T-1 (3mm) SOLID STATE LAMP
L-934GD-12V
GREEN
Features
!
LOW POWER CONSUMPTION.
!
GENERAL PURPOSE LEADS.
!
RELIABLE AND RUGGED.
!
LONG LIFE - SOLID STATE RELIABILITY.
!
AVAILABLE ON TAPE AND REEL.
!
12V INTERNAL RESISTOR.
Description
The Green source color devices are made with Gallium
Phosphide Green Light Emitting Diode.
Package Dimensions
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notice.
SPEC NO: DSAA5342
APPROVED : J. Lu
REV NO: V.3
CHECKED :Allen Liu
DATE:MAR/15/2003
DRAWN:S.J.HOU
PAGE: 1 OF 3
Selection Guide
Par t No .
L-934GD-12V
GREEN (GaP)
Di c e
L en s Ty p e
GREEN DIFFUSED
8
Iv (mc d )
V=12V
Min .
Ty p .
20
View in g
An g l e
2θ1/2
60°
Note:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value..
Electrical / Optical Characteristics at T
)
=25°C
°
Sy m b o l
λ
peak
λ
D
∆λ
1/2
I
F
I
R
Par ameter
Peak Wavelength
Dominate Wavelength
Spectral Line Half-width
Forward Current
Reverse Current
Green
Green
Green
Green
Green
Dev ic e
Ty p .
565
568
30
8.5
11.5
10
Max .
Un i t s
nm
nm
nm
mA
uA
Tes t Co n d itio n s
V
F
=12V
V
F
=12V
V
F
=12V
V
F
=12V
V
R
=5V
Absolute Maximum Ratings at T
)
=25°C
°
Par ameter
Power dissipation
Forward voltage
Reverse voltage
OperatingTemperature
Storage Temperature
Lead Solder Temperature [1]
Note:
1. 2mm below package base.
Gr een
120
14
5
-40
°
C To +70
°C
-40
°
C To +85
°C
260
°
C For 5 Seconds
Un i t s
mW
V
V
SPEC NO: DSAA5342
APPROVED : J. Lu
REV NO: V.3
CHECKED :Allen Liu
DATE:MAR/15/2003
DRAWN:S.J.HOU
PAGE: 2 OF 3
