SI3317-H / SI3317-H(B)
IRED
Features
•
•
•
•
Colorless transparency lens type
φ3mm(T-1)
all plastic mold type
Low power consumption
High radiant intensity
Applications
•
Infrared remote control and free air transmission systems with low forward voltage and
comfortable radiation angle requirements in combination with PIN photodiodes or phototransistors.
Outline Dimensions
STRAIGHT TYPE
2.80~3.20
unit :
mm
STOPPER
TYPE : (B)
2.80~3.20
5 . 1 0 ~ 5 . 5 0
2 . 7 0 ~ 3 . 1 0
5 . 1 0 ~ 5 . 5 0
2 . 7 0 ~ 3 . 1 0
1 . 2 0
M i n .
4 . 7 0 ~ 5 . 7 0
0 . 7 0
M a x .
1 . 2 7 T y p .
2 3 . 0 0
M i n .
0 . 7 0
2 3 . 0 0
M a x .
M i n .
1 . 0 0
M i n .
1 . 0 0
M i n .
2 . 5 4 T y p .
2 . 5 4 T y p .
3 . 5 0 ~ 3 . 9 0
M a x .
3 . 5 0 ~ 3 . 9 0
M a x .
1 2
3 . 6 0 ~ 4 . 0 0
1 2
3 . 6 0 ~ 4 . 0 0
PIN Connections
1. Anode
2. Cathode
0 . 4 5
KSD-O2B044-000
0 . 4 5
1
SI3317-H / SI3317-H(B)
Absolute Maximum Ratings
Characteristic
Power dissipation
Forward current
*
1
Peak forward current
Reverse voltage
Operating temperature range
Storage temperature range
(Ta=25
o
C)
Symbol
P
D
I
F
I
FP
V
R
T
opr
T
stg
Rating
150
100
1
4
-25
∼
85
-30
∼
100
Unit
mW
mA
A
V
℃
℃
*
2
Soldering temperature
T
sol
260
℃
for 10 seconds
*1.Duty ratio = 1/16, Pulse width = 0.1ms
*2.Keep the distance more than 2.0mm from PCB to the bottom of IRED package
Electrical / Optical Characteristics
Characteristic
Forward voltage
Radiant intensity
Peak wavelength
Spectrum bandwidth
Reverse current
*
3
Half angle
(Ta=25
o
C)
Symbol
V
F
I
E
Test Condition
I
F
= 50mA
I
F
= 50mA
I
F
= 50mA
I
F
= 50mA
V
R
=4V
I
F
= 50mA
Min.
-
12
-
-
-
-
Typ.
1.3
25
950
50
-
±22
Max.
1.5
-
-
-
10
-
Unit
V
mW/Sr
nm
nm
uA
deg
λ
P
∆
λ
I
R
θ
1
/
2
*3.
θ1/2
is the off-axis angle where the luminous intensity is 1/2 the peak intensity
KSD-O2B044-000
2
SI3317-H / SI3317-H(B)
