General IllumInatIon
luXeon r
High flux for outdoor applications
LUXEON R brings illumination grade LED light sources to outdoor
and industrial lighting applications and makes it easier than ever to
design LED solutions and bring them to market. With hot testing, every
LUXEON R is tested and specified at real world operating conditions —
85°C.
Freedom from Binning
means that every LUXEON R LED falls within
a single 5-step MacAdam ellipse centered in ANSI defined standard color
spaces and now, luminaire manufacturers can be confident in color
consistency from LED to LED. The superior quality of light, volume
of lumens, and real world efficacy enable leading performance and
efficient solution development in a wide variety of high bay, low bay
and outdoor applications.
Features and BeneFIts
5-step MacAdam color definition:
Freedom from Binning
Identical footprint to LUXEON Rebel family and ecosystem for compatibility
with existing designs
Hot tested at real world conditions which leads to better color accuracy
70CRI minimum and a full range of CCTs
PrImary aPPlIcatIons
High Bay & Low Bay
Outdoor
COMPLIANT
RoHS
DS101 LUXEON R Product Datasheet ©2015 Lumileds Holding B.V. All rights reserved.
Table of Contents
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Lumen Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Environmental Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Optical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
JEDEC Moisture Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Reflow Soldering Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Mechanical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Pad Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Solder Pad Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Typical Light Output Characteristics over Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Typical Forward Current Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Current Derating Curves. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Typical Radiation Patterns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Emitter Pocket Tape Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Emitter Reel Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Product Binning and Labeling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Luminous Flux Bins. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
LUXEON R 5-step MacAdam Ellipse Color Definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Forward Voltage Bins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
DS101 LUXEON R Product Datasheet 20140709 ©2015 Lumileds Holding B.V. All rights reserved.
i
General Information
Product Nomenclature
LUXEON R emitters are tested and binned “hot” under conditions comparable to those found in “real-world” lighting
products. The test conditions for LUXEON R are 700mA D.C. with junction temperature at 85°C.
The part number designation for the LUXEON R emitters is explained as follows:
LXA7-PWxx
Where:
7
—
P
W
xx
—
—
—
designates minimum CRI performance (value 7 = 70 minimum)
designates radiation pattern (value P for Lambertian)
designates color (value W = White)
designates nominal ANSI CCT (value 30 = 3000K, 40 = 4000K, 50 = 5000K, 57 = 5700K, and 65 =
6500K)
Lumen Maintenance
LUXEON R products are tested in compliance with LM-80. Please visit
www.lumileds.com
or contact your local
Lumileds Technical Solutions Manager for TM-21 extrapolations or other support.
Environmental Compliance
Lumileds is committed to providing environmentally friendly products to the solid-state lighting market. LUXEON R
is compliant to the European Union directives on the restriction of hazardous substances in electronic equipment,
namely the RoHS and REACH directives. Lumileds will not intentionally add the following restricted materials to the
LUXEON R: lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls (PBB) or polybrominated
diphenyl ethers (PBDE).
DS101 LUXEON R Product Datasheet 20140709 ©2015 Lumileds Holding B.V. All rights reserved.
2
Product Selection
Product Selection Guide for LUXEON R Emitters
Junction Temperature = 85°C
Table 1.
Typical Performance Characteristics at 350mA, 700mA, and 1000mA for LUXEON R, Junction Temperature = 85°C
Nominal
ANSI CCT
3000K
4000K
5000K
5700K
6500K
CRI @ 700mA
Min.
70
70
70
70
70
Typ.
75
75
75
75
75
Luminous Flux (lm) Typical Luminous Flux
Min
(lm)
700mA
160
200
200
200
200
350
mA
100
119
122
122
122
700
mA
180
215
220
220
220
1000
mA
245
292
299
299
299
Typical Forward
Voltage (V
f
)
350
mA
2.72
2.72
2.72
2.72
2.72
700
mA
2.81
2.81
2.81
2.81
2.81
1000
mA
2.85
2.85
2.85
2.85
2.85
Typical Efficacy
(lm/W)
350
mA
105
125
128
128
128
700
mA
92
109
112
112
112
1000
mA
86
103
105
105
105
Part Number
LXA7-PW30
LXA7-PW40
LXA7-PW50
LXA7-PW57
LXA7-PW65
Notes for Table 1:
1. Minimum luminous flux performance within published operating conditions. Lumileds maintains a tolerance of ± 6.5% on luminous flux measurements.
2. Lumileds maintains a tolerance of ± 0.06V on forward voltage measurements.
Optical Characteristics
LUXEON R at Test Current
[1]
Junction Temperature = 85°C
Table 2.
Nominal
ANSI CCT
3000K
4000K
5000K
5700K
6500K
Part
Number
LXA7-PW30
LXA7-PW40
LXA7-PW50
LXA7-PW57
LXA7-PW65
Typical
Color Temperature
CCT
3045K
3985K
5028K
5665K
6530K
160
120
Typical Total Included
Angle
[2]
(degrees)
u
0.90V
Typical Viewing Angle
[3]
(degrees)
2u 1/2
Notes for Table 2:
1. Test current is 700mA D.C. for all LXA7-PWxx emitters.
2. Total angle at which 90% of total luminous flux is captured.
3. Viewing angle is the off axis angle from lamp centerline where the luminous intensity is 1/2 of the peak value.
DS101 LUXEON R Product Datasheet 20140709 ©2015 Lumileds Holding B.V. All rights reserved.
3
Electrical Characteristics
Electrical Characteristics at 700mA for LUXEON R
Junction Temperature = 85°C
Table 3.
Forward Voltage V
f
(V)
[1]
Nominal
ANSI CCT
Minimum
2.5
2.5
2.5
2.5
2.5
Maximum
3.25
3.25
3.25
3.25
3.25
Typical Temperature
Coefficient
of Forward Voltage
[2]
(mV/°C)
DV
F
/
DT
J
-1.8 to -2.4
-1.8 to -2.4
-1.8 to -2.4
-1.8 to -2.4
-1.8 to -2.4
Typical Thermal
Resistance
Junction to Thermal Pad
(°C/W)
Ru
J-C
6
6
6
6
6
3000K
4000K
5000K
5700K
6500K
Notes for Table 3:
1. Lumileds maintains a tolerance of ± 0.06V on forward voltage measurements.
2. Measured between T
J
= 25°C and T
J
= 110°C at I
f
= 700mA.
Absolute Maximum Ratings
Table 4.
Parameter
DC Forward Current (mA)
Peak Pulsed Forward Current (mA)
ESD Sensitivity
LED Junction Temperature
[1]
Operating Case Temperature at 700mA
Storage Temperature
Soldering Temperature
Allowable Reflow Cycles
Reverse Voltage (Vr)
LUXEON R
1000
[2]
1200
[3]
< 8000V Human Body Model (HBM) Class 3A JESD22-A114-E
150°C
-40°C - 135°C
-40°C - 135°C
JEDEC 020c 260°C
3
LUXEON R LEDs are not designed to be driven in reverse bias
Notes for Table 4:
1. Proper current derating must be observed to maintain junction temperature below the maximum. For additional information on thermal measurement guidelines please refer to Application
Brief AB33.
2. Residual periodic variations due to power conversion from alternating current (AC) to direct current (DC), also called “ripple’, with frequencies
≥
100 Hz and amplitude
≤
200mA are acceptable,
assuming the average current throughout each cycle does not exceed 1000mA.
3. Pulsed operation with a peak drive current of 1200mA is acceptable if the pulse on-time is
≤
5 ms per cycle and the duty cycle is
≤
50%.
JEDEC Moisture Sensitivity
Table 5.
Level
Time
1
unlimited
Floor Life
Conditions
≤
30°C /
85% RH
Time
168h
+5/-0
Soak Requirements
Standard
Conditions
85°C / 85%
RH
DS101 LUXEON R Product Datasheet 20140709 ©2015 Lumileds Holding B.V. All rights reserved.
4
