SK54BL

Elektronische Bauelemente

Low V

F

& Low I

R

5.0 Amp Surface Mount Schottky Barrier Rectifiers

RoHS Compliant Product

A suffix of “-C” specifies halogen & lead-free

FEATURES

Low profile package

Ideal for automated placement

Guard Ring for over voltage protection

Low forward voltage drop

Component in accordance to RoHS 2002/95/EC

SMB

B

A

C

H

MECHANICAL DATA

Case: Molded Plastic

Epoxy: UL 94V-0 rate flame retardant

Terminals: Lead Free Plating (Tin Finish).

Solderable per MIL-STD-202, Method 208

Polarity:

Cathode Band

Mounting position: Any

Weight: 0.095 grams

D

G

E

F

REF.

A

B

C

D

Millimeter

Min.

Max.

1.91

2.20

4.06

4.70

3.30

3.94

2.13

2.44

REF.

E

F

G

H

Millimeter

Min.

Max.

-

0.203

5.08

5.59

0.76

1.52

0.15

0.305

PACKAGE INFORMATION

Package

SMB

MPQ

3K

Leader Size

13 inch

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

(Rating 25° ambient temperature unless otherwise s pecified. Single phase half wave, 60Hz, resistive or inductive load.

C

For capacitive load, de-rate current by 20%.)

Parameter

Maximum repetitive peak reverse voltage

Maximum RMS voltage

Maximum DC Blocking Voltage

Maximum average forward rectified current

Peak Forward Current @ 8.3 ms Half Sine

Maximum Instantaneous Forward Voltage

@ I

F

=5A

Maximum DC Reverse Current

At Rated DC Blocking

Typical Junction Capacitance

Typical Thermal Resistance

Operating And Storage Temperature Range

1

Symbol

V

RRM

V

RMS

V

DC

I

F(AV)

I

FSM

V

F

I

R

T

C

=100°C

C

J

R

θJA

R

θJC

T

J

,T

STG

Rating

40

28

40

5

100

0.45

0.5

Unit

V

A

V

mA

T

C

=25°C

50

400

60

20

-55~125, -50~150

pF

°

C/W

°

C/W

°

C

Note:

1. Measured at 1.0MHZ and applied reverse voltage of 4.0V DC.

http://www.SeCoSGmbH.com/

Any changes of specification will not be informed individually.

05-Apr-2012 Rev. A

Page 1 of 2
