3907-0-18-01-30-14-10-0 datasheet, PDF

Datasheet> All Categories > The connector> terminals> 3907-0-18-01-30-14-10-0

3907-0-18-01-30-14-10-0: DescriptionCircuit Board Hardware - PCB #30 CONTACT PIN RCPT; CategoryThe connector terminals; File Size824KB，1 Pages; ManufacturerMill-Max; Websitehttps://www.mill-max.com

Download Datasheet Parametric View All

3907-0-18-01-30-14-10-0 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	3907-0-18-01-30-14-10-0	-	-	View	Buy Now

3907-0-18-01-30-14-10-0 Overview

Circuit Board Hardware - PCB #30 CONTACT PIN RCPT

3907-0-18-01-30-14-10-0 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Reach Compliance Code	compliant
ECCN code	EAR99
Manufacturer's serial number	3907
terminal gender	FEMALE
Terminal and terminal strip types	PCB TERMINAL
Base Number Matches	1

Preview

Download Datasheet

View All

RECEPTACLES

FOR 0,38 - 0,64 DIAMETER PINS

0385

0385-0-15-XX-43-XX-10-0

Press-fit in 1,17 mounting hole

4001

1,83 DIA.

1,52 DIA.

4001-0-15-XX-43-XX-04-0

Press-fit in 1,45 mounting hole

0,76

0,79 2,34

3,71

5,84

1782

1,42 DIA.

1,22 DIA.

1,14 DIA.

0,97 DIA.

HOLE

0,51 DIA.

1782-0-15-XX-43-XX-04-0

Press-fit in 1,14 mounting hole

5960

1,83 DIA.

5960-0-15-XX-43-XX-04-0

Hex press-fit in 1,45 plated

through-hole

0,51

0,64 2,11

0,89

2,11 1,65

0,76 3,684,57

1,35 DIA.

0,71 DIA.

1,4 DIA.

1,14 DIA.

1,24 DIA.

0,99 DIA.

0,81 DIA.

HOLE

2,79

3,35

2,18 2,39

3,68

0,56

4,19

1,35 DIA.

2,92

3,3

1,52 DIA.

0,46 DIA.

3,68

1401/3185

XXXX-0-15-XX-30-XX-10-0

4310

Basic Part

Number

Length

Depth

1,4 DIA.

1,52 DIA.

1,4 DIA.

0,97 DIA.

1,14 DIA.

0,97 DIA.

0,66 DIA.

HOLE

Solder mount in 1,4 min. mounting hole

Also available on 16mm wide carrier tape:

1,700 parts per 330mm reel

Order as: XXXX-0-57-XX-30-XX-10-0

1,83 DIA.

4310-0-31-XX-43-XX-04-0

1385

Compliant press-fit in 1,02 ± 0,08 plated

through-hole. For 2,29

3,30 thick board

1,02

2,21

1385-0-15-XX-43-XX-10-0

Surface mount

0,25

2,54

3,18

0,79

2,44

1,47 DIA.

1,35 DIA.

1,37 DIA.

1,35 DIA.

1401-0

3185-0

4,19

3,30

3,68

2,77

2,11

3,43 3,68

5,08

1,35

3,0

0,25

1,47 DIA.

0,99 DIA.

0,46

SLOT

3018

1,8 DIA.

1,52 DIA.

KNURL

1,35 DIA.

3018-0-15-XX-30-XX-04-0

Press-fit in 1,45 mounting hole

0,71

0,76

2,39

0,64

3,94

28,02

8852

1,8 DIA.

1,5 DIA.

8852-0-15-XX-30-XX-04-0

Press-fit in 1,42 mounting hole

0,79

0,71 2,62

5,08

1,32 DIA.

6,4

3907

3907-0-18-XX-30-XX-10-0

Surface mount

Also available on 12mm wide carrier tape:

4,000 parts per 330mm reel

Order as: 3907-0-58-XX-30-XX-10-0

2,54 DIA.

0,51

2,11

2,92

1,09 DIA.

1,52

1,5

2,03

2,13 DIA.

P.C.B. Layout

1,75

0,50 DIA.

4,39

0,51 DIA.

3,15

0,25

2,41

P.C.B. PAD

2,41

PAGE 170 | PIN RECEPTACLES

SPECIFICATIONS:

Shell Material:

Brass Alloy 360, 1/2 Hard

Contact Material:

Beryllium Copper Alloy 172, HT

Dimensions: Millimeters

Tolerances On:

Lengths:

± 0,13

2011/65/EU

ORDER CODE: XXXX - X - XX - XX -

- XX - XX - 0

BASIC PART #

SPECIFY SHELL FINISH:

5,08μm TIN/LEAD OVER NICKEL

5,08μm TIN OVER NICKEL (RoHS)

0,25μm GOLD OVER NICKEL (RoHS)

SPECIFY CONTACT FINISH:

2,54μm TIN/LEAD OVER NICKEL

2,54μm TIN OVER NICKEL (RoHS)

0,76μm GOLD OVER NICKEL (RoHS)

Diameters: ± 0,051

Angles:

±2°

RoHS - 2

SELECT CONTACT:

#30, #35 or #43

CONTACT (DATA ON PAGE 253 & 254)

(For alternate contact choices, see groups B and C on page 248)

Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
