Halogen and Antimony Free. “Green” Device (Note 3)
Applications
•
•
•
•
•
Brushless DC Motor Commutation
Revolution Per Minute (RPM) Measurement
Flow Meters
Angular and Linear Encoder and Position Sensors
Contact-less Commutation, Speed Measurement and Angular
Position Sensing/Indexing in Consumer Home Appliances, Office
Equipments and Industrial Applications
•
•
•
•
•
•
•
Notes:
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
Electrostatic Discharge Withstand Capability - Human Body Model
SIP-3
SC59 and SOT23
Characteristic
Value
32
-0.3
32V
60
Unlimited
550
230
-65 to +165
+150
6
Unit
V
V
V
mA
mW
mW
°C
°C
kV
PRELIMINARY - CONFIDENTIAL
V
DDR
V
OUT_MAX
I
OUT
B
P
D
Ts
T
J
ESD
Notes:
5. Stresses greater than the 'Absolute Maximum Ratings' specified above may cause permanent damage to the device. These are stress ratings only;
functional operation of the device at these or any other conditions exceeding those indicated in this specification is not implied. Device reliability may be
affected by exposure to absolute maximum rating conditions for extended periods of time.
6. The absolute maximum V
DD
of 32V is a transient stress rating and is not meant as a functional operating condition. It is not recommended to
operate the device at the absolute maximum rated conditions for any period of time.
Recommended Operating Conditions
(@T
A
= -40°C to +125°C, unless otherwise specified.)
Symbol
V
DD
T
A
Parameter
Supply Voltage
Operating Temperature Range
Operating
Operating
Conditions
Rating
3.0 to 28
-40 to +125
Unit
V
°C
Electrical Characteristics
Symbol
V
OUT_ON
I
OUT_OFF
I
DD
R
PU
t
ST
f
c
(Notes 7 & 8) (@T
A
= -40°C to +125°C, V
DD
= 3V
to 28V, unless
otherwise specified.)
Conditions
I
OUT
= 20mA, B > B
OP
V
OUT
= 28V, B <
B
RP
, Output off
Output open, V
DD
= 12V , T
A
= 25°C
Output open, T
A
= -40°C to +125°C
T
A
= -40°C to 125°C,
V
DD
>= 3V, B >
B
OP
(Note 7)
V
DD
= 3V
to 28V
Min
-
-
-
-
10
-
-
Typ
0.2
<0.1
3.8
3.8
14
10
800
Max
0.4
15
4.9
5.8
18
-
Unit
V
µA
mA
mA
kΩ
µs
kHz
Parameter
Output On Voltage
Output Leakage Current
Supply Current
Internal Pull-Up Resistance
Device Start-Up Time
Chopping Frequency
The time delay from magnetic
threshold reached to the start of the
output rise or fall
Output Rising Time
(external pull-up resistor R
L
and load
capacitance dependent)
Output Falling Time
(Internal switch resistance and load
capacitance dependent)
Output Current Limit
Zener Clamp Voltage
t
d
t
r
(Note 9)
R
L
=1kΩ, C
L
= 20pF
-
-
3.75
0.2
-
1
µs
µs
t
f
I
OCL
V
Z
Notes:
R
L
=1kΩ, C
L
= 20pF
B > B
OP
, (Note 10 )
I
DD
= 5mA
-
30
28
0.1
-
-
1
55
-
µs
mA
V
7. When power is initially turned on, V
DD
must be within its correct operating range (3.0V to 28V) to guarantee the output sampling. The output state is valid
after the start-up time of 10us typical
from the operating voltage reaching 3V.
8. Typical values are defined at T
A
= +25
°C
, V
DD
= 12V. Maximum and minimum values over the operating temperature range is not tested in production
but guaranteed by design, process control and characterization
9. Guaranteed by design, process control and characterization. Not tested in production.
