CLD-DS135 Rev 1D
Product family data sheet
Cree
®
XLamp
®
XQ-A LEDs
ProDuCt DEsCriPtion
The
XLamp
®
XQ-A
LeD
brings
a
mid-power, cost-effective option to the
proven, compact ceramic XQ package,
enabling lighting manufacturers to quickly
and easily expand their product portfolio
by leveraging a common XQ design.
Unlike
to
plastic
the
mid-power
long-term
LeDs,
the
ceramic-based XQ-A LeDs are designed
deliver
calculated
lifetimes of Cree’s other high-power
LeDs. The XQ-A LeD’s combination
of optical symmetry and consistency
across all colors improves color mixing
and simplifies the production process
for lighting manufacturers. Available in
both white and color configurations, the
XQ-A LeD family opens up new design
possibilities for a wide spectrum of
lighting applications, such as portable,
directional and architectural lighting.
FEAturEs
•
•
Cree’s smallest lighting class LeD:
1.6 X 1.6 mm
Available in 70-, 80- & 90-CRI white,
and royal blue, blue, green, PC amber,
red-orange & red
•
•
Maximum drive current: white:
300 mA, color: 250 mA
Wide viewing angle: white: 100°,
royal blue, blue, PC amber: 105°,
green, red-orange, red: 110°
•
•
•
•
Reflow solderable - JEDEC
J-STD-020C compatible
Unlimited floor life at
≤ 30 °C/85% RH
RoHS compliant
UL
®
recognized component
(E349212)
tAbLE oF ContEnts
Characteristics ........................................2
Flux Characteristics - White....................3
Flux Characteristics - Color ....................4
Relative Spectral Power Distribution .....6
Relative Flux vs. Junction Temperature
.7
electrical Characteristics ........................8
Relative Flux vs. Current .........................9
Relative Chromaticity vs. Current and
Temperature ..........................................11
Typical Spatial Distribution...................12
Thermal Design .....................................13
Reflow Soldering Characteristics
.........14
Notes .....................................................15
Mechanical Dimensions .......................16
Tape and Reel ........................................17
Packaging ..............................................18
www.CRee.Com/XLAmp
Copyright © 2016-2018 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are
registered trademarks and the Cree logo is a trademark of Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
Cree, Inc.
4600 Silicon Drive
Durham, NC 27703
USA Tel: +1.919.313.5300
XLamp
®
XQ-a LED
ChArACtEristiCs
Characteristics
Thermal resistance, junction to solder point - white
Thermal resistance, junction to solder point - royal blue, blue
Thermal resistance, junction to solder point - green
Thermal resistance, junction to solder point - PC amber
Thermal resistance, junction to solder point - red-orange, red
Viewing angle (FWHM) - white
Viewing angle (FWHM) - royal blue, blue, PC amber
Viewing angle (FWHM) - green, red-orange, red
Temperature coefficient of voltage - white
Temperature coefficient of voltage - royal blue, blue
Temperature coefficient of voltage - green
Temperature coefficient of voltage - PC amber
Temperature coefficient of voltage - red-orange, red
ESD withstand voltage (HBM per Mil-Std-883D) - white, royal blue, blue, green, red-orange, red
ESD classification (HBM per Mil-Std-883D) - PC amber
DC forward current-white
DC forward current - color
Reverse voltage
Forward voltage (@ 175 mA, 85 °C) - white
Forward voltage (@ 175 mA, 25 °C) - royal blue, blue
Forward voltage (@ 175 mA, 25 °C) - green
Forward voltage (@ 175 mA, 25 °C) - PC amber
Forward voltage (@ 175 mA, 25 °C) - red-orange, red
LeD junction temperature
mA
mA
v
v
v
v
v
v
°C
3.0
3.25
3.4
3.4
2.2
unit
°C/W
°C/W
°C/W
°C/W
°C/W
degrees
degrees
degrees
mV/°C
mV/°C
mV/°C
mV/°C
mV/°C
Minimum
typical
20
17
30
20
18
100
105
110
-2.8
-4
-4.3
-4.2
-2.0
Class 3A
Class 2
300
250
5
3.3
3.6
3.6
3.7
2.6
150
Maximum
Copyright © 2016-2018 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are registered trademarks and the Cree logo is a trademark of
Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
2
XLamp
®
XQ-a LED
FLuX ChArACtEristiCs - WhitE (t
J
= 85 °C)
The following table provides several base order codes for XLamp XQ-A white LeDs. It is important to note that the base order codes listed
here are a subset of the total available order codes for the product family. For more order codes, as well as a complete description of the
order-code nomenclature, please consult the XLamp XQ Family LEDs Binning and Labeling document.
Calculated
Minimum
Luminous
Flux (lm)
@ 85 °C**
300 mA
65.6
74.2
81.6
65.6
74.2
81.6
57.1
65.6
50.5
57.1
50.5
57.1
37.3
43.9
XQAAWT-00-0000-00000L3E2
XQAAWT-00-0000-00000L4E2
XQAAWT-00-0000-00000L5E2
XQAAWT-00-0000-00000B3E2
XQAAWT-00-0000-00000B4E2
XQAAWT-00-0000-00000B5E2
XQAAWT-00-0000-00000L2E4
XQAAWT-00-0000-00000L3e4
XQAAWT-00-0000-00000LZe7
XQAAWT-00-0000-00000L2E7
XQAAWT-00-0000-00000HZE7
XQAAWT-00-0000-00000H2E7
XQAAWT-00-0000-00000UYe7
XQAAWT-00-0000-00000UZe7
CCt range
Color
Minimum
Maximum
Minimum Luminous Flux @ 175 mA
order Code
Group
M3
Flux (lm) @
85 °C
45.7
51.7
56.8
45.7
51.7
56.8
39.8
45.7
35.2
39.8
35.2
39.8
23.5
30.6
Flux (lm) @
25 °C*
52.6
59.5
65.3
52.6
59.5
65.3
45.8
52.6
40.5
45.8
40.5
45.8
26.6
35.2
Cool White
5000 K
8300 K
N2
N3
70-CRI
Minimum
White
M3
3700 K
8300 K
N2
N3
3700 K
5300 K
M2
M3
K3
M2
K3
M2
J2
K2
Neutral
White
Warm White
80-CRI
Minimum
White
90-CRI
Minimum
White
2700 K
3500 K
2700 K
3500 K
2850 K
3000 K
Notes:
•
Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and ±2 on
CRI measurements. See the Measurements section (page 15).
•
Typical CRI for Cool White (5000 K – 8300 K CCT) is 70.
•
Typical CRI for Neutral White (3700 K – 5300 K CCT) is 75.
•
Typical CRI for Warm White (2600 K – 3700 K CCT) is 80.
•
Minimum CRI for 70-CRI Minimum White is 70.
•
Minimum CRI for 80-CRI Minimum White is 80.
•
Minimum CRI for 90-CRI Minimum White is 90.
*
Flux values @ 25 °C are calculated and for reference only.
** Calculated flux values at 350 mA are for reference only.
Copyright © 2016-2018 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are registered trademarks and the Cree logo is a trademark of
Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
3
XLamp
®
XQ-a LED
FLuX ChArACtEristiCs - CoLor (t
J
= 25 °C)
The following table provides several base order codes for XLamp XQ-A color LeDs. It is important to note that the base order codes listed
here are a subset of the total available order codes for the product family. For more order codes, as well as a complete description of the
order-code nomenclature, please consult the XLamp XQ Family LEDs Binning and Labeling document.
Dominant Wavelength range
Color
Minimum
Group
Royal Blue
D36
DWL
(nm)
450
Maximum
Group
D57
DWL
(nm)
465
Minimum Radiant Flux @ 175 mA
Group
11
12
Flux (mW)
210
250
Calculated
Minimum PPF
(µmol/s)*
0.80
0.95
order Code
XQAROY-00-0000-000000601
XQAROY-00-0000-000000701
Dominant Wavelength range
Color
Minimim
Group
Blue
B3
DWL
(nm)
465
Maximum
Group
B6
DWL
(nm)
485
Minimum Luminous Flux @ 175 mA
order Code
Group
F2
G2
Flux (lm)
10.7
13.9
XQABLU-00-0000-000000T01
XQABLU-00-0000-000000U0
Dominant Wavelength range
Color
Minimum
Group
DWL
(nm)
Maximum
Group
DWL
(nm)
Minimum Luminous Flux @ 175 mA
Group
K2
Flux (lm)
30.6
35.2
39.8
45.7
Calculated
Minimum PPF
(µmol/s)*
0.28
0.32
0.36
0.41
order Code
XQAGRN-00-0000-000000Y01
XQAGRN-00-0000-000000Z01
XQAGRN-00-0000-000000201
XQAGRN-00-0000-000000301
Green
G2
520
G4
535
K3
M2
M3
Color
Color bin
Minimum Luminous Flux @ 175 mA
Group
J3
Flux (lm)
26.8
30.6
35.2
order Code
XQAAPA-00-0000-000000X01
XQAAPA-00-0000-000000Y01
XQAAPA-00-0000-000000Z01
PC Amber
Y2
K2
K3
Note
•
Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and a
tolerance of ±2 on CRI measurements. See the Measurements section (page 15).
*
Photosynthetic Photon Flux (PPF) values are calculated and for reference only.
Copyright © 2016-2018 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are registered trademarks and the Cree logo is a trademark of
Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
4
XLamp
®
XQ-a LED
FLuX ChArACtEristiCs - CoLor (t
J
= 25 °C) - Continued
Dominant Wavelength range
Color
Minimum
Group
DWL
(nm)
Maximum
Group
DWL
(nm)
Minimum Luminous Flux @ 175 mA
order Code
Group
K2
Red-Orange
O3
610
O4
620
K3
M2
Flux (lm)
30.6
35.2
39.8
XQARDO-00-0000-000000Y01
XQARDO-00-0000-000000Z01
XQARDO-00-0000-000000201
Dominant Wavelength range
Color
Minimum
Group
DWL
(nm)
Maximum
Group
DWL
(nm)
Minimum Luminous Flux @ 175 mA
Group
J2
Flux (lm)
23.5
26.8
30.6
Calculated
Minimum PPF
(µmol/s)*
0.61
0.70
0.80
order Code
XQAReD-00-0000-000000W01
XQAReD-00-0000-000000X01
XQAReD-00-0000-000000Y01
Red
R2
620
R3
630
J3
K2
Note
•
Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and a
tolerance of ±2 on CRI measurements. See the Measurements section (page 15).
*
Photosynthetic Photon Flux (PPF) values are calculated and for reference only.
Copyright © 2016-2018 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are registered trademarks and the Cree logo is a trademark of
Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
5
