8
7
6
5
4
3
2
1
ROHS COMPLIANT
PRODUCT DATA DRAWING
REVISION HISTORY
REV.
DESCRIPTION
DATE
APPROVED
-
NRN 40631
05/16
STW
F
F
2.280
2X .052
ALIGNMENT PINS
.107±.001
RP
.201
.114
.340
E
A
2X .069±.002
.233
8X .039
.119
E
2X 1-64 UNC-2B
THRU
0-80 UNF-2B THRU
.059±.002
1.140
8X
.012±.001
DETAIL A
SCALE 7 : 1
.115
.220
7X .250
.059
D
2.420
.205
D
.008
.394
2X .070
C
B
2X .052
ALIGNMENT
PINS
1.980
DETAIL B
SCALE 7 : 1
8X .051
8X .051
6X .020
C
.220
.070±.002
.150±.001
.060±.002
MATERIAL:
B
BODY &
SHROUDS:
B
STAINLESS STEEL PER AMS-5640,
ALLOY UNS S30300, TYPE 1;
OR ASTM A582 TYPE 303, COND. A
BERYLLIUM COPPER PER ASTM B196,
ALLOY No. UNS C17300, TD04
PTFE PER ASTM D1710, TYPE I, GRADE 1, CLASS B
CONTACTS:
INSULATORS:
FINISH:
MATERIAL:
BODY,
SHROUDS, &
CONTACTS:
A
FINISH:
SEE NOTES
SEE NOTES
GOLD PER ASTM B488, TYPE II,
CODE C, CLASS 0.76, OVER NICKEL
PER AMS-QQ-N-290, CLASS 1, .00010" MIN.
DIMENSIONS ARE IN INCHES
TOLERANCES:
ANGULAR:
1
ONE PLACE DECIMAL
.030
TWO PLACE DECIMAL
.010
THREE PLACE DECIMAL .005
INTERPRET DIMENSIONS AND TOLERANCES
PER ASME Y14.5M - 1994
UNLESS OTHERWISE SPECIFIED:
ALL DIMENSIONS ARE AFTER PLATING.
BREAK CORNERS & EDGES R.005 MAX.
CHAMFER 1ST AND LAST THREAD.
SURFACE ROUGHNESS 63 PER MIL-STD-10.
DIA'S ON COMMON CENTERS TO BE CONCENTRIC
WITHIN .005 T.I.R.
6. REMOVE ALL BURRS.
1.
2.
3.
4.
5.
SV Microwave, Inc.
2400 Centrepark West Drive, Suite 100
West Palm Beach, FL 33409
®
TITLE:
DO NOT SCALE DRAWING
PERFORMANCE:
IMPEDANCE:
FREQ. RANGE:
8
PROPRIETARY
50 OHMS
DC TO 65 GHz.
7
6
THE INFORMATION CONTAINED IN THIS DRAWING
IS THE SOLE PROPERTY OF SV MICROWAVE, INC.
ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
SV MICROWAVE, INC. IS PROHIBITED.
THIRD ANGLE PROJECTION
DRAWN:
CHECKED:
APPROVED:
E.M. SIMULATION:
FED 05/27/16
STW 05/27/16
STW 05/27/16
SMPM FD MALE 8-PORT
EDGE LAUNCH
DWG. NO.
A
SIZE
CAGE CODE
C
2
95077
3211-60181
SHEET 1 OF 2
1
SCALE: 4:1
5
4
3
8
7
6
5
4
3
2
1
ROHS COMPLIANT
PRODUCT DATA DRAWING
REVISION HISTORY
REV.
DESCRIPTION
DATE
APPROVED
SEE SHEET 1
F
F
2.100
2X 1.980
4X .074
THRU
.052
2X .138
2X .138
E
E
2.260
.080
D
D
(2X .121)
PIN EXTRUSION
C
C
B
B
MATERIAL:
FINISH:
A
SEE NOTES
SEE NOTES
DIMENSIONS ARE IN INCHES
TOLERANCES:
ANGULAR:
1
.030
ONE PLACE DECIMAL
TWO PLACE DECIMAL
.010
THREE PLACE DECIMAL .005
INTERPRET DIMENSIONS AND TOLERANCES
PER ASME Y14.5M - 1994
UNLESS OTHERWISE SPECIFIED:
ALL DIMENSIONS ARE AFTER PLATING.
BREAK CORNERS & EDGES R.005 MAX.
CHAMFER 1ST AND LAST THREAD.
SURFACE ROUGHNESS 63 PER MIL-STD-10.
DIA'S ON COMMON CENTERS TO BE CONCENTRIC
WITHIN .005 T.I.R.
6. REMOVE ALL BURRS.
1.
2.
3.
4.
5.
SV Microwave, Inc.
2400 Centrepark West Drive, Suite 100
West Palm Beach, FL 33409
®
TITLE:
DO NOT SCALE DRAWING
PROPRIETARY
THE INFORMATION CONTAINED IN THIS DRAWING
IS THE SOLE PROPERTY OF SV MICROWAVE, INC.
ANY REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
SV MICROWAVE, INC. IS PROHIBITED.
THIRD ANGLE PROJECTION
DRAWN:
CHECKED:
APPROVED:
E.M. SIMULATION:
FED 05/27/16
STW 05/27/16
STW 05/27/16
SMPM FD MALE 8-PORT
EDGE LAUNCH
DWG. NO.
A
SIZE
CAGE CODE
C
2
95077
3211-60181
SHEET 2 OF 2
1
SCALE: 4:1
8
7
6
5
4
3
