Single Digit LED Numeric Display
LA-401 D / N Series
SIM-013STW1
Datasheet
LA-401 D / N series is developed because of the demand for small single digit LED Numeric Display.
Materials of emission are GaAsP on GaP, AlGalnP and GaP. This is the height of a letter 10.16mm,
single digit LED Numeric Display that is packed by EPOXY resin.
lFeatures
1) The height of a letter is 10.16mm.
2) Dimension is 9.6×13.0×7.0mm.
3) The package of surface color is black. Color of segment is colored in emitting color.
4) Each color has anode common and cathode common respectively.
lDimensions
(Unit : mm)
lPin
assignments
Pin No.
1
2
3
4
5
6
7
8
9
10
Function
Common
Segment "f"
Segment "g"
Segment "e"
Segment "d"
Common
D.P
Segment "c"
Segment "b"
Segment "a"
lInternal
circuit schematic
lSelection
guide
Emitting color
Red
Orange
Yellow
Red
Green
(High brightness) (High brightness) (High brightness)
Common
Anode
LA-401VD LA-401AD LA-401ED LA-401XD LA-401MD
Cathode
LA-401VN LA-401AN LA-401EN LA-401XN LA-401MN
www.rohm.com
© 2015 ROHM Co., Ltd. All rights reserved.
1/4
2017.03 - Rev.D
LA-401 D / N Series
lAbsolute
maximum ratings
(T
a
= 25°C)
Parameter
Power dissipation
Datasheet
Symbol
P
D
Red
Red
Orange
Yellow
(High brightness)
(High brightness) (High brightness)
Green
Unit
mW
mW
mA
mA
V
°C
°C
LA-401VD / VN LA-401AD / AN
LA-401ED / EN LA-401XD / XN
LA-401MD / MN
320
40
15
60 *
1
5
520
65
25
50 *
2
5
520
65
25
50 *
2
5
-25
to
+75
-30
to
+85
520
65
25
50 *
2
5
480
60
20
60 *
1
5
Power dissipation
P
D
/ seg
Forward current
Peak forward current
I
F
I
FP
V
R
T
opr
T
stg
Reverse voltage
Operating temperature
Storage temperature
*
1
Pulse width 1ms, duty 1 / 5
*
2
Pulse width 0.1ms, duty 1 / 10
lElectrical
and optical characteristics
(T
a
= 25°C)
Parameter
Forward voltage
Reverse current
Peak wavelength
Spectral line halfwidth
Symbol
Conditions
V
F
I
R
l
p
Dl
I
F
=10mA
V
R
=3V
Red
Red
Orange
Yellow
(High brightness) (High brightness) (High brightness)
Green
Unit
V
mA
nm
nm
Typ. Max. Typ. Max. Typ. Max. Typ. Max. Typ. Max.
2.0
-
2.8
2.05*
2.6*
2.05*
2.6*
2.05*
2.6* 2.1
100
-
-
-
626*
2.8
100
-
-
100
-
-
-
610*
100
-
-
-
589*
100
-
-
-
563
40
I
F
=10mA 650
I
F
=10mA
40
18*
17*
15*
◎
Not designed for radiation resistance.
* Shows the number on the condition of I
F
=20mA.
lLuminous
intensity
Parameter
Red
Red
(High brightness)
l
p
650
626
610
589
563
Type
LA-401VD
LA-401VN
LA-401AD
LA-401AN
LA-401ED
LA-401EN
LA-401XD
LA-401XN
LA-401MD
LA-401MN
Min.
5.6
36
36
36
5.6
Typ.
16
90
90
90
16
Max.
-
-
-
-
-
Unit
mcd
mcd
mcd
mcd
mcd
Orange
(High brightness)
Yellow
(High brightness)
Green
◎
Condition I
F
=10mA
www.rohm.com
© 2015 ROHM Co., Ltd. All rights reserved.
2/4
2017.03 - Rev.D
