Cartridge Fuses
Low Profile JCASE
®
Cartridge Fuses Rated 58V
The Low Profile JCASE
®
fuse has similar performance characteristics as the standard JCASE
®
fuse. The lower overall height reduction allows for more space and weight savings and also
allows for a shorter male blade terminal, saving additional weight and material savings in fuse
box designs.
Specifications
Low Profile JCASE
®
Cartridge Fuses
Voltage Rating:
Interrupting Rating:
Operating Temperature Range:
Housing Material:
Cover Material:
Insertion Force:
Extraction Force:
Conforms to:
58 VDC
1000A @ 58 VDC
-40˚C to + 125˚C
PPA-GF13
PA66
53N Max. (12 lb.)
9N Min (2 lb.)
SAE 2741 and ISO 8820-4 except for the life test – LF
specification is 100-hours at 100% of rated current
Time-Current
Characteristic Curves
LOW PROFILE (LP) JCASE FUSE TIME-CURRENT CHARACTERISTIC CURVES
30A
40A
20A
25A
50A
60A
Ordering Information
Part Number
0895xxx.Z
0895xxx.U
0895xxx.T
Package Size
2000
500
10
Time-Current Characteristics
% of Rating
100
135
200
350
600
Opening Time Min / Max (s)
360,000 s / –
60 s / 1800 s
4 s / 60 s
0.200 s / 7 s
0.040 s / 1 s
Cold Resistance
(mΩ)
4.48
3.39
2.68
1.89
1.08
0.83
I
2
t
(A²s)
400
680
1780
5470
4880
9600
1000
100
Ratings
10
TIME IN SECONDS
Part Number
0895020_
0895025_
Current Rating
(A)
20
25
30
40
50
60
Housing
Material Color
Max. Voltage Drop
(mV)
125
125
125
125
125
125
1
0895030_
0895040_
0895050_
0.1
0895060_
Corresponding holder see Section “Fuse Holders.”
0.01
10
100
CURRENT IN AMPERES
1000
10000
Dimensions
Dimensions in mm
Littelfuse, Inc.
Confidential
October 2013
Temperature Rerating Curve
Littelfuse products are not designed for, and shall not be used for, any purpose (including, without limitation, automotive, military, aerospace, medical, life-saving, life-sustaining or nuclear facility applications, devices intended for
surgical implant into the body, or any other application in which the failure or lack of desired operation of the product may result in personal injury, death, or property damage) other than those expressly set forth in applicable Littelfuse
product documentation. Warranties granted by Littelfuse shall be deemed void for products used for any purpose not expressly set forth in applicable Littelfuse documentation. Littelfuse shall not be liable for any claims or damages
arising out of products used in applications not expressly intended by Littelfuse as set forth in applicable Littelfuse documentation. The sale and use of Littelfuse products is subject to Littelfuse Terms and Conditions of Sale, unless
otherwise agreed by Littelfuse.
