IllumInatIon
luXEon 3030 HV
High flux, hot-color targeted,
24V and 48V mid power packages
LUXEON 3030 HV is an industry standard package to optimize total voltage
output, available in 24V and 48V. This high voltage at low current architecture
allows system design freedom and is compatible with more efficient and
cost effective drivers. This mid power LED is 1/9
th
micro-color binned for
tight color control and hot-color targeted to ensure that the LEDs are within
color target at application conditions—85°C. LUXEON 3030 HV delivers
efficacy and reliability for a variety of applications such as downlights, lamps
and spotlights.
FEaturEs and BEnEFIts
High voltage at low current, compatible with more efficient and cost
effective drivers
24V and 48V options available to optimize total voltage output
1/9
th
micro color binning and 85°C hot-color targeting enables tight
color control
EMC based package affirms lumen maintenance and long lifetime
PrImary aPPlIcatIons
Downlights
Lamps
Spotlights
DS215 LUXEON 3030 HV Product Datasheet ©2017 Lumileds Holding B.V. All rights reserved.
No. E352519
Table of Contents
General Product Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Test Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Part Number Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Lumen Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Environmental Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Performance Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Product Selection Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Optical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Electrical and Thermal Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Characteristic Curves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Spectral Power Distribution Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Light Output Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Forward Current Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Radiation Pattern Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9
Product Bin and Labeling Definitions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Decoding Product Bin Labeling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Luminous Flux Bins
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Color Bin Definitions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Forward Voltage Bins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Mechanical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Reflow Soldering Guidelines
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
JEDEC Moisture Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Solder Pad Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Packaging Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Pocket Tape Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Reel Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
DS215 LUXEON 3030 HV Product Datasheet 20170110 ©2017 Lumileds Holding B.V. All rights reserved.
i
General Product Information
Product Test Conditions
LUXEON 3030 HV LEDs are tested with a 20ms monopulse of 34mA for LUXEON 3030 HV 24V and 17mA for LUXEON 3030 HV
48V parts at a junction temperature,T
j
, of 25°C. Forward voltage and luminous flux are binned at a T
j
of 25°C, while color is hot
targeted at a T
j
of 85°C.
Part Number Nomenclature
Part numbers for LUXEON 3030 HV follow the convention below:
L 1 3 0 –
A A B B C C
H V 0 0 0 0 1
Where:
A A
–
B B
–
C C
–
designates nominal CCT (27=2700K, 30=3000K, 35=3500K, 40=4000K, 50=5000K, 57=5700K, 65=6500K)
designates minimum CRI (80=80CRI, 90=90CRI)
designates voltage (0B=24V and 0C=48V)
Therefore, the following part number is used for a LUXEON 3030 HV 3000K 80CRI 24V:
L 1 3 0 –
3 0 8 0 0 B
H V 0 0 0 0 1
Lumen Maintenance
Please contact your local Sales Representative or Lumileds Technical Solutions Manager for more information about the long-
term performance of this product.
Environmental Compliance
Lumileds LLC is committed to providing environmentally friendly products to the solid-state lighting market. LUXEON 3030 HV
is compliant to the European Union directives on the restriction of hazardous substances in electronic equipment, namely the
RoHS Directive 2011/65/EU and REACH Regulation (EC) 1907/2006. Lumileds LLC will not intentionally add the following restricted
materials to its products: lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls (PBB) or polybrominated
diphenyl ethers (PBDE).
DS215 LUXEON 3030 HV Product Datasheet 20170110 ©2017 Lumileds Holding B.V. All rights reserved.
2
Performance Characteristics
Product Selection Guide
Table 1. Product performance of LUXEON 3030 HV at specified test current and temperature.
VoltaGE
nomInal
cct
[1]
2700K
3000K
3500K
4000K
24V
5000K
5700K
6500K
2700K
3000K
2700K
3000K
3500K
48V
4000K
5000K
5700K
6500K
2700K
mInImum
crI
[2, 3]
80
80
80
80
80
80
80
90
90
80
80
80
80
80
80
80
90
lumInous FluX
[2, 3]
(lm)
mInImum
97
99
102
107
107
107
107
87
90
97
99
102
107
107
107
107
87
tyPIcal
107
109
112
117
117
117
117
92
95
107
109
112
117
117
117
117
92
tyPIcal
lumInous
EFFIcacy (lm/W)
132
135
139
145
145
145
145
114
116
132
135
139
145
145
145
145
114
tEst currEnt
(ma)
34
34
34
34
34
34
34
34
34
17
17
17
17
17
17
17
17
Part numBEr
L130-27800BHV00001
L130-30800BHV00001
L130-35800BHV00001
L130-40800BHV00001
L130-50800BHV00001
L130-57800BHV00001
L130-65800BHV00001
L130-27900BHV00001
L130-30900BHV00001
L130-27800CHV00001
L130-30800CHV00001
L130-35800CHV00001
L130-40800CHV00001
L130-50800CHV00001
L130-57800CHV00001
L130-65800CHV00001
L130-27900CHV00001
Notes for Table 1:
1. Correlated color temperature is hot targeted at T
j
=85°C.
2.
Luminous flux and CRI specs are based upon mounted package on highly reflective surface at T
j
=25°C. Typical CRI is approximately 2 points higher than the minimum CRI specified, but this is
not guaranteed.
3.
Lumileds maintains a tolerance of ±2 on CRI and ±7.5% on luminous flux measurements.
Optical Characteristics
Table 2 . Optical characteristics for LUXEON 3030 HV at test current, T
j
=25°C .
Part numBEr
L130-XXXXXXHV00001
tyPIcal total IncludEd anGlE
[1]
140°
tyPIcal VIEWInG anGlE
[2]
116°
Notes for Table 2:
1.
Total angle at which 90% of total luminous flux is captured.
2.
Viewing angle is the off axis angle from the LED centerline where the luminous intensity is ½ of the peak value.
DS215 LUXEON 3030 HV Product Datasheet 20170110 ©2017 Lumileds Holding B.V. All rights reserved.
3
Electrical and Thermal Characteristics
Table 3 . Electrical and thermal characteristics for LUXEON 3030 HV at test current, T
j
=25°C .
Part numBEr
L130- XXXXXBHV00001
L130- XXXXXCHV00001
ForWard VoltaGE
[1]
(V
f
)
mInImum
22.5
45.0
tyPIcal
24.0
48.0
maXImum
25.0
50.0
tyPIcal tEmPEraturE
coEFFIcIEnt oF ForWard
VoltaGE
[2]
(mV/°c)
-13
-26
tyPIcal tHErmal
rEsIstancE — JunctIon
to soldEr Pad (°c/W)
12
12
Notes for Table 3:
1. Lumileds maintains a tolerance of ±0.1V on forward voltage measurements.
2. Measured between 25°C and 85°C.
Absolute Maximum Ratings
Table 4 . Absolute maximum ratings for LUXEON 3030 HV .
ParamEtEr
DC Forward Current
[1,2]
Peak Pulsed Forward Current
[1,3]
LED Junction Temperature
[1]
(DC & Pulse)
ESD Sensitivity (ANSI/ESDA/JEDEC JS-001-2012)
Operating Case Temperature
[1]
LED Storage Temperature
Soldering Temperature
Allowable Reflow Cycles
Reverse Voltage (V
reverse
)
maXImum PErFormancE
60mA for L130-xxxx0BHV00001
30mA for L130-xxxx0CHV00001
80mA for L130-xxxx0BHV00001
40mA for L130-xxxx0CHV00001
125°C
Class 2
-40°C to 105°C
-40°C to 105°C
JEDEC 020D 260°C
3
LUXEON LEDs are not designed to be driven in reverse bias
Notes for Table 4:
1.
Proper current derating must be observed to maintain the junction temperature below the maximum allowable junction temperature.
2. Residual periodic variations due to power conversion from alternating current (AC) to direct current (DC), also called “ripple,” are acceptable if the following conditions are met:
– The frequency of the ripple current is 100Hz or higher
– The average current for each cycle does not exceed the maximum allowable DC forward current
– The maximum amplitude of the ripple does not exceed 25% of the maximum allowable DC forward current
3.
Pulsed operation with the maximum peak pulsed forward current is acceptable if the pulse duty cycle is ≤10%.
DS215 LUXEON 3030 HV Product Datasheet 20170110 ©2017 Lumileds Holding B.V. All rights reserved.
4
