5082-3340
MICROSTRIP/STRIPLINE PIN DIODE SWITCH
DESCRIPTION:
The
ASI 5082-3340
is a Silicon PIN
Diode Module Designed for Reflective
Attenuator and Switching Applications
from 1 to 18 GHz.
PACKAGE STYLE M-50
FEATURES INCLUDE:
•
Direct Replacement for
HP 5082-3340
•
Isolation = 20 dB min. at 10 GHz
•
Hermetic Package
MAXIMUM RATINGS
I
F
V
R
P
DISS
T
J
T
STG
θ
JC
250 mA
150 V
2.5 W @ T
C
= 25
O
C
-65
O
C to +150
O
C
-65
O
C to +150
O
C
50
O
C/W
T
C
= 25
O
C
Cathode
ORDER CODE: ASI30254
CHARACTERISTICS
SYMBOL
V
BR
V
F
τ
I
L
I
L
V
SWR
I
R
= 10
µA
I
F
= 100 mA
I
F
= 50 mA
I
F
= 0 mA
TEST CONDITIONS
MINIMUM
150
TYPICAL
MAXIMUM
1.0
UNITS
V
V
µ
S
I
R
= 250 mA
P
IN
= 0 dBm
P
IN
= 0 dBm
P
IN
= 0 dBm
f = 10 GHz
f = 10 GHz
f = 10 GHz
20
400
0.5
dB
dB
I
F
= 100 mA
I
F
= 0 mA
1.5:1
---
NOTE:
The
ASI 5082-3340
was designed to be a single piece hermetic replacement for the
HP 5082-3340
diode. It features an
internal low pass filter structure with a corner frequency of 20 GHz which yields insertion loss and isolation performance equivalent
to the original HP device while maintaining mechanical compatible in most applications.
A D V A N C E D S E M I C O N D U C T O R, I N C.
7525 ETHEL AVENUE
•
NORTH HOLLYWOOD, CA 91605
•
(818) 982-1202
•
FAX (818) 765-3004
Specifications are subject to change without
REV. A
1/1
