B
Micro-D Backshells
Sample Part Number
Series
Shell Finish
Connector Size
Hardware Option
Jackscrew
Attachment Option
507-146
E
– Chem Film (Alodyne)
M
– Electroless Nickel
A
C
E
F
#4-40 THDS
ØD
507-146
Round Cable Entry Strain Relief Backshell
with Saddle Bar Clamps
507-146 Strain Relief Backshells
feature
saddle bar clamps for easy installation.
E-Rings
attach the backshell to the
Micro-D connector.
Materials
• Shell: Aluminum Alloy 6061 -T6
• Clips: 17-7PH Stainless Steel
• Hardware: 300 Series Stainless Steel
How To Order Round Cable Strain Relief Backshells
507-146
J
– Cadmium, Yellow Chromate
NF
– Cadmium, Olive Drab
(See Table I)
H
– Hex Head Jackscrew
F
– Jackpost, Female
C
–
"C" Clip
M
25
H
C
Z2
– Gold
09, 15, 21, 25, 31, 37 51, 51-2, 67, 69, 100
OMIT
– Fillister Head Jackscrew
E
– Extended Jackscrew
OMIT
(Leave Blank) –
Jackscrews Attach With E-Ring.
This Option Applies to Sizes 09 through 69.
Size 100 is Not Available with E-Ring.
Table I: Dimensions
CODE H
HEX HEAD
JACKSCREW
G
.28 (7.1)
CODE B
FILLISTER HEAD
JACKSCREW
.50 (12.7)
.26 (6.6)
CODE E
EXTENDED
JACKSCREW
CODE F
FEMALE
JACKPOST
#2-56 THDS SIZE 09-69
# 4-40 THDS SIZE 100
E-RING
C CLIP
ALTERNATE
CONFIGURATION
A Max.
In.
.915
1.065
1.215
1.315
1.465
1.615
1.565
1.965
2.365
2.265
2.305
mm.
23.24
27.05
30.86
33.40
37.21
41.02
39.75
49.81
60.07
57.53
58.55
In.
B Max.
mm.
11.43
11.43
11.43
11.43
11.43
11.43
12.57
11.43
11.43
12.57
13.72
In.
.565
.715
.865
.965
1.115
1.265
1.215
1.615
2.015
1.515
1.800
C
mm.
14.35
18.16
21.97
24.51
28.32
32.13
30.86
41.02
51.18
38.48
45.72
ØD
In.
± .010
.160
.190
.220
.260
.275
.285
.350
.285
.285
.350
.530
mm.
± 0.25
4.06
4.83
5.59
6.60
6.99
7.24
8.89
7.24
7.24
8.89
13.46
In.
E Max.
mm.
19.81
21.08
23.88
25.15
26.16
27.18
29.21
29.21
29.21
29.21
30.73
In.
F Max.
mm.
13.97
15.24
16.51
17.78
18.80
19.81
21.84
21.84
21.84
21.84
23.62
In.
G Max.
mm.
13.72
14.99
17.78
18.80
20.07
21.08
23.11
23.11
23.11
23.11
24.63
.450
.450
.450
.450
.450
.450
.495
.450
.450
.495
.540
.780
.830
.940
.990
1.030
1.070
1.150
1.150
1.150
1.150
1.210
.550
.600
.650
.700
.740
.780
.860
.860
.860
.860
.930
.540
.590
.700
.740
.790
.830
.910
.910
.910
.910
.970
