SAK-C164SV-2RF datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> SAK-C164SV-2RF

SAK-C164SV-2RF: Description16-Bit Single-Chip Microcontroller; CategoryThe embedded processor and controller Microcontrollers and processors; File Size638KB，65 Pages; ManufacturerInfineon; Websitehttp://www.infineon.com/

Download Datasheet Parametric Compare View All

SAK-C164SV-2RF Overview

16-Bit Single-Chip Microcontroller

SAK-C164SV-2RF Parametric

Parameter Name	Attribute value
Maker	Infineon
Parts packaging code	QFP
package instruction	PLASTIC, TQFP-64
Contacts	64
Reach Compliance Code	compliant
ECCN code	3A001.A.3
Has ADC	YES
Address bus width	16
bit size	16
CPU series	C166
maximum clock frequency	50 MHz
DAC channel	NO
DMA channel	NO
External data bus width	16
JESD-30 code	S-PQFP-G64
length	10 mm
Number of I/O lines	50
Number of terminals	64
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	LFQFP
Encapsulate equivalent code	QFP64,.47SQ,20
Package shape	SQUARE
Package form	FLATPACK, LOW PROFILE, FINE PITCH
power supply	3/5 V
Certification status	Not Qualified
RAM (bytes)	1024
rom(word)	16384
ROM programmability	MROM
Maximum seat height	1.6 mm
speed	20 MHz
Maximum slew rate	37 mA
Maximum supply voltage	5.5 V
Minimum supply voltage	4.5 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	AUTOMOTIVE
Terminal form	GULL WING
Terminal pitch	0.5 mm
Terminal location	QUAD
width	10 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER
Base Number Matches	1

Preview

Download Datasheet

View All

D at a S heet, V1.0, Apr. 20 0 3

C 16 4 S V

1 6 -B i t S i n g l e - C h i p M ic r o co n t ro l l e r

M i c r o c o n t ro l le r s

N e v e r

s t o p

t h i n k i n g .

SAK-C164SV-2RF Related Products

	SAK-C164SV-2RF	C164SV	SAF-C164SV-2RF	SAK-C164SV-2R25F	SAF-C164SV-2R25F
Description	16-Bit Single-Chip Microcontroller	16-Bit Single-Chip Microcontroller	16-Bit Single-Chip Microcontroller	16-Bit Single-Chip Microcontroller	16-Bit Single-Chip Microcontroller
Maker	Infineon	-	Infineon	Infineon	Infineon
Parts packaging code	QFP	-	QFP	QFP	QFP
package instruction	PLASTIC, TQFP-64	-	PLASTIC, TQFP-64	LFQFP, QFP64,.47SQ,20	LFQFP, QFP64,.47SQ,20
Contacts	64	-	64	64	64
Reach Compliance Code	compliant	-	compliant	compliant	compliant
ECCN code	3A001.A.3	-	3A001.A.3	3A001.A.3	3A001.A.3
Has ADC	YES	-	YES	YES	YES
Address bus width	16	-	16	16	16
bit size	16	-	16	16	16
CPU series	C166	-	C166	C166	C166
maximum clock frequency	50 MHz	-	50 MHz	50 MHz	50 MHz
DAC channel	NO	-	NO	NO	NO
DMA channel	NO	-	NO	NO	NO
External data bus width	16	-	16	16	16
JESD-30 code	S-PQFP-G64	-	S-PQFP-G64	S-PQFP-G64	S-PQFP-G64
length	10 mm	-	10 mm	10 mm	10 mm
Number of I/O lines	50	-	50	50	50
Number of terminals	64	-	64	64	64
Maximum operating temperature	125 °C	-	85 °C	125 °C	85 °C
Minimum operating temperature	-40 °C	-	-40 °C	-40 °C	-40 °C
PWM channel	YES	-	YES	YES	YES
Package body material	PLASTIC/EPOXY	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	LFQFP	-	LFQFP	LFQFP	LFQFP
Encapsulate equivalent code	QFP64,.47SQ,20	-	QFP64,.47SQ,20	QFP64,.47SQ,20	QFP64,.47SQ,20
Package shape	SQUARE	-	SQUARE	SQUARE	SQUARE
Package form	FLATPACK, LOW PROFILE, FINE PITCH	-	FLATPACK, LOW PROFILE, FINE PITCH	FLATPACK, LOW PROFILE, FINE PITCH	FLATPACK, LOW PROFILE, FINE PITCH
power supply	3/5 V	-	3/5 V	3/5 V	3/5 V
Certification status	Not Qualified	-	Not Qualified	Not Qualified	Not Qualified
RAM (bytes)	1024	-	1024	1024	1024
rom(word)	16384	-	16384	16384	16384
ROM programmability	MROM	-	MROM	MROM	MROM
Maximum seat height	1.6 mm	-	1.6 mm	1.6 mm	1.6 mm
speed	20 MHz	-	20 MHz	25 MHz	25 MHz
Maximum slew rate	37 mA	-	37 mA	46 mA	46 mA
Maximum supply voltage	5.5 V	-	5.5 V	5.5 V	5.5 V
Minimum supply voltage	4.5 V	-	4.5 V	4.5 V	4.5 V
Nominal supply voltage	5 V	-	5 V	5 V	5 V
surface mount	YES	-	YES	YES	YES
technology	CMOS	-	CMOS	CMOS	CMOS
Temperature level	AUTOMOTIVE	-	INDUSTRIAL	AUTOMOTIVE	INDUSTRIAL
Terminal form	GULL WING	-	GULL WING	GULL WING	GULL WING
Terminal pitch	0.5 mm	-	0.5 mm	0.5 mm	0.5 mm
Terminal location	QUAD	-	QUAD	QUAD	QUAD
width	10 mm	-	10 mm	10 mm	10 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER	-	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER
Base Number Matches	1	-	1	1	1
