BAS170WS
www.vishay.com
Vishay Semiconductors
Small Signal Schottky Diode
FEATURES
• Schottky diode for high-speed switching
• Circuit protection
• Voltage clamping
• High-level detecting and mixing
• AEC-Q101 qualified available
• Base P/N-E3 - RoHS-compliant, commercial grade
• Base P/N-HE3 - RoHS-compliant, AEC-Q101 qualified
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
DESIGN SUPPORT TOOLS
click logo to get started
Models
Available
MECHANICAL DATA
Case:
SOD-323
Weight:
approx. 4.3 mg
Packaging codes/options:
18/10K per 13" reel (8 mm tape), 10K/box
08/3K per 7" reel (8 mm tape), 15K/box
PARTS TABLE
PART
BAS170WS
ORDERING CODE
BAS170WS-E3-08 or BAS170WS-E3-18
BAS170WS-HE3-08 or BAS170WS-HE3-18
CIRCUIT
CONFIGURATION
Single
TYPE MARKING
73
REMARKS
Tape and reel
ABSOLUTE MAXIMUM RATINGS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Repetitive peak reverse voltage
Forward continuous current
Surge forward current
Power dissipation
(1)
TEST CONDITION
SYMBOL
V
RRM
I
F
I
FSM
P
tot
VALUE
70
70
600
200
UNIT
V
mA
mA
mW
t
p
< 1 s
Note
(1)
Valid provided that electrodes are kept at ambient temperature
THERMAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Thermal resistance junction to ambient air
(1)
Junction temperature
Operating temperature range
Storage temperature range
TEST CONDITION
SYMBOL
R
thJA
T
j
T
op
T
stg
VALUE
650
125
-55 to +125
-65 to +150
UNIT
K/W
°C
°C
°C
Note
(1)
Valid provided that electrodes are kept at ambient temperature
ELECTRICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Reverse breakdown voltage
Leakage current
Forward voltage
Forward voltage
(1)
Diode capacitance
Differential forward resistance
Note
(1)
Pulse test; t
≤
300 μs
p
Rev. 2.2, 01-Jun-17
Document Number: 85653
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
TEST CONDITION
I
R
= 10 μA (pulsed)
V
R
= 50 V
V
R
= 70 V
I
F
= 1 mA
I
F
= 10 mA
I
F
= 15 mA
V
R
= 0 V, f = 1 MHz
I
F
= 5 mA, f = 10 kHz
SYMBOL
V
(BR)
I
R
I
R
V
F
V
F
V
F
C
D
r
f
MIN.
70
TYP.
MAX.
0.1
10
410
750
1000
2
UNIT
V
μA
μA
mV
mV
mV
pF
Ω
375
705
880
1.5
34
BAS170WS
www.vishay.com
PACKAGE DIMENSIONS
in millimeters (inches):
SOD-323
1.15 [0.045]
0.8 [0.031]
0.2 [0.008]
0.1 [0.004] max.
1.1 [0.043]
Vishay Semiconductors
0.15 [0.006]
0.25 [0.010]
1.95 [0.077]
Cathode bar
1.60 [0.063]
0.40 [0.016]
0.20 [0.008]
2.85 [0.112]
2.50 [0.098]
Footprint recommendation:
0.8 [0.031]
1.5 [0.059]
0° - 8°
0.40 [0.016]
0.10 [0.004]
0.8 [0.031]
1.6 [0.063]
Document no.:
S8-V-3910.02-001
(4)
Created - Date: 24.August.2004
Rev. 6 - Date: 23.Sept.2016
17443
Rev. 2.2, 01-Jun-17
Document Number: 85653
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
0.6 [0.024]
