XF2L
For FPC
ZIF Slide-locking Connector (0.5-mm Pitch)
Greater Freedom in Board Design with a Bottom Wall and the
Smallest On-board Area in the Industry
•
Smallest on-board area and volume in the industry.
•
Low on-board height of only 1.2 mm.
•
Highest board design surface efficiency in the industry with a bottom
wall preventing terminal exposure.
•
Construction with secure slider locking mechanism.
•
Applicable FPC thickness of 0.3 mm (Gold-plated type).
•
Halogen Free (*)
* OMRON uses the following standard to determine halogen-free construction: 900 ppm
max. for Br, 900 ppm max. for Cl, and 1,500 ppm max. for Br+Cl.
RoHS compliant
■
Ratings and Specifications
Rated current
Rated voltage
Contact resistance
Insulation resistance
Dielectric strength
Insertion durability
Ambient operating temperature
0.5 A AC/DC
50 V AC/DC
30 mΩ max. (at 20 mV DC max., 100 mA max.)
100 MΩ min. (at 250 V DC)
250 V AC for 1 min. (leakage current: 1 mA max.)
20 times
−30
to 85
°C
(With no icing or condensation)
■
Materials and Finish
Model XF2L (Upper-sided Models) XF2L (Lower-sided Models)
Item
Housing
LCP resin (UL94 V-0)/natural
Slider
LCP resin (UL94 V-0)/black
LCP resin (UL94 V-0)/brown
Spring copper alloy/nickel substrate (2
μm)
Contacts
Gold-plated contacts (0.15
μm)
Hold-down
Copper alloy/tin-plated (1.5
μm)
(Unit: mm)
■
Dimensions
XF2L-@@@5-1A
F
E
B
A
Table of Dimensions
Upper
sided
Pins
*1
4
6
7
8
9
10
12
13
18
1.35 (Effective
21
stacking length)
26
30
1.2
Model
A
B
C
XF2L-0425-1A
1.5 5.9 6.9
XF2L-0625-1A
2.5 6.9 7.9
XF2L-0725-1A
3.0 7.4 8.4
XF2L-0825-1A
3.5 7.9 8.9
XF2L-0925-1A
4.0 8.4 9.4
XF2L-1025-1A
4.5 8.9 9.9
XF2L-1225-1A
5.5 9.9 10.9
XF2L-1325-1A
6.0 10.4 11.4
XF2L-1825-1A
8.5 12.9 13.9
XF2L-2125-1A
10.0 14.4 15.4
XF2L-2625-1A
12.5 16.9 17.9
XF2L-3025-1A
14.5 18.9 19.9
D
2.6
3.6
4.1
4.6
5.1
5.6
6.6
7.1
9.6
11.1
13.6
15.6
D
3.1
3.6
4.1
4.6
5.6
6.6
7.1
8.1
9.6
10.1
10.6
11.6
12.6
15.6
E
5.88
6.88
7.38
7.88
8.38
8.88
9.88
10.38
12.88
14.38
16.88
18.88
E
6.38
6.88
7.38
7.88
8.88
9.88
10.38
11.38
12.88
13.38
13.88
14.88
15.88
18.88
F
6.88
7.88
8.38
8.88
9.38
9.88
10.88
11.38
13.88
15.38
17.88
19.88
F
7.38
7.88
8.38
8.88
9.88
10.88
11.38
12.38
13.88
14.38
14.88
15.88
16.88
19.88
G
5.28
6.28
6.78
7.28
7.78
8.28
9.28
9.78
12.28
13.78
16.28
18.28
G
5.78
6.28
6.78
7.28
8.28
9.28
9.78
10.78
12.28
12.78
13.28
14.28
15.28
18.28
H
7.28
8.28
8.78
9.28
9.78
10.28
11.28
11.78
14.28
15.78
18.28
20.28
H
7.78
8.28
8.78
9.28
10.28
11.28
11.78
12.78
14.28
14.78
15.28
16.28
17.28
20.28
Terminal
No.1
0.5
0.2
1
1
Reference
pin mark
C
XF2L-@@25-1A (Upper-sided Models)
D
FPC insertion dimension X
1.2
X
3.45
With slider open
2.3
3.05
4.55
XF2L-@@35-1A (Lower-sided Models)
D
FPC insertion dimension Y
1.2
Y
PCB Dimensions (TOP VIEW)
F
E
0.55
±0.1
1
±0.1
1.34
±0.1
A
±0.05
0.5
±0.05
0.25
+0.05
0
(0.3)
Lower sided
0.45
Model
A
B
C
Cross-section diagram: X-X
Pins
*1
5
XF2L-0535-1A
2.0 6.4 7.4
1.35 (Effective
2.3
6
XF2L-0635-1A
2.5 6.9 7.9
3.05
stacking length)
7
XF2L-0735-1A
3.0 7.4 8.4
4.55
8
XF2L-0835-1A
3.5 7.9 8.9
1.2
10
XF2L-1035-1A
4.5 8.9 9.9
0.45
12
XF2L-1235-1A
5.5 9.9 10.9
3.45
With slider open
Cross-section diagram: Y-Y
13
XF2L-1335-1A
6.0 10.4 11.4
Recommended FPC Dimensions
15
XF2L-1535-1A
7.0 11.4 12.4
(D - 0.1)
± 0.05
18
XF2L-1835-1A
8.5 12.9 13.9
A
± 0.05
0.5
± 0.1
19
XF2L-1935-1A
9.0 13.4 14.4
0.5
± 0.05
20
XF2L-2035-1A
9.5 13.9 14.9
0.35
± 0.03
22
XF2L-2235-1A
10.5 14.9 15.9
(1.35)
24
XF2L-2435-1A
11.5 15.9 16.9
Effective stacking length
2.5 MIN.
30
XF2L-3035-1A
14.5 18.9 19.9
(5)
Reinforcement
board
*
G
±0.1
H
±0.1
*
Use polyimide and thermoset adhesive for reinforcement film material.
T = 0.3
± 0.03
(Conductive plating)
■
Ordering Information
Pins
*1
4
5
6
7
8
9
*1.
*2.
List of Models
Upper sided
Lower sided
Upper sided
Lower sided
Upper sided
Lower sided
Upper sided
Lower sided
Upper sided
Model
XF2L-0425-1A
XF2L-0535-1A
XF2L-0625-1A
XF2L-0635-1A
XF2L-0725-1A
XF2L-0735-1A
XF2L-0825-1A
XF2L-0835-1A
XF2L-0925-1A
Pins
*1
10
12
13
15
18
List of Models
Upper sided
Lower sided
Upper sided
Lower sided
Upper sided
Lower sided
Lower sided
Upper sided
Lower sided
Model
XF2L-1025-1A
XF2L-1035-1A
XF2L-1225-1A
XF2L-1235-1A
XF2L-1325-1A
XF2L-1335-1A
XF2L-1535-1A
XF2L-1825-1A
XF2L-1835-1A
Pins
*1
19
20
21
22
24
26
30
-
List of Models
Lower sided
Lower sided
Upper sided
Lower sided
Lower sided
Upper sided
Upper sided
Lower sided
-
Model
XF2L-1935-1A
XF2L-2035-1A
XF2L-2125-1A
XF2L-2235-1A
XF2L-2435-1A
XF2L-2625-1A
XF2L-3025-1A
XF2L-3035-1A
-
Quantity per reel (unit)
*2
3,000
Please consult your OMRON representative for available pin count.
Please order by integer multiple of the quantity per reel.
17
XF2L
