SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DATASHEET 290, REV. -
SHD114634
SHD114634A
SHD114634B
HERMETIC POWER SCHOTTKY RECTIFIER
Ultra Low Reverse Leakage
200°C Operating Temperature
Applications:
•
Switching Power Supply
•
Converters
•
Free-Wheeling Diodes
•
Polarity Protection Diode
Features:
•
•
•
•
•
•
•
Ultra low Reverse Leakage Current
Soft Reverse Recovery at Low and High Temperature
Very Low Forward Voltage Drop
Low Power Loss, High Efficiency
High Surge Capacity
Guard Ring for Enhanced Durability and Long Term Reliability
Guaranteed Reverse Avalanche Characteristics
ALL RATINGS ARE @ T
C
= 25
°C
UNLESS OTHERWISE SPECIFIED.
MAXIMUM RATINGS
RATING
PEAK INVERSE VOLTAGE
SYMBOL
PIV
I
O
I
FSM
(V
r
=5V)
C
T
R
θJC
Top
Tstg
MAX.
100
120
1650
3000
0.20
-65 to
+200
-65 to
+175
UNITS
Volts
Amps
Amps
pF
°C/W
°C
°C
MAXIMUM DC OUTPUT CURRENT (With Cathode Maintained @ T
C
=100
O
C)
MAXIMUM NONREPETITIVE FORWARD SURGE CURRENT
(t = 8.3ms, Sine)
MAXIMUM JUNCTION CAPACITANCE
MAXIMUM THERMAL RESISTANCE
(Junction to Mounting Surface, Cathode)
MAXIMUM OPERATING JUNCTION TEMPERATURE RANGE
MAXIMUM STORAGE TEMPERATURE RANGE
ELECTRICAL CHARACTERISTICS
CHARACTERISTIC
MAXIMUM FORWARD VOLTAGE DROP, Pulsed (I
f
= 120 Amps)
T
J
= 25
°C
T
J
= 125
°C
MAXIMUM REVERSE CURRENT (I
r
@ 100 V PIV)
T
J
= 25
°C
T
J
= 125
°C
SYMBOL
MAX.
UNITS
V
f
0.87
0.72
0.60
6.0
Volts
I
r
mA
•
221 WEST INDUSTRY COURT
•
DEER PARK, NY 11729-4681
•
PHONE (631) 586-7600
•
FAX (631) 242-9798
•
•
World Wide Web Site - http://www.sensitron.com
•
E-mail Address - sales@sensitron.com
•
SHD114634
SHD114634A
SHD114634B
SENSITRON
TECHNICAL DATA
DATASHEET 290, REV. -
MECHANICAL DIMENSIONS: In Inches / mm
.410±.010
(10.4±.254)
.550±.020
(14.0±.508)
.410±.010
(10.4±.254)
.560±.020
(14.2±.508)
.410±.010
(10.4±.254)
.150±.010
(3.81±.254)
.410±.010
(10.4±.254)
.410±.010
(10.4±.254)
.200±.010
(5.08 ±.254)
.410±.010
(10.4±.254)
.015±.005
(.381±.127)
.075 (1.91) Max
Alumina Ring
Moly Lid
.020±.005 R
(.508±.127 )
Copper Anode
.090 (2.29) Max
Alumina Ring
Moly Base
(Cathode)
.015±.002
(.381±.051)
.060±.010
(1.52±.254)
.020±.005 R
(.508±.127 )
.075 (1.91) Max
Alumina Ring
Moly Base
Moly Lid
Moly Base
(Cathode)
Moly Anode
.020±.002
(.508±.051)
.060±.010
(1.52±.254)
SHD-3
PINOUT TABLE
TYPE
SINGLE RECTIFIER
SHD-3A
PIN 1 (Base)
CATHODE
SHD-3B
PIN 2
ANODE
Typical Forward Characteristics
10
10
2
Instantaneous Reverse Current - I
R
(mA)
2
Typical Reverse Characteristics
10
1
200 °C
175 °C
150 °C
125 °C
200 °C
175 °C
10
0
Instantaneous Forward Current - I
F
(A)
10
1
10
-1
100 °C
75 °C
50 °C
25 °C
10
-2
10
-3
10
0
125 °C
10
-4
0
20
40
60
80
Reverse Voltage - V
R
(V)
100
120
Typical Junction Capacitance
25 °C
10
-1
Junction Capacitance - C
T
(pF)
2500
2000
1500
1000
500
0
20
40
60
80
100
Reverse Voltage - V
R
(V)
120
10
-2
0.1
0.2
0.3
0.4
0.5
0.6
Forward Voltage Drop - V (V)
F
0.7
0.8
•
221 WEST INDUSTRY COURT
•
DEER PARK, NY 11729-4681
•
PHONE (631) 586-7600
•
FAX (631) 242-9798
•
•
World Wide Web Site - http://www.sensitron.com
•
E-mail Address - sales@sensitron.com
•
SHD114634
SHD114634A
SHD114634B
SENSITRON
TECHNICAL DATA
DATASHEET 290, REV. -
DISCLAIMER:
1- The information given herein, including the specifications and dimensions, is subject to change without prior notice to improve product
characteristics. Before ordering, purchasers are advised to contact the Sensitron Semiconductor sales department for the latest version of the
datasheet(s).
2- In cases where extremely high reliability is required (such as use in nuclear power control, aerospace and aviation, traffic equipment, medical
equipment , and safety equipment) , safety should be ensured by using semiconductor devices that feature assured safety or by means of users’
fail-safe precautions or other arrangement .
3- In no event shall Sensitron Semiconductor be liable for any damages that may result from an accident or any other cause during operation of
the user’s units according to the datasheet(s). Sensitron Semiconductor assumes no responsibility for any intellectual property claims or any
other problems that may result from applications of information, products or circuits described in the datasheets.
4- In no event shall Sensitron Semiconductor be liable for any failure in a semiconductor device or any secondary damage resulting from use at
a value exceeding the absolute maximum rating.
5- No license is granted by the datasheet(s) under any patents or other rights of any third party or Sensitron Semiconductor.
6- The datasheet(s) may not be reproduced or duplicated, in any form, in whole or part, without the expressed written permission of Sensitron
Semiconductor.
7- The products (technologies) described in the datasheet(s) are not to be provided to any party whose purpose in their application will hinder
maintenance of international peace and safety nor are they to be applied to that purpose by their direct purchasers or any third party. When
exporting these products (technologies), the necessary procedures are to be taken in accordance with related laws and regulations.
•
