ABOUT OUR COMPANY
Amphenol is the world’s leading interconnect technology company with more
than 80 business units around the globe. Amphenol Alden, an operating unit of
Amphenol, was founded in 1929 as Alden Products Company and has a strong
legacy in High Voltage products and services. With factories in China, Mexico,
and in our Massachusetts headquarters location, Amphenol Alden meets the
varying demands of its worldwide customers.
This catalog showcases the Amphenol Alden line of standard high voltage
connectors that helped shape the high voltage interconnect industry. In addition
to these standard products, our experienced high voltage design engineers
collaborate with customers to develop custom solutions and engineered cable
assemblies that solve the most demanding high voltage challenges. Throughout
our 70 years of high voltage leadership we have served a diverse range of
customers in the complex and competitive medical, industrial and military markets
and have developed industry standard connectors for X-Ray, ESD, HeNe lasers
and more.
At Amphenol Alden, a spirit of collaboration extends from the design process
through to final delivery. Utilizing dedicated internal quality and supply chain
management teams, Amphenol Alden provides unsurpassed service before,
during, and after the sale. This collaborative structure ensures Amphenol Alden
is a true partner in solving your most difficult product challenges, whether using
standard products or fully customized solutions.
MARKETS SERVED
Imaging
Medical X-ray
Security Detection
CT Scanners
Industrial
Laser
HV Test Equipment
ESD simulators
Military/Aerospace
Missile Ignition
HUD’s
Navigation
TABLE OF CONTENTS
Table of content
A Series
.....................................................................................
2
Single Pole up to 25 kVDC
B Series
.....................................................................................
6
Single Pole locking up to 40 kVDC
D Series
.....................................................................................
8
Two Pole up to 15 kVDC
E Series
.....................................................................................
10
Two and Three Pole latching up to 15 kVDC
F Series
.....................................................................................
12
Single Pole up to 35 kVDC
G Series
.....................................................................................
16
Miniature Single and Dual Pole up to 20 kVDC
H Series
.....................................................................................
18
Multi-Pole Oil-Tight up to 5 kVDC
P Series
.....................................................................................
20
Three Pole up to 75 kVDC
V Series
.....................................................................................
22
Auto-Latching Single and Dual Pole up to 20 kVDC
Ordering Information
..............................................................
24
A-SERIES
The A-Series of high voltage connectors are small, lightweight, and come in a
variety of configurations. This high performing connector series perfectly handles
the varying demands of high voltage test equipment, ionizers, ESD simulators and
many other end uses.
A100QX"L"
Single Circuit In-Line
Receptacle
Up to
15
kVDC
L
A109
Field Installable Single
Circuit In-Line Receptacle
Available in Panel Mount
and Multiple Diameters to
Accommodate Different
Wire Sizes. Consult
Factory for Additional
Details.
Molded in Black
Polybutylene Terephthalate
Up to
20
kVDC
A200QX"L"
90 deg: Single Circuit
Flanged Receptacle
Up to
20
kVDC
A400QX"L"
Single Circuit Panel
Mount Receptacle
Up to
15
kVDC
