ITEM #
1
2
3
PART #
AJ-156-11
AJ-166-30
AP-105-5
AP-116-3
AP-136-8
AP-136-6
AP-136-5
SEE TABLE #1
SEE TABLE #1
SEE TABLE #1
AP-116-6
4
QTY
1
1
1
1
1
1
1
1
1
1
1
DESCRIPTION
HOUSING, JACK CABLE
INSERT, 6-COND SOLDER
STRAIN RELIEF
WASHER, RUBBER
NUT ADAPTER WITH GASKET
CLAMP, OUTER SHELL
CLAMP, SHIELD INNER
BUSHING
WASHER
SPRING
STUD
3
B
2
AJ-166S
TABLE #1
PART #
AJ-166S/14-1
AJ-166S/14-2
AJ-166S/14-3
AJ-166S/14-4
AJ-166S/14-5
CABLE
.165 ± .010
.228 ± .010
.250 ± .010
.290 ± .010
.320 ± .010
BUSHING
AP-116-17
AP-116-18
AP-116-8
AP-116-19
AP-116-20
1
WASHER
AP-116-2
AP-116-2
AP-116-2
AP-116-2
AP-116-22
SPRING
AP-116-4
AP-116-4
AP-116-4
AP-116-4
AP-116-21
D
4
5
6
7
8
9
10
11
D
C
NOTES:
1) MARK PART NUMBER & MANUFACTURER'S
NAME, LOCATED APPROX AS SHOWN
3
2
1
4
5
6
C
11
7
8
9
10
SEE NOTE #1
B
Z
3.7
B
THIS DOCUMENT CONTAINS PROPRIETARY INFOR-
Z
.83
SECTION Z-Z
DWN.BY
MATION OF NEXUS,INCORPORATED AND SUCH
INFORMATION MAY NOT BE DISCLOSED TO OTHERS
FOR ANY PURPOSE OR USED FOR ANY PURPOSE
WITHOUT THE WRITTEN CONSENT OF NEXUS.
GPH
DATE
17-May-10
MATERIAL
FINISH
WEIGHT
TITLE
SCALE = 2.00 :1
A
CHECKED BY
DATE
D
C
ADD; AJ-166S/14-5; BILL
OF MATERIAL
213
118
10/8
2014
1/11
2012
5/24
2011
5/19/10
HR
HR
APPR.BY
DATE
ADD; NOTE #1
ADD P/N CHART
INITIAL RELEASE
REVISION
B
106
CN #
HR
GPH
CHK.
A
LET.
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES &/OR [mm]
TOLERANCES:
DECIMAL: .XX[X.X] .XXX[X.XX]
±
.01[0.3] ±
.003[0.08]
FRACTION: X/X
±
1/64
ANGLES: .X
±
.5 °
JACK, 6 PIN, SOLDER CUP
SHIELDED
SHEET 1 OF 1
STAMFORD,CONN
NEXUS
DWG. NO.
A
DATE
DO NOT SCALE DWG.
B
SIZE
AJ-166S
