3M
Mini D Ribbon (MDR) Connectors
.050″ I/O Mounting Hardware — Jacksockets
3M Part Number
3341-10
Thread
Locking
Mat’l
.65
[ 16.5 ]
R .01
[ 0.3 ]
.30
[ 7.6 ]
.03
[ 0.8 ]
∅
.16
[ 4.0 ]
M2.5 Thd
.230 DP
3341-XX Series
Material:
Plating:
Thread Size:
Package Size:
ST. Steel
Passivated
M2.5/M2.5, 2.5 inch/lbs.
200 Pieces
M2.5 Thd
3M Part Number
3341-16
.65
[ 16.5 ]
R .01
[ 0.3 ]
.30
[ 7.6 ]
#4-40 Thd X
.230 DP
Material:
Plating:
Thread Size:
Package Size:
ST. Steel
Passivated
#4-40/#4-40, 3.5 inch/lbs.
200 Pieces
#4-40 Thd
Thread
Locking
Mat’l
.03
[ 0.8 ]
∅
.16
[ 4.0 ]
3M Part Number
3341-17
R .01
[ 0.3 ]
.65
[ 16.5 ]
.30
[ 7.6 ]
.03
[ 0.8 ]
#4-40 Thd X .230 DP
∅
.187
[ 4.75 ]
∅
.16
[ 4.0 ]
.03
[ 0.8 ]
Material:
Plating:
Thread Size:
Package Size:
ST. Steel
Passivated
#4-40/#4-40, 3.5 inch/lbs.
200 Pieces
Thread Locking Mat’l
#4-40 Thd
.65
[ 16.5 ]
.30
[ 7.6 ]
.03
[ 0.8 ]
∅
.187
[ 4.75 ]
∅
.16
[ 4.0 ]
#4-40 Thd X .230 DP
3M Part Number
3341-13
Thread
Locking
Mat’l
Material:
Plating:
Thread Size:
Package Size:
ST. Steel
Passivated
M2.5/#4-40, 2.5 inch/lbs.
200 Pieces
R .01
[ 0.3 ]
M2.5 Thd
.03
[ 0.8 ]
Inch
3M Part Number
3341-25
Thread
Locking
Mat’l
M2.5 Thd
Material:
Plating:
Thread Size:
Package Size:
ST. Steel
Passivated
M2.5/M2, 2.5 inch/lbs.
200 Pieces
.53
[ 13.5 ]
.05 [ 1.3 ]
R .01
[ 0.3 ]
[mm]
.12
[ 3.0 ]
.0
Inch
M2 Thd
×
.120 DP
∅
.188
[ 4.78 ]
∅
.16
[ 4.1 ]
±
.1
Tolerance Unless Noted
.00
.000
±
.01
±
.005
[ ] Dimensions for
Reference only
∅
.130
[ 3.30 ]
.025
[ 0.64 ]
.03
[ 0.8 ]
TS-0502-08
Sheet 1 of 2
3
Interconnect Solutions
http://www.3M.com/interconnects/
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
3M
Mini D Ribbon (MDR) Connectors
.050″ I/O Mounting Hardware — Jacksockets
3M Part Number
3341-31
3341-XX Series
Material:
Plating:
Thread Size:
Package Size:
ST. Steel
Passivated
M2.5/#4-40, 2.5 inch/lbs.
200 Pieces
3M Part Number
3341-32
Material:
Plating:
Thread Size:
Package Size:
ST. Steel
Passivated
M2.5/#4-40, 2.5 inch/lbs.
200 Pieces
TS-0502-08
Sheet 2 of 2
3
Interconnect Solutions
http://www.3M.com/interconnects/
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
