MC74HCT373A
Octal 3-State Noninverting
Transparent Latch with
LSTTL-Compatible Inputs
High−Performance Silicon−Gate CMOS
The MC74HCT373A may be used as a level converter for
interfacing TTL or NMOS outputs to High−Speed CMOS inputs.
The HCT373A is identical in pinout to the LS373.
The eight latches of the HCT373A are transparent D−type latches.
While the Latch Enable is high the Q outputs follow the Data Inputs.
When Latch Enable is taken low, data meeting the setup and hold
times becomes latched.
The Output Enable does not affect the state of the latch, but when
Output Enable is high, all outputs are forced to the high−impedance
state. Thus, data may be latched even when the outputs are not
enabled.
The HCT373A is identical in function to the HCT573A, which has
the input pins on the opposite side of the package from the output pins.
This device is similar in function to the HCT533A, which has
inverting outputs.
•
Output Drive Capability: 15 LSTTL Loads
•
TTL/NMOS−Compatible Input Levels
•
Outputs Directly Interface to CMOS, NMOS, and TTL
•
Operating Voltage Range: 4.5 to 5.5 V
•
Low Input Current: 1.0
mA
•
In Compliance with the Requirements Defined by JEDEC Standard
No. 7 A
•
Chip Complexity: 196 FETs or 49 Equivalent Gates
•
These Devices are Pb−Free and are RoHS Compliant
