IllumInatIon
luXeon rebel Plus
The original high power LED
LUXEON Rebel PLUS is designed with the highest possible efficacy and
light output from an industry standard 4530 package with a 2.5mm
2
dome. With hot testing and color binning, every LUXEON Rebel PLUS
is tested and specified at real world operating conditions—85°C.
Our exceptional color control enables design simplicity for luminaire
manufacturers and ensures that they can be confident in color
consistency from LED to LED. The superior quality of light, light output,
and real world efficacy enable leading performance and efficient solution
development in a wide variety of outdoor and industry lighting segments.
Features and BeneFIts
3- and 5-step MacAdam ellipse:
Freedom from Binning
for superior
quality of light
Ability to deliver high lm/$ for Indoor applications
Low typical V
f
~2.8V
Small optical source size
Full range of CCTs in 80CRI minimum
LM-80 test report available
PrImary aPPlIcatIons
High Bay & Low Bay
Outdoor
DS107 LUXEON Rebel PLUS Product Datasheet ©2017 Lumileds Holding B.V. All rights reserved.
No. E352519
Table of Contents
General Product Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Test Conditions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Part Number Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Lumen Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Environmental Compliance
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Performance Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Product Selection Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3
Optical Characteristics
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3
Electrical and Thermal Characteristics.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4
Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Characteristic Curves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Spectral Power Distribution Characteristics
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5
Light Output Characteristics
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5
Forward Current Characteristics.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Radiation Pattern Characteristics
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Product Bin and Labeling Definitions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Decoding Product Bin Labeling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Luminous Flux Bins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Color Bin Definitions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8
Forward Voltage Bins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Mechanical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Reflow Soldering Guidelines
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
JEDEC Moisture Sensitivity
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Pad Configuration
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Solder Pad Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Packaging Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Pocket Tape Dimensions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Reel Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13
DS107 LUXEON Rebel PLUS Product Datasheet 20170712 ©2017 Lumileds Holding B.V. All rights reserved.
i
General Product Information
Product Test Conditions
LUXEON Rebel PLUS LEDs are tested and binned with a DC drive current of 350mA at a junction temperature, T
j
, of 85°C.
Part Number Nomenclature
Part numbers for LUXEON Rebel PLUS follow the convention below:
L X 1 8 –
P 1
A A
–
B
Where:
A A
–
B
–
designates nominal ANSI CCT (27=2700K, 30=3000K, 35=3500K, 40=4000K, 50=5000K)
designates color defintion (3=3 SDCM and 5=5 SDCM)
Therefore, the following part number is used for a LUXEON Rebel PLUS 3000K with 3 SDCM:
L X 1 8 – P 1
3 0 – 3
Lumen Maintenance
Please contact your local Sales Representative or Lumileds Technical Solutions Manager for more information about the long-
term performance of this product.
Environmental Compliance
Lumileds LLC is committed to providing environmentally friendly products to the solid-state lighting market. LUXEON Rebel PLUS
is compliant to the European Union directives on the restriction of hazardous substances in electronic equipment, namely the
RoHS Directive 2011/65/EU and REACH Regulation (EC) 1907/2006. Lumileds LLC will not intentionally add the following restricted
materials to its products: lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls (PBB) or polybrominated
diphenyl ethers (PBDE).
DS107 LUXEON Rebel PLUS Product Datasheet 20170712 ©2017 Lumileds Holding B.V. All rights reserved.
2
Performance Characteristics
Product Selection Guide
Table 1. Product performance of LUXEON Rebel PLUS at 350mA and 700mA, T
j
=85°C .
nomInal
cct
2700K
3000K
3500K
4000K
5000K
mInImum
crI
[1, 2]
80
80
80
80
80
lumInous FluX
[1]
(lm)
mInImum
80
85
90
90
95
tyPIcal
350ma
85
95
98
103
106
88
98
101
107
110
156
166
172
180
186
tyPIcal
lumInous
eFFIcacy (lm/W)
tyPIcal
lumInous
FluX (lm)
tyPIcal
lumInous
eFFIcacy (lm/W)
700ma
78
83
86
90
93
LX18-P127-x
LX18-P130-x
LX18-P135-x
LX18-P140-x
LX18-P150-x
Part numBer
Notes for Table 1:
1.
Lumileds maintains a tolerance of ±2 on CRI and ±6.5% on luminous flux measurements.
2.
Typical CRI is approximately 2 points higher than the minimum CRI specified, but this is not guaranteed.
Optical Characteristics
Table 2. Optical characteristics for LUXEON Rebel PLUS at 350mA, T
j
=85°C .
Part numBer
LX18-P127-x
LX18-P130-x
LX18-P135-x
LX18-P140-x
LX18-P150-x
tyPIcal total Included angle
[1]
160°
160°
160°
160°
160°
tyPIcal VIeWIng angle
[2]
120°
120°
120°
120°
120°
Notes for Table 2:
1.
Total angle at which 90% of total luminous flux is captured.
2.
Viewing angle is the off axis angle from the LED centerline where the luminous intensity is ½ of the peak value.
DS107 LUXEON Rebel PLUS Product Datasheet 20170712 ©2017 Lumileds Holding B.V. All rights reserved.
3
Electrical and Thermal Characteristics
Table 3. Electrical and thermal characteristics for LUXEON Rebel PLUS at 350mA, T
j
=85°C .
Part numBer
LX18-P127-x
LX18-P130-x
LX18-P135-x
LX18-P140-x
LX18-P150-x
ForWard Voltage
[1]
(V
f
)
mInImum
2.5
2.5
2.5
2.5
2.5
tyPIcal
2.8
2.8
2.8
2.8
2.8
maXImum
3.0
3.0
3.0
3.0
3.0
tyPIcal temPerature
coeFFIcIent oF ForWard
Voltage
[2]
(mV/°c)
-1.0 to -3.0
-1.0 to -3.0
-1.0 to -3.0
-1.0 to -3.0
-1.0 to -3.0
tyPIcal thermal
resIstance—JunctIon
to solder Pad (°c/W)
9.0°
9.0°
9.0°
9.0°
9.0°
Notes for Table 3:
1. Lumileds maintains a tolerance of ±0.06V on forward voltage measurements.
2.
Measured between 25°C and 110°C.
Absolute Maximum Ratings
Table 4. Absolute maximum ratings for LUXEON Rebel PLUS.
Parameter
DC Forward Current
[1, 2]
Peak Pulsed Forward Current
[1, 3]
LED Junction Temperature
[1]
(DC & Pulse)
ESD Sensitivity (ANSI/ESDA/JEDEC JS-001-2012)
Operating Case Temperature
[1]
LED Storage Temperature
Soldering Temperature
Allowable Reflow Cycles
Reverse Voltage (V
reverse
)
maXImum PerFormance
1000mA
1000mA
150°C
< 8000V Human Body Model (HBM) Class 3A JESD22-A114-E
-40°C to 135°C
-40°C to 135°C
JEDEC 020c 260°C
3
LUXEON LEDs are not designed to be driven in reverse bias
Notes for Table 4:
1.
Proper current derating must be observed to maintain the junction temperature below the maximum allowable junction temperature.
2.
Residual periodic variations due to power conversion from alternating current (AC) to direct current (DC), also called “ripple,” are acceptable if the following conditions are met:
– The frequency of the ripple current is 100Hz or higher
– The average current for each cycle does not exceed the maximum allowable DC forward current
– The maximum amplitude of the ripple does not exceed the maximum peak pulsed forward current
3. Pulsed operation with the maximum peak pulsed forward current is acceptable if the pulse on-time is ≤5ms per cycle and the duty cycle is ≤50%.
DS107 LUXEON Rebel PLUS Product Datasheet 20170712 ©2017 Lumileds Holding B.V. All rights reserved.
4
