31-8354-6 datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> 31-8354-6

Preview

31-8354-6: DescriptionRF Connectors / Coaxial Connectors TNC TRIAX PLUG POLARIZED; CategoryThe connector; File Size60KB，1 Pages; ManufacturerAmphenol; Websitehttp://www.amphenol.com/

Download Datasheet Parametric Compare View All

31-8354-6 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	31-8354-6	-	-	View	Buy Now

31-8354-6 Overview

RF Connectors / Coaxial Connectors TNC TRIAX PLUG POLARIZED

31-8354-6 Parametric

Parameter Name	Attribute value
Product Attribute	Attribute Value
Manufacturer	Amphenol
Product Category	RF Connectors / Coaxial Connectors
RoHS	Details
Product	Connectors
RF Series	TNC
Gender	Plug
Impedance	50 Ohms
Maximum Frequency	11 GHz
Contact Plating	Gold
Body Finish	Nickel
Factory Pack Quantity	1

Preview

Download Datasheet

View All

Triax

TNC Threaded, 7/16-28

Fig. 1

Fig. 2

Amphenol

®

T

.505(12.8) dia.

.473(12.9)

Plug

31-8357-3

31-8357-6

Fig. 3

Bulkhead Jack Receptacle

31-8359-1

T

.505(12.8) dia.

.473(12.9)

Bulkhead Adapter Jack to Jack

31-8356-2

Triax

PLUGS - MALE CONTACTS

Triax

Cable

Raychem

9530-D-5117

Times

TBF-58

Config.

Plug

a

b

Dims. Inches (mm)

c

e

.177 (4.5)

.257 (6.5)

—

f

—

MTG

Hole

—

CAI

C13

PLT

P15

P33

Ins.

D1

Amphenol

Number

31-8357-3

31-8357-6

Fig

1

1.43 (36.3) .625 (15.9)

RECEPTACLES - FEMALE CONTACTS

Description

Bulkhead

Jack Receptacle

Config.

Recep.

a

b

Dims. Inches (mm)

c

e

.825 (21.0)

.250 (6.4)

f

—

MTG

Hole

T

CAI

—

PLT

P33

Ins.

D1

Amphenol

Number

31-8359-1

Fig

2

1.20 (30.5) .690 (17.5)

ADAPTER

Description

Bulkhead

Jack to Jack

G

Config.

a

Dims. Inches (mm)

b

c

e

.638 (16.2)

.187 (4.7)

f

.737 (1.87)

MTG

Hole

T

CAI

—

PLT

—

Ins.

—

Amphenol

Number

31-8356-2

Fig

3

Adapter 1.37 (34.8) .730 (18.5)

accommodates cable diameter

Amphenol Corporation Tel: 800-627-7100

www.amphenolrf.com

183

31-8354-6 Related Products

	31-8354-6	31-34156-1	31-4674	031-8354-6	031-8356-2	031-8354-12
Description	RF Connectors / Coaxial Connectors TNC TRIAX PLUG POLARIZED	RF Connectors / Coaxial Connectors TNC TRIAX	RF Connectors / Coaxial Connectors TNC(M) MIL CR GEN DYN C8811-1	RF Connectors / Coaxial Connectors TNC TRIAX PLUG POLARIZED	RF Adapters - In Series TNC TRIAX ADAPTER	RF Connectors / Coaxial Connectors TNC TRIAX ASSY
Product Attribute	Attribute Value	Attribute Value	Attribute Value	Attribute Value	Attribute Value	Attribute Value
Manufacturer	Amphenol	Amphenol	Amphenol	Amphenol	Amphenol	Amphenol
Product Category	RF Connectors / Coaxial Connectors	RF Connectors / Coaxial Connectors	RF Connectors / Coaxial Connectors	RF Connectors / Coaxial Connectors	RF Adapters - In Series	RF Connectors / Coaxial Connectors
RF Series	TNC	TNC	TNC	TNC	TNC	TNC
Impedance	50 Ohms	50 Ohms	50 Ohms	50 Ohms	50 Ohms	50 Ohms
Maximum Frequency	11 GHz	11 GHz	11 GHz	11 GHz	500 MHz	11 GHz
Contact Plating	Gold	Gold	Gold	Gold	Gold	Gold
Factory Pack Quantity	1	1	1	1	1	1
RoHS	Details	Details	-	Details	Details	Details
Product	Connectors	Connectors	Connectors	Connectors	-	Connectors
Gender	Plug	Plug	Plug	Plug	-	-
Body Finish	Nickel	Nickel	Silver	Nickel	-	Nickel
