PART NUMBER
521-9630
LED COLOR
RED
YELLOW
GREEN
521 SERIES
2mm Discrete LED
Diffused
521-9631
521-9632
SPECIFICATIONS
Dimensions in inches
ABSOLUTE MAXIMUM RATINGS
(T
A
= 25
O
C)
Power Dissipation (mW)
Average Forward Current (mA)
Derating (mA/
o
C)
Peak Current (mA)
From 25
o
C
RED
-9630
105
30
0.4
160
-40/+85
-40/+85
YELLOW
-9631
105
30
0.4
140
-40/+85
-40/+85
GREEN
-9632
105
25
.33
140
-40/+85
-40/+85
Pulse width = 10us
Operating Temperature (
o
C)
Storage Temperature (
o
C)
Soldering Temperature
260
o
C, 5 seconds, 1.6 mm from case
OPERATING CHARACTERISTICS
(T
A
= 25
O
C)
Luminous Intensity (mcd)
*I
F = 10mA
RED
-9630
YELLOW
-9631
5
8
590
70
o
2.1
2.5
5
GREEN
-9632
5
10
565
70
o
2.2
2.5
5
Min.
Typical
Typical
Typical
Typical
Max.
Min.
8
15
627
70
o
2
2.5
5
Peak Wavelength
Peak
Viewing Angle (2O
1
/
2
)*
Forward Voltage
*I
F = 10mA
Reverse Voltage (V), IR=100uA
* O
1
/
2
is the off axis angle at which the luminous intensity is half the axial luminous intensity
Dialight Corporation
1501 Route 34 South • Farmingdale, NJ 07727 USA
Tel: (1) 732-919-3119 • Fax: (1) 732-751-5778 • www.dialight.com
a Roxboro Group Company
MDEA5212MM001_A
