Ultra Slim Inline Relay
PC458
FEATURES
Handles from signal level to 5 amps
1 Form A contact form
Ultra Slim, 5 MM package
SIL terminal pattern
Terminals on 1/10 in grid pattern
2 Kv dielectric between coil and contacts
Sealed, immersion cleanable
File # E86876
UL/CSA RATINGS
Load Type
General Use
Resistive
Minimum Load
All Forms
All Contacts
3A or 5A at 30VDC / 250VAC
3A or 5A at 30VDC / 250VAC
0.1 mA @ 0.1 VDC
CONTACT DATA
Material
Initial Contact Resistance
Service Life
AgCdO (Silver Cadmium Oxide)
AgCdO+Au (Silver Cad Oxide Gold Clad)
100 milliohms max @ 0.1A, 6VDC
1 X 10
5
Operations
7
Mechanical
2 X 10 Operations
Electrical
CHARACTERISTICS
Operate Time
Release Time
Insulation Resistance
Dielectric Strength
Shock Resistance
Vibration Resistance
Power Consumption
Ambient Temperature Range
Weight
6 ms. Max.
3 ms. Max.
1000 megohms min, at 500VDC, 50%RH
2000 Vrms, 1 min. between coil and contacts
1000 Vrms, 1 min. between open contacts
10 g, 11ms, functional; 100 g, destructive
DA 2.5 mm, 10 - 55 Hz
.12W
-40 to 70 C operating for class B, -40 to 130 C storage
3 grams approx.
ORDERING INFORMATION
Example:
Model
Contact Form
1A
Coil Voltage
Enclosure
S: Sealed; C: Flux Free
Contact Rating
3: 3 AMP; 5: 5 AMP
PC458
-1A
-12
S
-5
3220 Commander Drive, Suite 102, Carrollton, Texas 75006
Sales: Call Toll Free (888)997-3933 Fax (818) 342-5296 email: pickerwest@sbcglobal.net URL: pickercomponents.com
PC458 Rev C 4-5-04
PAGE 1
PC458
COIL DATA
Coil Voltage
3
5
6
9
12
18
Resistance
_
ohms + 10%
75
208
300
675
1200
2700
Must Operate
Voltage Max.
(VDC)
2.2
3.5
4.2
6.3
8.4
12.6
Must Release
Voltage Min.
(VDC)
0.15
0.25
0.30
0.45
0.60
0.90
1.20
PC458
Continuous
Voltage Max.
(VDC)
3.3
5.5
6.6
9.9
13.2
19.8
26.4
24
3200
16.8
Note: Custom coil voltages within the ranges shown are available on special order.
Dimensions in Inches (millimeters)
Drawings are 2X actual size
Side View
.787
(20.0)
End View
.197
(5.0)
.504
(12.5)
.138
(3.5)
.100
(2.54)
.300
(7.62)
.300
(7.62)
.046
(1.1)
.100
(2.54) Grid Pattern
.047 Dia. 4 Places
(1.2)
Hole Pattern
Notes:
Tolerances + .010 unless otherwise noted
Relays previously tested or used above 10mA at 6VDC or higher
are not recommended for subsequent use in low level applications
Wiring Diagram
