1S1G thru 1S9G
Glass Passivated Super Fast Rectifiers
Reverse Voltage 50 to 1000 Volts Forward Current 1.0 Ampere
Features
Low forward voltage drop
High current capability
High reliability
High surge current capability
Mechanical Data
Case: Molded plastic R-1
Epoxy: UL 94V-O rate flame retardant
Lead: Axial leads, solderable per MIL-STD-202, Method 208
guaranteed
Polarity: Color band denotes cathode end
High temperature soldering guaranteed:
250
o
C/10 seconds .375” (9.5mm) lead
lengths at 5 lbs., (2.3kg) tension
Mounting position: Any
Weight: 0.007 ounce, 0.20 gram
Maximum Ratings and Electrical Characteristics
Ratings at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Parameter
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
.375" (9.5mm) lead length @T
A
=55
o
C
Peak forward surge current, 8.3ms single
half sine-wave superimposed on rated load
(JEDEC Method)
Maximum instantaneous forward voltage @ 1.0A
Maximum DC reverse current
at rated DC blocking voltage
@ T
A
=25 C
@ T
A
=125
o
C
o
Symbols
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
V
F
I
R
t
rr
C
J
T
J
T
STG
1S 1G
50
35
50
1S 2G
100
70
100
1S 3G
150
105
150
1S 4G
200
140
200
1S 5G
300
210
300
1.0
1S 6G
400
280
400
1S 7G
600
420
600
1S 8G
800
560
800
1S 9G
1000
700
1000
Units
Volts
Volts
Volts
Amp
30.0
0.95
5.0
100
35
40
-55 to +150
-55 to +150
25
1.3
1.7
Amps
Volts
uA
uA
nS
pF
o
Maximum reverse recovery time (Note 1)
Typical junction capacitance (Note 2)
Operating junction temperature range
Storage temperature range
C
C
o
Notes:
1. Reverse Recovery Test Conditions: I
F
=0.5A, I
R
=1.0A, I
RR
=0.25A
2. Measured at 1 MHz and Applied Reverse Voltage of 4.0 V D.C.
223
