KBPC5000 - KBPC5010
PRV : 50 - 1000 Volts
Io : 50 Amperes
FEATURES :
*
*
*
*
*
*
*
High case dielectric strength
High surge current capability
High reliability
High efficiency
Low reverse current
Low forward voltage drop
Pb / RoHS Free
SILICON BRIDGE RECTIFIERS
BR50-M
0.728(18.50)
0.688(17.40)
0.570(14.50)
0.530(13.40)
0.685(16.7 1.130(28.70)
1.120(28.40)
0)
0.658(16.70)
0 618(15 70)
0.032(0.81)
0.028(0.71)
0.210(5.30
)
0.252(6.40
)
φ
0.100(2.50
)
0.905(23.0)
0.826(21.0)
MECHANICAL DATA :
Case : Metal Case
Epoxy : UL94V-O rate flame retardant
Terminals : plated .25" (6.35 mm). Faston
Polarity : Polarity symbols marked on case
Mounting position : Bolt down on heat-sink with
silicone thermal compound between bridge
and mounting surface for maximum heat
transfer efficiency.
* Weight : 17.1 grams
*
*
*
*
*
0.310(7.87)
0.280(7.11)
Dimensions in inches and ( millimeters )
Rating at 25
°
C ambient temperature unless otherwise specifie.
Single phase, half wave, 60 Hz, resistive or inductive load
For capacitive load, derate current by 20%
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
RATING
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Current Tc 55
°
C
=
Peak Forward Surge Current Single half sine wave
Superimposed on rated load (JEDEC Method)
Current Squared Time at t < 8.3 ms.
Maximum Forward Voltage per Diode at I
F
= 25A
Maximum DC Reverse Current
at Rated DC Blocking Voltage
Typical Thermal Resistance (Note 1)
Operating Junction Temperature Range
Storage Temperature Range
Ta = 25
°
C
Ta = 100
°
C
SYMBOL
KBPC
5000
50
35
50
KBPC
5001
100
70
100
KBPC
5002
200
140
200
KBPC
5004
400
280
400
50
400
660
1.1
10
500
2.0
- 40 to + 150
- 40 to + 150
KBPC
5006
600
420
600
KBPC
5008
800
560
800
KBPC
5010
1000
700
1000
UNIT
V
V
V
A
A
A
2
S
V
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
I
2
t
V
F
I
R
I
R(H)
R
θ
JC
T
J
T
STG
μA
μA
°C/W
°C
°C
Note :
( 1 ) Thermal resistance from Junction to Case with units mounted on a 9"x5"x4.6" (22.9x12.7x11.7 cm) Al-Finned Heatsink.
Page 1 of 2
Rev. 01 : August 25, 2005
RATING AND CHARACTERISTIC CURVES (KBPC50005 - KBPC5010 )
FIG.1 - DERATING CURVE FOR OUTPUT
RECTIFIED CURRENT
60
HEAT-SINK MOUNTING, Tc
9" x 5" x 4.6" THK.
5
5
5
(22.9 x 12.7 x 11.7cm)
Al.-Finned .
FIG.2 - MAXIMUM NON-REPETITIVE PEAK
FORWARD SURGE CURRENT
600
50
PEAK FORWARD SURGE CURRENT,
AMPERES
T
J
= 50
°C
500
AVERAGE FORWARD OUTPUT
CURRENT AMPERES
40
400
30
300
8.3 ms SINGLE HALF SINE WAVE
JEDEC METHOD
20
200
10
100
0
0
25
50
75
100
125
150
175
0
1
2
4
6
10
20
40
60 100
CASE TEMPERATURE, (
°
C)
NUMBER OF CYCLES AT 60Hz
FIG.3 - TYPICAL FORWARD CHARACTERISTICS
PER DIODE
100
FIG.4 - TYPICAL REVERSE CHARACTERISTICS
PER DIODE
10
T
J
= 100
°C
FORWARD CURRENT, AMPERES
REVERSE CURRENT,
MICROAMPERES
10
Pulse Width = 300
μs
1 % Duty Cycle
1.0
1.0
0.1
T
J
= 25
°C
T
J
= 25
°C
0.1
0.01
0
20
40
60
80
100
120
140
PERCENT OF RATED REVERSE
VOLTAGE, (%)
0.01
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
FORWARD VOLTAGE, VOLTS
Page 2 of 2
Rev. 01 : August 25, 2005
