SMD Transient Voltage Suppressor
TV02W5V0-G Thru TV02W191-G
Working Peak Reverse Voltage:5.0-190Volts
Peak Pulse Power:200Watts
RoHS Device
Features
-Glass passivated chip.
-Low leakage current.
-200W peak pulse power capility with a
10/1000us waveform,repetitive rate
(duty cycle):0.01%.
-Uni and bidirectional unit.
-Excellent clamping capability.
-Very fast response time.
0.112 (2.81)
0.100 (2.51)
0.040 (1.00)
0.020 (0.50)
0.152 (3.82)
0.140 (3.51)
0.071 (1.78)
0.055 (1.38)
SOD-123
Mechanical data
-Case: Molded plastic.
-Epoxy: UL 94V-0 rate flame retardant.
-Lead: Axial leads, solderable per
MIL-STD-202,method 208 guranteed.
-Polarity: Color band denotes cathode end
except bipolar.
-Mounting position: Any.
0.053 (1.33)
0.037 (0.93)
0.008 (0.20)max
0.01 (0.25)min
Dimensions in inches and (millimeter)
Maximum Rating AND Electrical Characteristics
Ratings at 25
O
C ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Parameter
Peak power dissipation at 10/1000µs waveform
Peak power dissipation at 8/20µs waveform
Peak pulse current with a 10/1000µs waveform
Power dissipation on infinite heatsonk at T
L
= 75°C
Peak forward surge current, 8.3ms single half sone-wave
undirestional only
(1)
Operating junction and storage temperature range
Symbol
P
PP
P
PP
I
PP
P
D
I
FSM
T
J
,T
STG
Value
200
1000
See next table
0.4
20
-55 to +150
Unit
W
W
A
W
A
°C
Notes:
Measured on 8.3ms single half sine-wave or equivalent square wave, duty cycle=4 pulses per minute maximum.
REV:B
QW-BTV15
Page 1
Comchip Technology CO., LTD.
SMD Transient Voltage Suppressor
Rating and Characteristic Curves (TV02W5V0-G
Thru TV02W191-G)
Fig. 1 - Pulse Derating Curve
Steady State Power Dissipation,(W)
150
125
0.6
0.5
0.4
Fig.2 - Steady State Power
Derating Curve
Peak Pulse Derating in % of
Peak Power or Current, %
100
75
50
25
0
0
0.3
0.2
0.1
25
50
75
100
125
150
0
0
25
50
75 100 125 150 175 200
Ambient Temperature, (°C)
Lead Temperature, (°C)
Fig. 3 - Pulse Waveform
10
Tr=10µs
TJ=25°C
Fig. 4 - Peak Pulse Power
Rating Curve
100
Peak Value(I
PP
)
Pulse Width(td) is defined as
the point where the peak
current decays 50% of I
PPM
Peak Pulse Current, (%)
Half Value=I
PP
/2
Peak Power, (kW)
4
1
50
10/1000 µ sec.Waveform
as defined by R.E.A.
td
0
0
1
2
3
0.1
0.1µs
1µs
10µs
100µs
Time, (ms)
1ms
10ms
Pulse Width
Fig. 5 - Maximum non-repetitive
surge current
30
T
J
= T
J
max.
8.3 ms single half sine-wave
Peak forward surge current, (A)
20
10
0
1
10
100
Number of cycle at 60 Hz
REV:B
QW-BTV15
Page 2
Comchip Technology CO., LTD.
SMD Transient Voltage Suppressor
Electrical Characteristics (TV02W5V0-G
Thru TV02W191-G)
Absolute Maximum Rating
(Ta=25°C)
Part No
TV02W5V0(B)-G
TV02W6V0(B)-G
TV02W6V5(B)-G
TV02W7V0(B)-G
TV02W7V5(B)-G
TV02W8V0(B)-G
TV02W8V5(B)-G
TV02W9V0(B)-G
TV02W100(B)-G
TV02W110(B)-G
TV02W120(B)-G
TV02W130(B)-G
TV02W140(B)-G
TV02W150(B)-G
TV02W160(B)-G
TV02W170(B)-G
TV02W180(B)-G
TV02W190(B)-G
TV02W200(B)-G
TV02W220(B)-G
TV02W240(B)-G
TV02W260(B)-G
TV02W280(B)-G
TV02W300(B)-G
TV02W330(B)-G
TV02W360(B)-G
TV02W400(B)-G
TV02W430(B)-G
TV02W450(B)-G
TV02W480(B)-G
TV02W510(B)-G
TV02W540(B)-G
TV02W580(B)-G
TV02W600(B)-G
TV02W640(B)-G
TV02W700(B)-G
TV02W750(B)-G
TV02W780(B)-G
TV02W800(B)-G
TV02W850(B)-G
TV02W900(B)-G
TV02W101(B)-G
TV02W111(B)-G
TV02W121(B)-G
TV02W131(B)-G
TV02W141(B)-G
TV02W151(B)-G
TV02W161(B)-G
TV02W171(B)-G
TV02W181(B)-G
TV02W191(B)-G
Notes:
1.Suffix B after part number to specify bi-directional devices.
V
C (
M
ax.)
@ IPP
V
RWM
(V)
5.0
6.0
6.5
7.0
7.5
8.0
8.5
9.0
10
11
12
13
14
15
16
17
18
19
20
22
24
26
28
30
33
36
40
43
45
48
51
54
58
60
64
70
75
78
80
85
90
100
110
120
130
140
150
160
170
180
190
V
BR
M
in.
(V)
6.40
6.67
7.22
7.78
8.33
8.89
9.44
10.0
11.1
12.2
13.3
14.4
15.6
16.7
17.8
18.9
20.0
21.1
22.2
24.4
26.7
28.9
31.1
33.3
36.7
40.0
44.4
47.8
50.0
53.3
56.7
60.0
64.4
66.7
71.1
77.8
83.3
86.7
88.8
94.4
100
111
122
133
144
155
167
178
189
200
211
V
BR
M
ax.
(V)
7.00
7.37
7.98
8.60
9.21
9.83
10.4
11.1
12.3
13.5
14.7
15.9
17.2
18.5
19.7
20.9
22.1
23.3
24.5
26.9
29.5
31.9
34.4
36.8
40.6
44.2
49.1
52.8
55.3
58.9
62.7
66.3
71.2
73.7
78.6
86.0
92.1
95.8
97.6
104
111
123
135
147
159
171
185
197
209
220
232
I
T
(mA)
10
10
10
10
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
IPP
@ 10/1000us
I
R
@ V
RWM
(uA)
400
400
250
100
50
25
10
5
2.5
2.5
2.5
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Marking Code
Uni
FE
FG
FK
FM
FP
FR
FT
FV
FX
FZ
HE
HG
HK
HM
HP
HR
HT
HB
HV
HX
HZ
JE
JG
JK
JM
JP
JR
JT
JV
JX
JZ
XE
XG
XK
XM
XP
XR
XT
XB
XV
XX
XZ
TE
TG
TK
TB
TM
TP
TR
TT
TV
(V)
9.20
10.3
11.2
12.0
12.9
13.6
14.4
15.4
17.0
18.2
19.9
21.5
23.2
24.4
26.0
27.6
29.2
30.6
32.4
35.5
38.9
42.1
45.4
48.4
53.3
58.1
64.5
69.4
72.7
77.4
82.4
87.1
93.6
96.8
103
113
121
126
129
137
146
162
177
193
209
224
243
259
275
290
290
(A)
21.7
19.4
17.9
16.7
15.5
14.7
13.9
13.0
11.8
11.0
10.1
9.30
8.62
8.20
7.69
7.25
6.85
6.54
6.17
5.63
5.14
4.75
4.41
4.13
3.75
3.44
3.10
2.88
2.75
2.58
2.43
2.30
2.14
2.07
1.94
1.77
1.65
1.59
1.55
1.46
1.37
1.23
1.13
1.04
0.96
0.89
0.82
0.77
0.73
0.69
0.69
Bi
KE
KG
KK
KM
KP
KR
KT
KV
KX
KZ
LE
JG
LK
LM
LP
LR
LT
LB
LV
LX
LZ
ME
MG
MK
MM
MP
MR
MT
MV
MX
MZ
NE
NG
NK
NM
NP
NR
NT
NB
NV
NX
NZ
PE
PG
PK
PB
PM
PP
PR
PT
PV
REV:B
QW-BTV15
Page 3
Comchip Technology CO., LTD.
