AWS5516
GaAs IC
SPDT Reflective Switch DC-2.0 GHz
PRELIMINARY DATA SHEET - Rev 1.2
FEATURES
•
•
•
•
•
•
High Linearity (IP3 48 dBm @ 0.9 GHz)
Low Insertion Loss (0.4 dB @ 0.9 GHz)
2.7 V to 6V Operation
Low DC Power Consumption
Ultra Miniature SOT-26 Package
High Isolation
APPLICATIONS
•
•
•
Transmit/receive switch
Diversity switching
Antenna selection
PRODUCT DESCRIPTION
The AWS5516 is a Single Pole Double Throw (SPDT)
GaAs MMIC switch assembled in a SOT-26 plastic
package. The AWS5516 is designed for applications
that require low insertion loss, high isolation, high
linearity, and small size. The switch can be controlled
with positive, negative, or a combination of both
voltages.
S14
SOT-26
6 Pin Plastic Package
Table 1: Pin Description
Pin
Vs
C
3
RF
o u t 1
(J2)
GND
RF
o u t 2
(J3)
Optional Rs
see Note 3
RF
i n
(J1)
Function
RF
OUT 1
(J2)
GND
RF
OUT 2
(J3)
V2
RF
IN
(J1)/Vs
V1
Description
RF port can be used as an input or as an output.
Ground connection. Keep as short as possible.
RF port can be used as an input or an ouput.
Control Voltage 2, Low 0V , High 3V to 5V
RF common port and bias voltage for positive
control (3V to 5V).
Control Voltage 1, Low 0V , High 3V to 5V
1
2
3
4
5
6
1
2
3
C
2
6
5
V1
C
1
4
V2
Figure 1: Pin Layout
Notes:
1. DC blocking capacitors C1,2,3 and optional resistor Rs must be supplied externally.
2. C1,2,3 = 100 pF for operation >500MHz.
3. The use of resistor Rs to the positive voltage supply is optional. It is only required if it is necessary to
independently control the RF ports, such as selecting both ports to be OFF at the same time.
01-03
AWS5516
ELECTRICAL CHARACTERISTICS
Table 2: Absolute Minimum and Maximum Ratings
PARAMETER
RF Input Power
> 900 MHz, V Control
Control Voltage
Operating Temperature
Storage Temperature
Θ
JC
MIN
-
-0.2
-40°
-65
-
MAX
6
+8
+85
+150
25°
UNIT
W
V
°C
°C
C/W
Stresses in excess of the absolute ratings may cause permanent
damage. Functional operation is not implied under these
conditions. Exposure to absolute ratings for extended periods
of time may adversely affect reliability.
Table 3: Operating Ranges at 25° C
PARAMETER
Switching Characteritics
2
CONDITION
Rise, Fall (10/90% or 90/10% RF)
On, Off (50% CTL to 90/10% RF)
Video Feedthru
2-tone power levels 13dBm to 27dBm
(selected to optimize dynamic range of test)
FREQUENCY
MIN
TYP
100
100
100
MAX
UNIT
nS
nS
mV
Intermodulation Intercept Point (IP3)
V
CTL
= 2.7V
V
CTL
= 5.0V
1.0 GHz
1.8 GHz
1.0 GHz
1.8 GHz
1.0 GHz
1.8 GHz
1.0 GHz
1.8GHz
1 & 1.8 GHz
+45
+42
+55
+52
+48
+46
+61
+56
+28
+27
+37
+37
-75
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBc
6
50
75
V
µA
µA
Input power for 1dB Compression
V
CTL
= 2.7V
V
CTL
= 5.0V
Harmonic Level
Control Voltage (V
CTL
)
3
Leakage Current
Input power = +30 dBm, V
CTL
= 5.0V
Nominal operation voltage
V
CTL
= 2.7V
V
CTL
= 5.0V
2.7
The device may be operated safely over these conditions; however, parametric performance is guaranteed
only over the conditions defined in the electrical specifications.
Notes:
1. All measurements made in a 50 ohm system, unless other specified.
2. Video feedthru measured with 1 ns rise time pulse and 500 MHz bandwidth.
3. VCTL is the absolute value of the differential voltage from V1 to V2. Changing polarity selects the switch path
as defined in the truth table below. Use of the optional resistor Rs on the common port limits VHIGH to Vs ±
0.2V
2
PRELIMINARY DATA SHEET - Rev 1.2
08/2001
AWS5516
Table 4: Electrical Specifications at 25 °C (VCTL = 2.7V)
PARAMETER
1
Insertion Loss
Isolation
VSWR
3
3
FREQUENCY
DC - 1.0 GHz
DC - 2.0 GHz
DC - 1.0 GHz
DC - 2.0 GHz
0.5 - 2.0 GHz
2
MIN
TYP
0.35
0.45
MAX
0.45
0.55
UNIT
dB
dB
25
22
32
24
1.4:1
dB
Notes:
1. All measurements made in a 50
Ω
system, unless other specified.
2. DC= 300 kHz
3. In low insertion loss path.
Table 5: Truth Table
V
1
V
Low
V
High
V
2
V
High
V
Low
J
1
- J
2
Isolation
Low Loss
J
1
- J
3
Low Loss
Isolation
V
CTL
= V
High
– V
Low
= 2.7V to 8V (V
High
= Vs ± 0.2V when Rs used on common port.)
PRELIMINARY DATA SHEET - Rev 1.2
08/2001
3
AWS5516
PERFORMANCE DATA
Figure 2: Insertion Loss vs Frequency
1.0
0.9
30
35
Figure 3: Isolation vs Frequency
0.8
Insertion Loss (dB)
0.7
0.6
0.5
0.4
0.3
0.2
25
Isolation (dB)
20
1
5
1
0
5
0.1
0.0
0.5
1.0
1.5
2.0
2.5
0
0.5
1.0
1.5
2.0
2.5
Frequency (GHz)
Frequency (GHz)
Figure 4: VSWR vs Frequency
Figure 5: TOI vs Control Voltage
1.4
65
60
1.3
1.2
TOI (dBm)
VSWR
55
50
1.0GHz
1.1
45
1.8GHz
1.0
0.5
1.0
1.5
2.0
2.5
40
2.5
3
3.5
4
4.5
5
Frequency (GHz)
Control Voltage (V)
4
PRELIMINARY DATA SHEET - Rev 1.2
08/2001
AWS5516
PACKAGE OUTLINE
θ
SYMBOLS
DIMENSIONS IN MILLIMETERS
DIMENSIONS IN INCHES
A
A1
A2
b
C
D
E
e
H
L
θ1
NOTE
1. PACKAGE BODY SIZES EXCLUDE MOLD FLASH
AND GATE BURRS
2. DIMENSION L IS MEASURED IN GAGE PLANE
3. COPLANARITY : 0.1000 mm
4. TOLERANCE ±0.1000 mm(4 mil) UNLESS
OTHERWISE SPECIFIED
MIN
MAX
1.00
1.30
0.00
0.10
0.70
0.90
0.35
0.50
0.10
0.25
2.70
3.10
1.40
1.80
1.90(TYP)
2.60
3.00
0.37
−−−
1°
9°
MIN
MAX
0.039
0.051
0.00
0.004
0.027
0.035
0.014
0.020
0.004
0.010
0.106
0.122
0.055
0.071
0.075(TYP)
0.102
0.118
0.015
−−−
1°
9°
Figure 6: S14 Package Outline Diagram
PRELIMINARY DATA SHEET - Rev 1.2
08/2001
5
