J-CAP
TM
Series
Highest Joules/cc Conductive Polymer Solid Electrolytic Chip Capacitors
FEATURES
•
Highest Energy per volume
• Fast DCL drop with Voltage applied after reflow
• Benign failure mode under recommended use conditions
• Low ESR
• Undertab terminations layout:
- High Volumetric Efficiency
- Low profile case sizes
- High capacitance in smaller dimensions
- Close positioning of several parts for efficient high density PCB layout
• 3x reflow 260°C compatible
Polarity Band (Anode+)
LEAD-FREE COMPATIBLE
COMPONENT
W
L
W
APPLICATIONS
• Power backup for SSDs (MLC, SLC, EFD, PCIe), battery-powered portable equipment,
industrial alarms, smart power meters, and mobile devices.
H
W
P
A
P
S
A
N
W
N
CASE DIMENSIONS Undertab:
millimeters (inches)
Code
L
T
X
4
EIA
Code
1210
1210
2917
2924
EIA
Metric
3528-10
3528-12
7343-15
7361-20
L±0.20
(0.008)
3.50 (0.138)
3.50 (0.138)
7.30 (0.287)
7.30 (0.287)
W+0.20 (0.008)
-0.10 (0.004)
2.80 (0.110)
2.80 (0.110)
4.30 (0.169)
6.10 (0.240)
H max.
1.00 (0.039)
1.20 (0.047)
1.50 (0.059)
2.00 (0.079)
W
P
±0.10
(0.004)
2.50 (0.098)
2.50 (0.098)
3.25 (0.128)
4.75 (0.187)
W
N
±0.10
(0.004)
2.10 (0.083)
2.10 (0.083)
3.25 (0.128)
4.75 (0.187)
A
P
±0.10
(0.004)
1.15 (0.045)
1.15 (0.045)
2.00 (0.079)
2.00 (0.079)
A
N
±0.10
(0.004)
1.35 (0.053)
1.35 (0.053)
3.20 (0.126)
3.20 (0.126)
S Min.
1.00 (0.039)
1.00 (0.039)
2.10 (0.083)
2.10 (0.083)
MAXIMUM ENERGY
PER CASE SIZE
CASE DIMENSIONS J-lead:
millimeters (inches)
Code
C
D
E
H
5
EIA
Code
2312
2917
2917
1210
2917
EIA
Metric
6032-28
7343-31
7343-43
3528-15
7343-40
L±0.20
W+0.20 (0.008) H+0.20 (0.008)
(0.008)
-0.10 (0.004)
-0.10 (0.004)
6.00 (0.236)
3.20 (0.126)
2.60 (0.102)
7.30 (0.287)
4.30 (0.169)
2.90 (0.114)
7.30 (0.287)
4.30 (0.169)
4.10 (0.162)
3.50 (0.138)
2.80 (0.110)
1.50 (0.059) max.
7.30 (0.287)
4.30 (0.169)
3.80 (0.150)
W
1
±0.20
(0.008)
2.20 (0.087)
2.40 (0.094)
2.40 (0.094)
2.20 (0.087)
2.40 (0.094)
A+0.30 (0.012)
-0.20 (0.008)
1.30 (0.051)
1.30 (0.051)
1.30 (0.051)
0.80 (0.031)
1.30 (0.051)
S Min.
2.90 (0.114)
4.40 (0.173)
4.40 (0.173)
1.40 (0.055)
4.40 (0.173)
W1 dimension applies to the termination width for A dimensional area only.
MARKING
4 CASE
AVX LOGO
Polymer
Capacitance Value in pF
158 = 1500µF
Rated Voltage
J = 6.3V
ID Code
Case
Size
C
D
E
H
L
T
X
4
5
H Max
(mm)
2.8
3.1
4.3
1.5
1.0
1.2
1.5
2.0
4.0
Max Energy
(mJ)
5.8
21.8
11.9
2.6
1.8
6.5
18.2
43.0
46.6
C, D, E, H, L, T, X, 5 CASE
AVX LOGO
Polymer
Capacitance Value in pF
158 = 1500µF
Rated Voltage
J = 6.3V
ID Code
Polarity
Band
(Anode+)
158 J
XXXXX
Polarity
Band
(Anode+)
158 J
XXXXX
HOW TO ORDER
TCN
4
Type
TCJ
TCN
Case Size
See table
above
158
M
Tolerance
M = ±20%
006
Rated DC Voltage
006 = 6.3Vdc
010 = 10Vdc
016 = 16Vdc
020 = 20Vdc
025 = 25Vdc
035 = 35Vdc
050 = 50Vdc
R
Packaging
R = Pure Tin 7" Reel
S = Pure Tin 13" Reel
(J-Lead)
0055
ESR in mΩ
Capacitance Code
pF code: 1st two digits
represent significant figures,
3rd digit represents multiplier
(number of zeros to follow)
011918
217
J-CAP
TM
Series
Highest Joules/cc Conductive Polymer Solid Electrolytic Chip Capacitors
TECHNICAL SPECIFICATIONS
Technical Data:
Capacitance Range:
Capacitance Tolerance:
Leakage Current DCL:
Rated Voltage (V
R
)
Surge Voltage (V
S
)
Temperature Range:
Reliability:
All technical data relate to an ambient temperature of +25°C
4.7 μF to 1500 μF
±20%
0.1CV
6.3
10
16
20
25
35
50
8
13
21
26
33
46
65
-55°C up to +125°C
1% per 1000 hours at 85°C, V
R
with 0.1Ω/V series impedance
60% confidence level
+85ºC:
+85ºC:
NOTE: Conductive Polymer Capacitors are designed to operate within the limits of the environmental conditions specified for each series. If operated continuously
at their maximum temperature and / or humidity limit, or beyond these limits, capacitors may exhibit a parametric shift in capacitance and increases in ESR. These
changes may occur earlier if the specified environmental conditions are exceeded. Similarly, their normal operational time period will be significantly extended if their
general duty cycle includes operation below maximum temperature within humidity controlled environments. Careful attention should be paid to maximum temper-
ature with associated high humidity environments as well as voltage derating, ripple current and current surges. Please reference the AVX Conductive Polymer
Capacitor Guidelines for more information or contact factory for application assistance.
CAPACITANCE AND RATED VOLTAGE RANGE
(LETTER DENOTES CASE SIZE)
Capacitance
μF
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
1000
1500
Code
475
685
106
156
226
336
476
686
107
157
227
337
477
108
158
T(200)
H(170)
D(40)
X(50)
4(55)
4(55)
6.3V (J)
10V (A)
16V (C)
Rated Voltage DC to 85°C, [mJ]
20V (D)
25V (E)
35V (V)
L(300)
[1.8]
T(200)
50V (T)
C(100)
D(45)
D(45)
[1.7] D(45)
[2.6] D(40)
[3.8] 5(100)
[5.4]
[11.6]
[17.4]
T(200)
[3.3]
[1.7] T(150,200) [4.7]
[2.5] D(50)
[6.7] D(55)
[3.6] D(50)
[5.4] X(100)
D(50)
[7.9]
4(70)
4(70)
[11.9]
5(100)
5(100)
[9.9] D(55)
[14.9]
[21.8] 4(100)
[32.7] 4(100)
[46.6]
T(200)
T(250)
X(100)
[8.4] D(70)
D(70)
[12.4]
4(100)
4(70)
[27.2] 4(100)
[40.8]
C(200)
T(200)
[3.9] D(120)
C(200)
[5.8] E(70)
[4.3] D(100)
[8.5]
[6.5] D(70)
[12.8]
[9.2] X(100,150) [18.2]
[13.3]
[19.6] 4(100)
[29.3]
[43.0]
[38.8]
[5.4]
[8.0]
[11.9]
Released ratings, (ESR ratings in mOhms in parentheses) [Energy in mJ]
Engineering samples - please contact AVX
Note: Voltage ratings are minimum values. AVX reserves the right to supply
higher voltage ratings in the same case size, to the same reliability standards.
218
011918
J-CAP
TM
Series
Highest Joules/cc Conductive Polymer Solid Electrolytic Chip Capacitors
