SINGLE PHASE GLASS PASSIVATED BRIDGE RECTIFIER
DF15005M THRU DF1510M
FEATURES
•
•
•
•
VOLTAGE RANGE
CURRENT
50 to 1000 Volts
1.5 Ampere
high forward surge current capability
Glass passivated chip junction
High case dielectric strength
High temperature soldering guaranteed:
260
O
C / 10 seconds
MECHANICAL DATA
•
•
•
•
•
Case: Transfer molded plastic
Terminal: Lead solderable per MIL-STD-750
method 2026
Polarity: Polarity symbols marked on case
Mounting: any
Weight: 0.04 ounce, 1.0 gram
DFM
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
•
•
•
Ratings at 25
O
C ambient temperature unless otherwise specified
Single Phase, half wave, 60Hz, resistive or inductive load
For capacitive load derate current by 20%
SYMBOLS
DF
DF
DF
DF
DF
DF
DF
15005M 1501M 1502M 1504M 1506M 1508M 1510M
UNIT
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current,
0.06” (1.5mm) lead length at T
A
= 40
O
C (Note 1)
Peak Forward Surge Current
8.3mS single half sine wave superimposed on
rated load (JEDEC method)
Rating for Fusing (t<8.3mS)
Maximum Instantaneous Forward Voltage drop per
Bridge element 1.5A
Maximum DC Reverse Current at Rated T
A
= 25
O
C
DC Blocking Voltage per element
T
A
= 125 C
O
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
I
2
t
V
F
I
R
C
J
R
θJC
T
J
T
STG
50
35
50
100
70
100
200
140
200
400
280
400
1.5
50
10
1.1
10
0.5
25
600
420
600
800
560
800
1000
700
1000
Volts
Volts
Volts
Amps
Amps
A
2
s
Volts
µA
mA
pF
O
Typical Junction Capacitance
(Measured at 1.0MHz and applied reverse voltage of
4.0V)
Typical Thermal Resistance (Note 1)
Operating Junction Temperature Range
Storage Temperature Range
40
(-55 to +150)
(-55 to +150)
C/W
O
C
O
C
Notes:
1.
Unit mounted on PCB with 0.51” X 0.51” (13mm X 13mm) copper pads
Sep-03, Rev A
