APT10086SVR
1000V
13A 0.860
Ω
POWER MOS V
®
Power MOS V
®
is a new generation of high voltage N-Channel enhancement
mode power MOSFETs. This new technology minimizes the JFET effect,
increases packing density and reduces the on-resistance. Power MOS V
®
also achieves faster switching speeds through optimized gate layout.
D
3
PAK
• Faster Switching
• Lower Leakage
• 100% Avalanche Tested
• Surface Mount D
3
PAK Package
G
D
S
MAXIMUM RATINGS
Symbol
V
DSS
I
D
I
DM
V
GS
V
GSM
P
D
T
J
,T
STG
T
L
I
AR
E
AR
E
AS
Parameter
Drain-Source Voltage
Continuous Drain Current @ T
C
= 25°C
Pulsed Drain Current
1
All Ratings: T
C
= 25°C unless otherwise specified.
APT10086SVR
UNIT
Volts
Amps
1000
13
52
±30
±40
370
2.96
-55 to 150
300
13
30
4
Gate-Source Voltage Continuous
Gate-Source Voltage Transient
Total Power Dissipation @ T
C
= 25°C
Linear Derating Factor
Operating and Storage Junction Temperature Range
Lead Temperature: 0.063" from Case for 10 Sec.
Avalanche Current
1
Volts
Watts
W/°C
°C
Amps
mJ
(Repetitive and Non-Repetitive)
1
Repetitive Avalanche Energy
Single Pulse Avalanche Energy
1300
STATIC ELECTRICAL CHARACTERISTICS
Symbol
BV
DSS
I
D(on)
R
DS(on)
I
DSS
I
GSS
V
GS(th)
Characteristic / Test Conditions
Drain-Source Breakdown Voltage (V
GS
= 0V, I
D
= 250µA)
On State Drain Current
2
MIN
TYP
MAX
UNIT
Volts
Amps
1000
13
0.86
25
250
±100
2
4
(V
DS
> I
D(on)
x R
DS(on)
Max, V
GS
= 10V)
2
Drain-Source On-State Resistance
(V
GS
= 10V, 0.5 I
D[Cont.]
)
Ohms
µA
nA
Volts
050-5570 Rev B
Zero Gate Voltage Drain Current (V
DS
= V
DSS
, V
GS
= 0V)
Zero Gate Voltage Drain Current (V
DS
= 0.8 V
DSS
, V
GS
= 0V, T
C
= 125°C)
Gate-Source Leakage Current (V
GS
=
±30V,
V
DS
= 0V)
Gate Threshold Voltage (V
DS
= V
GS
, I
D
= 1.0mA)
APT Website - http://www.advancedpower.com
Bend, Oregon 97702-1035
F-33700 Merignac - France
Phone: (541) 382-8028
Phone: (33) 5 57 92 15 15
CAUTION:
These Devices are Sensitive to Electrostatic Discharge. Proper Handling Procedures Should Be Followed.
USA
405 S.W. Columbia Street
FAX: (541) 388-0364
FAX: (33) 5 56 47 97 61
EUROPE
Avenue J.F. Kennedy Bât B4 Parc Cadéra Nord
DYNAMIC CHARACTERISTICS
Symbol
C
iss
C
oss
C
rss
Q
g
Q
gs
Q
gd
t
d(on)
t
r
t
d(off)
t
f
Characteristic
Input Capacitance
Output Capacitance
Reverse Transfer Capacitance
Total Gate Charge
3
APT10086SVR
Test Conditions
V
GS
= 0V
V
DS
= 25V
f = 1 MHz
V
GS
= 10V
V
DD
= 0.5 V
DSS
I
D
= I
D[Cont.]
@ 25°C
V
GS
= 15V
V
DD
= 0.5 V
DSS
I
D
= I
D[Cont.]
@ 25°C
R
G
= 1.6Ω
MIN
TYP
MAX
UNIT
3700
350
180
185
16
90
12
10
43
10
4440
490
270
275
24
135
24
20
65
20
ns
nC
pF
Gate-Source Charge
Gate-Drain ("Miller ") Charge
Turn-on Delay Time
Rise Time
Turn-off Delay Time
Fall Time
SOURCE-DRAIN DIODE RATINGS AND CHARACTERISTICS
Symbol
I
S
I
SM
V
SD
t
rr
Q
rr
Characteristic / Test Conditions
Continuous Source Current (Body Diode)
Pulsed Source Current
Diode Forward Voltage
1
2
MIN
TYP
MAX
UNIT
Amps
Volts
ns
µC
13
52
1.3
800
11
(Body Diode)
(V
GS
= 0V, I
S
= -I
D[Cont.]
)
Reverse Recovery Time (I
S
= -I
D[Cont.]
, dl
S
/dt = 100A/µs)
Reverse Recovery Charge (I
S
= -I
D[Cont.]
, dl
S
/dt = 100A/µs)
THERMAL CHARACTERISTICS
Symbol
R
θJC
R
θJA
Characteristic
Junction to Case
Junction to Ambient
MIN
TYP
MAX
UNIT
°C/W
0.34
40
3
See MIL-STD-750 Method 3471
4
Starting T = +25°C, L = 15.38mH, R = 25Ω, Peak I = 13A
j
G
L
1
Repetitive Rating: Pulse width limited by maximum junction
temperature.
2
Pulse Test: Pulse width < 380
µS,
Duty Cycle < 2%
APT Reserves the right to change, without notice, the specifications and information contained herein.
0.4
Z
JC
, THERMAL IMPEDANCE (°C/W)
θ
D=0.5
0.1
0.05
0.2
0.1
0.05
PDM
0.01
0.005
0.02
0.01
Note:
t1
t2
050-5570 Rev B
SINGLE PULSE
0.001
10
-5
t
Duty Factor D = 1/t2
Peak TJ = PDM x Z
θJC
+ TC
10
-3
10
-2
10
-1
1.0
10
RECTANGULAR PULSE DURATION (SECONDS)
FIGURE 1, MAXIMUM EFFECTIVE TRANSIENT THERMAL IMPEDANCE, JUNCTION-TO-CASE vs PULSE DURATION
10
-4
APT10086SVR
25
I
D
, DRAIN CURRENT (AMPERES)
VGS=5.5V, 6V, 7V, 10V & 15V
I
D
, DRAIN CURRENT (AMPERES)
25
VGS=15V
20
VGS=7V & 10V
15
VGS=5.5V & 6V
5V
20
5V
15
10
4.5V
5
4V
0
100
200
300
400
500
V
DS
, DRAIN-TO-SOURCE VOLTAGE (VOLTS)
FIGURE 2, TYPICAL OUTPUT CHARACTERISTICS
30
0
10
4.5V
5
4V
0
4
8
12
16
20
V
DS
, DRAIN-TO-SOURCE VOLTAGE (VOLTS)
FIGURE 3, TYPICAL OUTPUT CHARACTERISTICS
0
R
DS
(ON), DRAIN-TO-SOURCE ON RESISTANCE
1.3
V
GS
I
D
, DRAIN CURRENT (AMPERES)
24
VDS> ID (ON) x RDS (ON)MAX.
250µSEC. PULSE TEST
@ <0.5 % DUTY CYCLE
NORMALIZED TO
= 10V @ 0.5 I [Cont.]
D
1.2
18
1.1
VGS=10V
VGS=20V
1.0
12
TJ = +125°C
TJ = +25°C
0
TJ = -55°C
6
0
2
4
6
8
V
GS
, GATE-TO-SOURCE VOLTAGE (VOLTS)
FIGURE 4, TYPICAL TRANSFER CHARACTERISTICS
14
I
D
, DRAIN CURRENT (AMPERES)
12
10
8
6
4
2
0
0.9
0
5
10
15
20
25
I
D
, DRAIN CURRENT (AMPERES)
FIGURE 5, R
DS
(ON) vs DRAIN CURRENT
BV
DSS
, DRAIN-TO-SOURCE BREAKDOWN
VOLTAGE (NORMALIZED)
25
I = 0.5 I [Cont.]
D
D
GS
1.15
1.10
1.05
1.00
0.95
50
75
100
125
150
T
C
, CASE TEMPERATURE (°C)
FIGURE 6, MAXIMUM DRAIN CURRENT vs CASE TEMPERATURE
R
DS
(ON), DRAIN-TO-SOURCE ON RESISTANCE
(NORMALIZED)
2.5
V
GS
(TH), THRESHOLD VOLTAGE
(NORMALIZED)
V
= 10V
-25
0
25 50 75 100 125 150
T
J
, JUNCTION TEMPERATURE (°C)
FIGURE 7, BREAKDOWN VOLTAGE vs TEMPERATURE
1.2
0.90
-50
2.0
1.1
1.0
1.5
0.9
0.8
0.7
050-5570 Rev B
1.0
0.5
0.0
-50
-25
0
25 50
75 100 125 150
T
J
, JUNCTION TEMPERATURE (°C)
FIGURE 8, ON-RESISTANCE vs. TEMPERATURE
-25
0
25 50 75 100 125 150
T
C
, CASE TEMPERATURE (°C)
FIGURE 9, THRESHOLD VOLTAGE vs TEMPERATURE
0.6
-50
APT10086SVR
60
I
D
, DRAIN CURRENT (AMPERES)
OPERATION HERE
LIMITED BY RDS (ON)
10µS
100µS
C, CAPACITANCE (pF)
15,000
10,000
5,000
Ciss
10
5
1mS
10mS
1
.5
TC =+25°C
TJ =+150°C
SINGLE PULSE
100mS
DC
1,000
500
Coss
Crss
.01
.1
1
10
50
V
DS
, DRAIN-TO-SOURCE VOLTAGE (VOLTS)
FIGURE 11, TYPICAL CAPACITANCE vs DRAIN-TO-SOURCE VOLTAGE
I
DR
, REVERSE DRAIN CURRENT (AMPERES)
50
100
.1
1
5 10
50 100
500 1000
V
DS
, DRAIN-TO-SOURCE VOLTAGE (VOLTS)
FIGURE 10, MAXIMUM SAFE OPERATING AREA
I = I [Cont.]
D
D
V
GS
, GATE-TO-SOURCE VOLTAGE (VOLTS)
20
VDS=100V
VDS=200V
12
VDS=500V
8
16
TJ =+150°C
10
5
TJ =+25°C
1
.5
4
50 100 150 200 250 300 350
Q
g
, TOTAL GATE CHARGE (nC)
FIGURE 12, GATE CHARGES vs GATE-TO-SOURCE VOLTAGE
0
0
0.2
0.4
0.6
0.8
1.0
1.2
V
SD
, SOURCE-TO-DRAIN VOLTAGE (VOLTS)
FIGURE 13, TYPICAL SOURCE-DRAIN DIODE FORWARD VOLTAGE
.1
D PAK Package Outline
Drain
(Heat Sink)
4.98 (.196)
5.08 (.200)
1.47 (.058)
1.57 (.062)
15.95 (.628)
16.05 (.632)
13.41 (.528)
13.51 (.532)
3
1.04 (.041)
1.15 (.045)
Revised
4/18/95
13.79 (.543)
13.99 (.551)
Revised
8/29/97
11.51 (.453)
11.61 (.457)
0.46 (.018)
0.56 (.022) {3 Plcs}
0.020 (.001)
0.178 (.007)
2.67 (.105)
2.84 (.112)
1.98 (.078)
2.08 (.082)
1.27 (.050)
1.40 (.055)
1.22 (.048)
1.32 (.052)
3.81 (.150)
4.06 (.160)
(Base of Lead)
5.45 (.215) BSC
{2 Plcs.}
Heat Sink (Drain)
and Leads
are Plated
050-5570 Rev B
Source
Drain
Gate
Dimensions in Millimeters (Inches)
APT's devices are covered by one or more of the following U.S.patents: 4,895,810
5,256,583
5,045,903
4,748,103
5,089,434
5,283,202
5,182,234
5,231,474
5,019,522
5,434,095
5,262,336
5,528,058
