.
PRIMARY CHARACTERISTICS
I
F(AV)
V
RRM
I
FSM
V
F
T
J
max.
Package
Diode variations
40 A
35 V, 45 V, 50 V, 60 V
400 A
0.60 V, 0.62 V
150 °C
TO-247AD (TO-3P)
Common cathode
MECHANICAL DATA
Case:
TO-247AD (TO-3P)
Molding compound meets UL 94 V-0 flammability rating
Base P/N-E3 - RoHS-compliant, commercial grade
Terminals:
Matte tin plated leads, solderable
J-STD-002 and JESD 22-B102
E3 suffix meets JESD 201 class 1A whisker test
Polarity:
As marked
Mounting Torque:
10 in-lbs maximum
per
MAXIMUM RATINGS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Maximum repetitive peak reverse voltage
Maximum working peak reverse voltage
Maximum DC blocking voltage
Maximum average forward rectified current T
C
= 125 °C
Peak forward surge current 8.3 ms single half
sine-wave superimposed on rated load per diode
Peak repetitive reverse surge current per diode
Voltage rate of change (rated V
R
)
Operating junction temperature range
Storage temperature range
Note
(1)
2.0 μs pulse width, f = 1.0 kHz
SYMBOL
V
RRM
V
RWM
V
DC
I
F(AV)
I
FSM
I
RRM (1)
dV/dt
T
J
T
STG
2.0
10 000
-65 to +150
-65 to +175
MBR4035PT
35
35
35
MBR4045PT
45
45
45
40
400
1.0
MBR4050PT
50
50
50
MBR4060PT
60
60
60
UNIT
V
V
V
A
A
A
V/μs
°C
°C
Revision: 17-Aug-15
Document Number: 88679
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
MBR4035PT, MBR4045PT, MBR4050PT, MBR4060PT
www.vishay.com
Vishay General Semiconductor
SYMBOL
TEST CONDITIONS
I
F
= 20 A T
J
= 25 °C
I
F
= 20 A T
J
= 125 °C
I
F
= 40 A T
J
= 25 °C
I
F
= 40 A T
J
= 125 °C
T
J
= 25 °C
T
J
= 125 °C
MBR4035PT MBR4045PT MBR4050PT MBR4060PT UNIT
0.70
0.60
0.80
0.75
1.0
mA
100
0.72
0.62
-
-
V
ELECTRICAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Maximum instantaneous forward
voltage per diode
Maximum instantaneous reverse
current at rated DC blocking voltage
per diode
V
F (1)
I
R (1)
Note
(1)
Pulse test: 300 μs pulse width, 1 % duty cycle
THERMAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Thermal resistance, junction to case
per diode
SYMBOL
R
JC
MBR4035PT
MBR4045PT
1.2
MBR4050PT
MBR4060PT
UNIT
°C/W
ORDERING INFORMATION
(Example)
PACKAGE
TO-247AD
PREFERRED P/N
MBR4045PT-E3/45
UNIT WEIGHT (g)
6.13
PACKAGE CODE
45
BASE QUANTITY
30/tube
DELIVERY MODE
Tube
RATINGS AND CHARACTERISTICS CURVES
(T
A
= 25 °C unless otherwise noted)
50
400
40
Peak Forward Surge Current (A)
Resistive or Inductive Load
T
J
= T
J
Max.
8.3 ms Single Half Sine-Wave
Average Forward Current (A)
300
30
20
200
10
0
0
50
100
150
100
1
10
100
Case Temperature (°C)
Number
of Cycles at 60 Hz
Fig. 1 - Forward Current Derating Curve
Fig. 2 - Maximum Non-Repetitive Peak Forward Surge Current
Per Diode
Revision: 17-Aug-15
Document Number: 88679
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
MBR4035PT, MBR4045PT, MBR4050PT, MBR4060PT
www.vishay.com
Vishay General Semiconductor
10 000
T
J
= 25 °C
f = 1.0 MHz
V
sig
= 50 mV
p-p
100
Instantaneous Forward Current (A)
10
T
J
= 150 °C
Pulse Width = 300 µs
1 % Duty Cycle
1
T
J
= 25 °C
Junction Capacitance (pF)
1000
0.1
MBR4035PT, MBR4045PT
MBR4050PT, MBR4060PT
0.01
0
0.2
0.4
0.6
0.8
1.0
1.2
MBR4035PT, MBR4045PT
MBR4050PT, MBR4060PT
100
0.1
1
10
100
Instantaneous Forward Voltage (V)
Reverse Voltage (V)
Fig. 3 - Typical Instantaneous Forward Characteristics Per Diode
Fig. 5 - Typical Junction Capacitance Per Diode
100
100
10
T
J
= 125 °C
1
T
J
= 75 °C
Transient Thermal Impedance (°C/W)
Instantaneous Reverse Current (mA)
MBR4035PT, MBR4045PT
MBR4050PT, MBR4060PT
10
0.1
T
J
= 25 °C
0.01
1
0.001
0
20
40
60
80
100
0.1
0.01
0.1
1
10
100
Percent of Rated Peak Reverse Voltage (%)
t - Pulse Duration (s)
Fig. 4 - Typical Reverse Characteristics Per Diode
Fig. 6 - Typical Transient Thermal Impedance Per Diode
PACKAGE OUTLINE DIMENSIONS
in inches (millimeters)
TO-247AD (TO-3P)
0.245 (6.2)
0.225 (5.7)
0.645 (16.4)
0.625 (15.9)
0.323 (8.2)
0.313 (7.9)
0.203 (5.16)
0.193 (4.90)
30°
0.170
(4.3)
0.840 (21.3)
0.820 (20.8)
0.142 (3.6)
0.138 (3.5)
10° TYP.
Both Sides
0.078 (1.98) REF.
10
1
2
3
0.086 (2.18)
0.076 (1.93)
0.127 (3.22)
0.118 (3.0)
0.108 (2.7)
1° REF.
Both Sides
0.160 (4.1)
0.140 (3.5)
0.795 (20.2)
0.775 (19.6)
0.117 (2.97)
0.225 (5.7)
0.205 (5.2)
PIN 1
PIN 3
0.048 (1.22)
0.044 (1.12)
0.030 (0.76)
0.020 (0.51)
PIN 2
CASE
Revision: 17-Aug-15
Document Number: 88679
3
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
