BAT54
THRU
BAT54S
•
Features
Lead Free Finish/Rohs Compliant ("P"Suffix designates
RoHS Compliant. See ordering information)
Low Forward Voltage
Surface Mount device
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Halogen
free available upon request by adding suffix "-HF"
MCC Catalog
Number
Device Marking
1
KL1
KL2
KL3
KL4
2
L4
/L4P
L42
L43
L44
Type
Single
Dual
Dual
Dual
Pin
Configuration
See page 3
Figure 1
Figure
2
Figure 3
Figure 4
F
•
•
•
•
•
200mWatt, 30Volt
Schottky Barrier Diode
SOT-23
A
D
BAT54
BAT54A
BAT54C
BAT54S
C
B
Maximum Ratings
Continuos Reverse Voltage
Forward ContinuousCurrent
Non-Repetitive Peak Forward Current t<1s
Total Power Dissipation @ T
A
= 25°C
Storage Temperature Range
Operating Junction Temperature Range
Soldering temperature during 10s
V
R
I
F
I
FSM
P
D
T
stg
T
j
T
j
30V
200mA
0.6A
200mW
-55°C to 150°C
-55°C to 125°C
260°C
G
E
H
J
K
DIMENSIONS
Electrical Characteristics @ 25
°C
Unless Otherwise Specified
Characteristics
Forward Voltage at
I
F
= 0.1mA
I
F
= 1mA
I
F
= 10mA
I
F
= 30mA
I
F
= 100mA
Reverse Current
Symbol
Max.
Notes
V
F
I
R
240mV
320mV
400mV
500mV
1000mV
2.0 uA
DIM
A
B
C
D
E
F
G
H
J
K
INCHES
MIN
.110
.083
.047
.035
.070
.018
.0005
.035
.003
.015
MAX
.120
.104
.055
.041
.081
.024
.0039
.044
.007
.020
MM
MIN
2.80
2.10
1.20
.89
1.78
.45
.013
.89
.085
.37
MAX
3.04
2.64
1.40
1.03
2.05
.60
.100
1.12
.180
.51
NOTE
Suggested Solder
Pad Layout
V
R
= 25V
.035
.900
.031
.800
Capacitance
C
J
10pF
Reverse Recovery
Time
Thermal Resistance,
Junction to Ambient
t
rr
R
θJA
5nS
500
°C/W
Measured at
1.0MHz, V
R
=1.0V
I
F
=I
R
=10mA;
I
(REC)
= 1mA
.037
.950
.037
.950
.079
2.000
in
ches
mm
Revision:
C
www.mccsemi.com
1 of 3
2014/04/24
BAT54 thru BAT54S
1
100
MCC
Micro Commercial Components
T
A
= 125ºC
TM
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
0.1
10
T
A
= 75ºC
T
A
= 125ºC
1
T
A
= 75ºC
T
A
= 25ºC
0.01
T
A
= 25ºC
T
A
= 0ºC
0.1
T
A
= 0ºC
0.001
T
A
= -40ºC
0.01
0.0001
0
0.2
0.4
0.6
0.8
1.0
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig.
1 Forward Characteristics
12
f = 1.0MHz
0.001
0
5
10
15
20
25
30
V
R
, INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 2 Typical Reverse Characteristics
P
D,
POWER DISSIPATION (mW)
0
5
10
15
20
25
30
10
C
T
, TOTAL CAPACITANCE (pF)
200
8
6
100
4
2
0
0
0
25
50
75
100
125
V
R
, REVERSE VOLTAGE (V)
Fig. 3 Typical Capacitance vs. Reverse Voltage
T
A
, AMBIENT TEMPERATURE (
°
C)
Fig. 4 Power Derating Curve
Pin Configuration - Top View
3
1
Figure 1
2
Figure 2
Figure 3
Figure 4
BAT54
BAT54A
BAT54C
BAT54S
Revision:
C
www.mccsemi.com
2 of 3
2014/04/24
MCC
Micro Commercial Components
TM
Ordering Information :
Device
Part Number-TP
Note : Adding "-HF" suffix for halogen free, eg. Part Number-TP-HF
Packing
Tape&Reel:
3Kpcs/Reel
