CP316: DescriptionSmall Signal Transistor NPN - High Voltage Transistor Chip; File Size205KB，2 Pages; ManufacturerCentral Semiconductor

Download Datasheet View All

CP316 Overview

Small Signal Transistor NPN - High Voltage Transistor Chip

Preview

Download Datasheet

View All

PROCESS

Small Signal Transistor

NPN - High Voltage Transistor Chip

CP316

Central

Semiconductor Corp.

PROCESS DETAILS

Process

Die Size

Die Thickness

Base Bonding Pad Area

Emitter Bonding Pad Area

Top Side Metalization

Back Side Metalization

GEOMETRY

GROSS DIE PER 4 INCH WAFER

29,250

PRINCIPAL DEVICE TYPES

CMPT5551

CXT5551

CZT5551

2N5551

EPITAXIAL PLANAR

20 x 20 MILS

9.0 MILS

4.0 x 4.0 MILS

4.7 x 4.7 MILS

Al - 30,000Å

Au - 18,000Å

BACKSIDE COLLECTOR

145 Adams Avenue

Hauppauge, NY 11788 USA

Tel: (631) 435-1110

Fax: (631) 435-1824

www.centralsemi.com

R2 (1-August 2002)
