MS27467E23A55SC datasheet, PDF

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> The connector> MS27467E23A55SC

Preview

MS27467E23A55SC: DescriptionCircular MIL Spec Connector Connectors, Interconnects - CONN PLUG 55POS STRAIGHT W/SCKT - Circular; CategoryThe connector The connector; File Size107KB，1 Pages; ManufacturerAmphenol; Websitehttp://www.amphenol.com/

Download Datasheet Parametric View All

MS27467E23A55SC Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	MS27467E23A55SC	-	-	View	Buy Now

MS27467E23A55SC Overview

Circular MIL Spec Connector Connectors, Interconnects - CONN PLUG 55POS STRAIGHT W/SCKT - Circular

MS27467E23A55SC Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Amphenol
Reach Compliance Code	compliant
Other features	STANDARD:MIL-C-38999, EMI SHIELDED, COMPATIBLE CONTACT:M39029/56-351
Back shell type	SOLID
Body/casing type	PLUG
Connector type	MIL SERIES CONNECTOR
Contact to complete cooperation	GOLD
Contact completed and terminated	GOLD
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
Coupling type	BAYONET
DIN compliance	NO
empty shell	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e4
MIL compliance	YES
Manufacturer's serial number	MS27467
Mixed contacts	NO
Installation type	CABLE
Options	GENERAL PURPOSE
Shell surface	CADMIUM PLATED NICKEL BASE
Shell material	ALUMINUM
Housing size	23
Termination type	CRIMP
Total number of contacts	55

Preview

Download Datasheet

View All

Amphenol

Aerospace

38999

III

HD

Dualok

II

I

SJT

Commercial

Connector

Type

Shell

Style

Service

Class

LJT06R (MS27467) Series I – Crimp

Straight Plug

PART #

LJT

Part number reference. To complete,

see how to order pages 62-66.

Shell Size

& Insert Arrg

Contact Alternate

Type

Position

Special

Variations

06

Service

Class

RE

Shell

Size

22-2

Finish

Insert

Arrg

P

A

(XXX)

Alternate

Position

Military

MS

Number

Contact Style

(P or S)

MS27467

E

14

A

18

P

A

1.219

MAX

A

ccessories

A

quacon

H

erm/Seal

PCB

GROUNDING RING

D

HigH

Speed

Fiber

Optics

Connectors

Contacts

Cables

+.003

–.002

1.656 MAX

V

±.025

eMi Filter

Transient

.594

Q

.325

LJT06RE-XX-XXX (MS27467E)

LJT06RT-XX-XXX (MS27467T)

VIEW D ENLARGED

FOR COAXIAL USE ONLY

Matrix 2

26482

L

83723 iii

Matrix|pyle

GROUNDING RING

F

KK

26500

pyle

Crimp Rear

Release

Matrix

5015

.594

+.003

–.002

.325

±.025

LJT06RP-XX-XXX (MS27467P)

22992

Class L

Shell

Size

9

11

13

15

17

19

21

23

25

F Dia.

±.010

.444

.528

.683

.808

.909

1.034

1.159

1.284

1.409

L Max.

1.531

1.625

Q

Max.

.844

.969

1.141

1.266

1.391

1.500

1.625

1.750

1.875

V Thread Class 2A

(Plated)

.4375-28 UNEF

.5625-24 UNEF

.6875-24 UNEF

.8125-20 UNEF

.9375-20 UNEF

1.0625-18 UNEF

1.1875-18 UNEF

1.3125-18 UNEF

1.4375-18 UNEF

KK Dia.

Max.

.608

.734

.858

.984

1.110

1.234

1.360

1.484

1.610

Options

Others

Back-

Shells

All dimensions for reference only.

88

Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
