BYM13-30-E3-96

Description
Schottky Diodes & Rectifiers 1.0 Amp 30 Volt 30 Amp IFSM
Categorysemiconductor    Discrete semiconductor
File Size84KB,4 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Download Datasheet Parametric View All

BYM13-30-E3-96 Online Shopping

Suppliers Part Number Price MOQ In stock
BYM13-30-E3-96 - - View Buy Now

BYM13-30-E3-96 Overview

Schottky Diodes & Rectifiers 1.0 Amp 30 Volt 30 Amp IFSM

BYM13-30-E3-96 Parametric

Parameter NameAttribute value
Product AttributeAttribute Value
ManufacturerVishay
Product CategorySchottky Diodes & Rectifiers
RoHSDetails
ProductSchottky Rectifiers
Mounting StyleSMD/SMT
Package / CaseMELF (DO-213AB)
If - Forward Current1 A
Vrrm - Repetitive Reverse Voltage30 V
Vf - Forward Voltage0.5 V
Ifsm - Forward Surge Current30 A
ConfigurationSingle
TechnologySi
Ir - Reverse Current500 uA
Minimum Operating Temperature- 55 C
Maximum Operating Temperature+ 125 C
PackagingCut Tape
PackagingMouseReel
PackagingReel
Height2.67 mm
Length5.2 mm
Operating Temperature Range- 55 C to + 125 C
TypeSchottky Diode
Width2.67 mm
Factory Pack Quantity1500
Unit Weight0.004833 oz
BYM13-xx, SGL41-xx
www.vishay.com
Vishay General Semiconductor
Surface Mount Schottky Barrier Rectifier
FEATURES
• MELF Schottky rectifier
• Ideal for automated placement
• Guardring for overvoltage protection
• Low power losses, high efficiency
• Low forward voltage drop
• High surge capability
• Meets MSL level 1, per J-STD-020, LF maximum peak of
250 °C
DO-213AB
• AEC-Q101 qualified
• Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
TYPICAL APPLICATIONS
PRIMARY CHARACTERISTICS
I
F(AV)
V
RRM
I
FSM
V
F
T
J
max.
Package
Diode variations
1.0 A
20 V to 60 V
30 A
0.50 V, 0.70 V
125 °C, 150 °C
DO-213AB
Single
For use in low voltage high frequency inverters,
freewheeling, DC/DC converters, and polarity protection
applications
MECHANICAL DATA
Case:
DO-213AB
Molding compound meets UL 94 V-0 flammability rating
Base P/N-E3 - RoHS-compliant, commercial grade
Base P/NHE3 - RoHS-compliant, AEC-Q101 qualified
Terminals:
Matte tin plated leads, solderable per
J-STD-002 and JESD 22-B102
E3 suffix meets JESD 201 class 1A whisker test, HE3 suffix
meets JESD 201 class 2 whisker test
Polarity:
Two bands indicate cathode end 1
st
band denotes
device type 2
nd
band denotes voltage type
MAXIMUM RATINGS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
DENOTES SCHOTTKY DEVICES:
ORANGE
1
st
BAND IS
SYMBOL BYM13-20 BYM13-30 BYM13-40 BYM13-50 BYM13-60 UNIT
SGL41-20
Gray
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
dV/dt
T
J
T
STG
- 55 to + 125
- 55 to + 150
20
14
20
SGL41-30
Red
30
21
30
SGL41-40
Orange
40
28
40
1.0
30
10 000
- 55 to + 150
SGL41-50
Yellow
50
35
50
SGL41-60
Green
60
42
60
V
V
V
A
A
V/μs
°C
°C
Polarity color bands (2
nd
band) voltage type
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current (fig. 1)
Peak forward surge current 8.3 ms single half
sine-wave superimposed on rated load
Voltage rate of change (rated V
R
)
Operating junction temperature range
Storage temperature range
Reivision: 13-Aug-13
Document Number: 88548
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
