T3/DS3/E3/STS-1 TRANSFORMERS
Twelve Transformers Designed for
T3, DS3, E3 and STS-1 Interface
RoHS peak reflow temperature rating 245°C
Twelve transformers in a surface mount package
Extended temperature range of -40°C to +85°C
Return loss meets requirements of G.703
UL recognized
Electrical Specifications @ 25°C — Operating Temperature -40°C to +85°C
RoHS Compliant Turns Ratio
Part Number
(Pri:Sec ±2%)
TX3051NL
1:1
OCL Primary
@ 25°C
(µH MIN)
60
OCL Primary
@ -40°C
(µH MIN)
40
L
L
(µH MAX)
.120
Cw/w
Isolation Voltage
(pF MAX)
(Vrms MIN)
12
1500
Primary Pins
1-2, 3-4, 5-6, 7-8
9-10, 11-12, 13-14, 15-16
17-18, 19-20, 21-22, 23-24
1-2, 3-4, 5-6, 7-8
9-10, 11-12, 13-14, 15-16
17-18, 19-20, 21-22, 23-24
TX3052NL
1:2
40
19
.110
12
1500
NOTE:
Crosstalk is typically -60dB.
TX3051NL, TX3052NL
Mechanical
Tape & Reel
. . . . . . . . . . . . . . 250/reel
Tube
. . . . . . . . . . . . . . . . . . . . 15/tube
Dimensions:
Inches
mm
Unless otherwise specified, all
tolerances are ± .010
0,25
48
47 46
45 44
43 42
41 40
39 38
37 36
35 34
33 32
31 30
29 28
27 26
25
Schematic
1
2
3
4
5
6
7
8
9
10 11
12 13
14 15
16 17
18 19
20 21
22 23
24
For More Information:
Pulse Europe
Einsteinstrasse 1
12220 World Trade Dr. D-71083 Herrenberg
Germany
San Diego, CA 92128
U.S.A.
Pulse Worldwide
Headquarters
www.pulseeng.com
Tel: 858 674 8100
Fax: 858 674 8262
Pulse China Headquarters
B402, Shenzhen Academy of
Aerospace Technology Bldg.
10th Kejinan Rd.
High-Tech Zone
Nanshan District
Shenzen, PR China 518057
Tel: 49 7032 7806 0
Tel: 86 755 33966678
Fax: 49 7032 7806 135 Fax: 86 755 33966700
Pulse North China
Room 2704/2705
Super Ocean Finance Ctr.
2067 Yawwn An Rd.
West
Shanghai 200336
China
Tel: 86 21 62787060
Fax: 86 2162786973
Pulse South Asia Pulse North Asia
135 Joo Seng Rd.
#03-02
PM Industrial Bldg.
Singapore 368363
3F, No. 198
Zhongyuan Rd.
Zhongli City
Taoyuan County 320
Taiwan R. O. C.
Tel: 886 3 4356768
Fax: FRE 886 3 43568 20
Pulse: 886 3 4356823
Tel: 65 6287 8998
Fax: 65 6287 8998
Performance warranty of products offered on this data sheet is limited to the parameters specified. Data is subject to change without notice. Other brand and product
names mentioned herein may be trademarks or registered trademarks of their respective owners.
© Copyright, 2009. Pulse Engineering, Inc. All rights reserved.
www.pulseeng.com
1
T668.B (10/09)
