8STA/8TA Series
Presentation
SOURIAU
is a recognized worldwide market leader
in the design and manufacture of connectors and
interconnect systems for harsh environments.
The relationship between the company and the
motorsport industry goes back many years.
SOURIAU’s
main production facility is located in
Le Mans and since 1990 we supply connectors to
local racing teams for the world famous 24 Hours
Endurance Racing.
The
Motorsport
activity is a market where more
and more electronics are installed and where space
and weight constraints become more critical.
8STA
and
8TA Series
are designed to be smaller and
lighter with high reliability features to protect the
driver and are used across the world of motorsport
on 2 and 4 wheels.
8STA
&
8TA
circular connectors are derived from
international military specifications
MIL-DTL-38999
and
JN1003,
and are designed to withstand high
levels of shock and vibration in harsh environments.
Contents
Overview
Typical applications ..........................................
Features & Benefits ..........................................
8STA/8TA Series product overview .................
Custom solutions .............................................
Contact layouts ................................................
6
7
8
9
10
Blind mating plug .............................................
Hermetic shell size 02 ......................................
Hermetic fuel tank ............................................
Hermetic feed-through .....................................
Fuel immersible ................................................
44
46
48
50
52
Common Section
Contacts ...........................................................
Wiring instructions ............................................
Filler plugs, Tooling ..........................................
Boots, Shrinkable termination detail ................
Metal protective caps .......................................
Nut plates, Gaskets ..........................................
56
57
58
59
60
61
Standard Series
8STA Series shell sizes 02, 04 & 06 ..................
8STA Series shell sizes 08 to 24 .......................
8TA Series compact low profile ........................
8STA Series PC Tail contacts ............................
8STA Series power contacts .............................
8STA Series coax contacts ................................
8STA Series high density #26 contacts .............
16
19
23
26
29
32
34
Range Extension
209 Series .........................................................
High power contacts ........................................
Composite connectors .....................................
micro38999 Series break away .........................
microComp
®
Series ..........................................
8D8/8D Series ..................................................
64
64
65
65
66
66
3
Derived Series
Integrated clinch nuts .......................................
Single hole fixing ..............................................
Quick release for steering boss system ............
38
40
42
