65W Triple Output Medical Type
■
Features :
Universal AC input / Full range
Low leakage current <250
μ
A
M P T- 6 5
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
series
Medical safety approved (2 x MOPP between primary to secondary)
100% full load burn-in test
Fixed switching frequency at 45KHz
3 years warranty
EN 60601-1
IEC 60601-1
SPECIFICATION
MODEL
OUTPUT NUMBER
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
RATED POWER
OUTPUT POWER (max.)
OUTPUT
VOLTAGE ADJ. RANGE
LINE REGULATION
LOAD REGULATION
SETUP, RISE TIME
HOLD UP TIME (Typ.)
VOLTAGE RANGE
FREQUENCY RANGE
INPUT
EFFICIENCY(Typ.)
AC CURRENT (Typ.)
INRUSH CURRENT (Typ.)
LEAKAGE CURRENT
OVERLOAD
PROTECTION
OVER VOLTAGE
WORKING TEMP.
WORKING HUMIDITY
ENVIRONMENT STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
SAFETY STANDARDS
SAFETY & ISOLATION LEVEL
WITHSTAND VOLTAGE
EMC
(Note 4)
ISOLATION RESISTANCE
EMC EMISSION
EMC IMMUNITY
MTBF
OTHERS
NOTE
8
MPT-65A
CH1
5V
5.5A
0.4 ~ 7A
60W
120mVp-p
+10,-7%
±2.0%
±4.0%
60mVp-p
±5.0%
±1.0%
±1.0%
CH2
12V
2.5A
0.2 ~ 3.2A
CH3
-5V
0.5A
0 ~ 0.7A
MPT-65B
CH1
5V
5.5A
0.4 ~ 7A
63.5W
60mVp-p
±4.0%
±1.0%
±3.0%
160mVp-p
+10,-7%
±2.0%
±4.0%
100mVp-p
±5.0%
±1.0%
±1.0%
CH2
12V
2.5A
0.2 ~ 3.2A
CH3
-12V
0.5A
0 ~ 0.7A
MPT-65C
CH1
5V
5.5A
0.4 ~ 7A
65W
60mVp-p
±4.0%
±1.0%
±3.0%
180mVp-p
+10,-7%
±2.0%
±4.0%
100mVp-p
±5.0%
±1.0%
±1.0%
CH2
15V
2A
0.2 ~ 2.6A
CH3
-15V
0.5A
0 ~ 0.7A
72W with 18CFM min. Forced air convection
CH1:4.5 ~ 5.5V
±1.0%
±3.0%
80ms/230VAC
90 ~ 264VAC
47 ~ 440Hz
74%
1.6A/115VAC
1A/230VAC
74%
74%
RIPPLE & NOISE (max.)
Note.2
60mVp-p
VOLTAGE TOLERANCE
Note.3
±4.0%
800ms, 20ms/230VAC
800ms, 20ms/115VAC at full load
12ms/115VAC at full load
127 ~ 370VDC
COLD START 20A/115VAC
40A/230VAC
μ
A/264VAC , Touch current < 60
μ
A/264VAC
Note.7
Earth leakage current < 250
73 ~ 95W
rated output power
Protection type : Hiccup mode, recovers automatically after fault condition is removed
5.75 ~ 6.75VDC on CH1
Protection type : Hiccup mode, recovers automatically after fault condition is removed
-10 ~ +55
℃
(Refer to "Derating Curve")
20 ~ 90% RH non-condensing
-20 ~ +85
℃
, 10 ~ 95% RH
±
0.04%/
℃
(0 ~ 50
℃
) on +5V output
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
ANSI/AAMI ES60601-1, TUV EN60601-1, IEC60601-1 approved
Primary-Secondary: 2xMOPP, Primary-Earth:1xMOPP
I/P-O/P:4KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC 1min.
I/P-O/P, I/P-FG:100M Ohms / 500VDC / 25
℃
/ 70% RH
Compliance to EN55011 (CISPR11) Class B, EN61000-3-2,-3
Compliance to EN61000-4-2,3,4,5,6,8,11, EN60601-1-2, medical level, criteria A
275.1Khrs min. MIL-HDBK-217F (25
℃
)
127*76*42mm (L*W*H)
0.27Kg; 54pcs/16.8Kg/1.35CUFT
DIMENSION
PACKING
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25
℃
of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. The power supply is considered a component which will be installed into a final equipment. All the EMC tests are been executed by mounting the unit on
a 360mm*360mm metal plate with 1mm of thickness. The final equipment must be re-confirmed that it still meets EMC directives. For guidance on how to
perform these EMC tests, please refer to EMI testing of component power supplies. (as available on http://www.meanwell.com)
5. Mounting holes M1 and M2 should be grounded for EMI purposes.
6. Heat Sink HS1,HS2 can not be shorted.
7.
Touch current was measured from primary input to DC output
.
File Name:MPT-65-SPEC 2015-08-06
