DJ06S/D Series
6W DC/DC CONVERTER, DIP-Package, High Isolation
FEATURES
Efficiency up to 84%
DIP Package with Industry Standard Pinout
4:1 Wide Input Range
Operating Temperature Range -40°C to +85°C
Isolation
Voltage 1500VDC /3000VDC(Optional)
Short Circuit Protection
Overload Protection
Complies with EN 55022 Class A
Lead free, RoHs Compliant
3 Years Product Warranty
The DJ06S/D series is miniature, DIP Package, isolated 6W DC/DC converters with 1,500VDC/3000VDC isolation. It offers
short circuit protection and allows a wide operating temperature range of –40°C to +85°C. These isolated DC/DC converters are the
latest offering from a world leader in power systems technology and manufacturing
―
Delta Electronics, Inc. With creative design
technology and optimization of component placement, these converters possess outstanding electrical and thermal performance, as
well as extremely high reliability under highly stressful operating conditions.
Model List
Model
Number
Input
Voltage
(Range)
VDC
DJ06S2403A
DJ06S2405A
DJ06S2412A
DJ06S2415A
DJ06S2424A
DJ06D2405A
DJ06D2412A
DJ06D2415A
DJ06S4803A
DJ06S4805A
DJ06S4812A
DJ06S4815A
DJ06S4824A
DJ06D4805A
DJ06D4812A
DJ06D4815A
Output
Voltage
VDC
3.3
5
12
15
24
±5
±12
±15
3.3
5
12
15
24
±5
±12
±15
Output
Current
Max.
mA
1200
1200
500
400
250
±500
±250
±200
1200
1200
500
400
250
±500
±250
±200
Input Current
@Max. Load
mA(typ.)
214
313
298
298
298
260
298
298
107
156
149
149
149
130
149
149
@No Load
mA(typ.)
Reflected
Ripple
Current
mA(typ.)
Max. capacitive
Load
uF
470
470
100
100
47
100*
100*
100*
470
470
100
100
47
100*
100*
100*
Efficiency
(typ.)
@Max. Load
%
77
80
84
84
84
80
84
84
77
80
84
84
84
80
84
84
* For each output
24
(9 ~ 36)
20
20
48
(18 ~ 75)
10
15
DS_DJ06S/D_07162012
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P1
Input Characteristics
Parameter
Input Surge Voltage (1 sec. max.)
Start-Up Voltage
Under Voltage Shutdown
Short Circuit Input Power
Internal Power Dissipation
Conducted EMI
All Models
Model
24V Input Models
48V Input Models
24V Input Models
48V Input Models
24V Input Models
48V Input Models
Min.
-0.7
-0.7
7
14
---
---
---
---
Typ.
---
---
8
16
---
---
---
---
Max.
50
100
9
18
8.5
16
3000
2500
mW
mW
VDC
Unit
Compliance to EN 55022,class A and FCC part 15,class A
Output Characteristics
Parameter
Output Voltage Accuracy
Output Voltage Balance
Line Regulation
Load Regulation
Min.Load
Ripple & Noise (20MHz)
Ripple & Noise (20MHz)
Transient Recovery Time
Transient Response Deviation
Temperature Coefficient
Over Load Protection
Short Circuit Protection
Foldback
Over Line, Load & Temp.
25% Load Step Change
Dual Output, Balanced Loads
Vin=Min. to Max.
Io=0% to 100%
Conditions
Min.
---
---
---
---
---
---
---
---
---
110
Continuous
Typ.
±1.0
±1.0
±0.1
±0.6
50
---
300
±3
±0.01
150
Max.
±2.0
±2.0
±0.5
±1.2
80
100
600
---
±0.02
---
Unit
%
%
%
%
mV
P-P
mV
P-P
uS
%
%/℃
%
No minimum Load Requirement
General Characteristics
Parameter
I/O Isolation Voltage (rated)
I/O Isolation Resistance
I/O Isolation Capacitance
Switching Frequency
MTBF (calculated)
Safety Approvals(pending)
MIL-HDBK-217F@25℃, Ground Benign
Conditions
60 Seconds
500 VDC
100KHz, 1V
Standard
Suffix H (note 5)
Min.
1500
3000
1000
---
---
800,000
Typ.
---
---
---
1000
330
---
Max.
---
---
---
---
---
---
Unit
VDC
VDC
MΩ
pF
KHz
Hours
UL/cUL 60950-1 recognition(CSA certificate), IEC/EN 60950-1(CB-scheme)
Recommended Input Fuse
24V Input Models
1500mA Slow-Blow Type
48V Input Models
800mA Slow-Blow Type
Environmental Characteristics
Parameter
Operating Temperature Range
(with Derating)
Case Temperature
Storage Temperature Range
Humidity (non condensing)
Cooling
Lead Temperature
(1.5mm from case for 10Sec.)
Conditions
Ambient
Min.
-40
---
-50
---
Free-Air convection
---
260
℃
Max.
+85
+100
+125
95
Unit
℃
℃
℃
% rel. H
DS_DJ06S/D_07162012
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P2
Power Derating Curve
Output Power (%)
(3.3 & 5V Output Models)
Output Power (%)
(Other Output Models)
Notes
1
2
3
4
5
6
Specifications typical at Ta=+25℃, resistive load, nominal input voltage and rated output current unless otherwise noted.
Transient recovery time is measured to within 1% error band for a step change in output load of 75% to 100%
Ripple & Noise measurement bandwidth is 0-20MHz.
All DC/DC converters should be externally fused at the front end for protection.
To order the converter at 3KVDC isolation, please add a suffix H (e.g. DJ06S2403H) to order code.
Specifications subject to change without notice.
Mechancial Drawing
Mechanical Dimensions
Pin Connections
Pin
2
10.2
[0.40]
Single Output
-Vin
-Vin
No Pin
NC
+Vout
-Vout
+Vin
+Vin
Dual Output
-Vin
-Vin
Common
-Vout
+Vout
Common
+Vin
+Vin
3
9
11
14
16
22
23
0.50 [0.02]
4.1
[0.16]
15.22 [0.60]
2
3
9
11
NC: No Connection
20.3 [0.80]
Bottom View
23 22
16
14
►All
dimensions in mm (inches)
►Tolerance:
X.X±0.25 (X.XX±0.01)
X.XX±0.13 ( X.XXX±0.005)
►Pin
diameter
⇔
0.5 ±0.05 (0.02±0.002)
2.54
[0.10]
15.24 [0.60]
31.8 [1.25]
5.08 4.5
[0.20][0.18]
Physical Outline
Case Size
Case Material
Weight
:
:
:
31.8x20.3x10.2mm (1.25x0.80x0.40 Inches)
Non-Conductive Black Plastic (flammability to UL 94V-0 rated)
12.7g
2.54
[0.10]
DS_DJ06S/D_07162012
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P3
Part Numbering System
D
Form factor
D-DIP
P-SIP
S-SMD
J
Family series
A~Z
06
Watt
01:1W
02:2W
03:3W
04:4W
06:6W
S
Number of
Outputs
S - Single
D- Dual
24
Input Voltage
03:3.3V
05: 5V
12:12V
24: 24V
48:48V
05
Output Voltage
03:3.3V
05: 5V
12:12V
15: 15V
24: 24V
A
Option Code
A - Std. Functions
H- High isolation
WARRANTY
Delta offers a three(3) years limited warranty. Complete warranty information is listed on our web site or is available upon request from Delta.
Information furnished by Delta is believed to be accurate and reliable. However, no responsibility is assumed by Delta for its use, nor for any
infringements of patents or other rights of third parties, which may result from its use. No license is granted by implication or otherwise under
any patent or patent rights of Delta. Delta reserves the right to revise these specifications at any time, without notice.
DS_DJ06S/D_07162012
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P4
