LQG15HZ2N7C02D: DescriptionFixed Inductors; CategoryPassive components inductor; File Size13MB，433 Pages; ManufacturerMurata; Websitehttps://www.murata.com; Environmental Compliance

Download Datasheet Parametric View All

LQG15HZ2N7C02D Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	LQG15HZ2N7C02D	-	-	View	Buy Now

Fixed Inductors

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Murata
package instruction	CHIP, 0402
Reach Compliance Code	compliant
Factory Lead Time	17 weeks 1 day
Samacsys Description	LQG15HZ_02 Series Inductor 2.7nH ±0.2nH 0402 (1005)
DC Resistance	0.12 Ω
Nominal inductance(L)	0.0027 µH
Inductor Applications	RF INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
JESD-609 code	e3
Number of functions	1
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package height	0.5 mm
Package length	1 mm
Package form	SMT
Package width	0.5 mm
Minimum quality factor (at nominal inductance)	8
Maximum rated current	0.8 A
Guideline	AEC-Q200
self resonant frequency	6000 MHz
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
surface mount	YES
Terminal surface	Matte Tin (Sn) - with Nickel (Ni) barrier
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Test frequency	100 MHz
Tolerance	7.407%

O05E.pdf

Apr.28,2017

Chip Inductors (Chip Coils)
