2N3819

Description
RF JFET Transistors N-CH -25V 10mA BULK
CategoryDiscrete semiconductor    The transistor
File Size1018KB,4 Pages
ManufacturerCentral Semiconductor
Download Datasheet Parametric View All

2N3819 Online Shopping

Suppliers Part Number Price MOQ In stock
2N3819 - - View Buy Now

2N3819 Overview

RF JFET Transistors N-CH -25V 10mA BULK

2N3819 Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
Parts packaging codeTO-92
package instructionCYLINDRICAL, O-PBCY-T3
Contacts3
Reach Compliance Codenot_compliant
ECCN codeEAR99
ConfigurationSINGLE
Minimum drain-source breakdown voltage25 V
Maximum drain current (ID)0.02 A
FET technologyJUNCTION
Maximum feedback capacitance (Crss)4 pF
JEDEC-95 codeTO-92
JESD-30 codeO-PBCY-T3
JESD-609 codee0
Number of components1
Number of terminals3
Operating modeDEPLETION MODE
Maximum operating temperature150 °C
Package body materialPLASTIC/EPOXY
Package shapeROUND
Package formCYLINDRICAL
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Polarity/channel typeN-CHANNEL
Maximum power dissipation(Abs)0.36 W
Certification statusNot Qualified
surface mountNO
Terminal surfaceTin/Lead (Sn/Pb)
Terminal formTHROUGH-HOLE
Terminal locationBOTTOM
Maximum time at peak reflow temperatureNOT SPECIFIED
transistor applicationsAMPLIFIER
Transistor component materialsSILICON
Base Number Matches1
2N3819
w w w. c e n t r a l s e m i . c o m
SILICON
N-CHANNEL JFET
The CENTRAL SEMICONDUCTOR 2N3819 is a silicon
N-Channel JFET designed for RF amplifier and mixer
applications.
MARKING: FULL PART NUMBER
TO-92 CASE
MAXIMUM RATINGS:
(TA=25°C)
Drain-Gate Voltage
Drain-Source Voltage
Gate-Source Voltage
Continuous Gate Current
Power Dissipation
Operating and Storage Junction Temperature
SYMBOL
VDG
VDS
VGS
IG
PD
TJ, Tstg
UNITS
V
V
V
mA
mW
°C
25
25
25
10
360
-65 to +150
ELECTRICAL CHARACTERISTICS:
(TA=25°C unless otherwise noted)
SYMBOL
TEST CONDITIONS
MIN
IGSS
VGS=15V
IGSS
VGS=15V, TA=100°C
IDSS
BVGSS
VGS(OFF)
VGS
VDS=15V
IG=1.0μA
VDS=15V, ID=2.0nA
VDS=15V, ID=200μA
VDS=15V, VGS=0, f=1.0MHz
VDS=15V, VGS=0, f=100MHz
VDS=15V, VGS=0, f=1.0kHz
VDS=15V, VGS=0, f=1.0MHz
VDS=15V, VGS=0, f=1.0MHz
2.0
25
MAX
2.0
2.0
20
8.0
UNITS
nA
μA
mA
V
V
V
mS
mS
μS
pF
pF
0.5
2.0
1.6
7.5
6.5
50
8.0
4.0
|
Yfs
|
|
Yfs
|
|
Yos
|
Ciss
Crss
R1 (9-January 2014)
