Resonator SMD, 2 Pin
Features:
- Low cost
- Consumer electronics
- Microprocessor systems
- Excellent for automatotive applications
Specifications
Part
Frequency range (MHz)
Frequency accuracy (25°C)
Temp. stability (-20°C ~ +80°C)
Aging (over 10 years)
Load capacitance ( pF )
C1
C2
ZTACV/MG
ZTACV/MX
ZTACW/MX
ZTACV/MT
8.0 ~ 13.0
+/-0.5%
+/-0.4%
+/-0.3%
30
30
30
30
ZTACV/MX
ZTACW/MX
26 ~ 50.0
13.01 ~ 20.0 20.01 ~ 25.99 26.0 ~ 50.0 20.0 ~ 25.99
+/-0.5%
+/-0.4%
+/-0.3%
15
15
5
5
15
15
+/-0.5%
+/-0.3%
+/-0.3%
5
5
Drawing
ZTACV
ZTACW
Dimensions in mm
Test circuit
C1 C2 :
IC :
X :
as listed
1/6 4069UBP x 2 (MT)
1/6 74HCU04 x 2 (MX)
Ceramic Resonator
Order key
R
Part
- 15.000000M - ZTACV/MX
Frequency
Type/Package
- 0.5
Frequency
tolerance
- 0.4
Temperature
tolerance
+/-%
(Temp. range)
-H
Temperature
range
H=-20°C ~ +80°C
- 30/30
Load
capacitance
pF
C1/C2
R=Resonator
K=KHz
M=MHz
ZTACV/MT
ZTACV/MX
ZTACW/MX
+/-KHz or %
(25°C)
Remarks: All specifications subject to change without notice!
