tains an IRED optically coupled to a phototransistor.
It is packaged in a 4-pin DIP, available in SMT gullw-
ing lead-form option.
Input-output isolation voltage(rms) is 5.0kV.
Collector-emitter voltage is 350V and CTR is MIN.
1 000% at input current of 1mA.
DIP 4pin Darlington Phototransistor Ouput,
High Collector-emitter Voltage
Photocoupler
■
Agency approvals/Compliance
1. Recognized by UL1577, file No. E64380 (as model
No.
PC852/PC853)
2. Approved by VDE, DIN EN60747-5-2
(
*
)
(only for
PC852XJ0000F
series as an option), file No.
40008087 (as model No.
PC852)
3. Package resin : UL flammability grade (94V-0)
(
*
)
DIN EN60747-5-2 : successor standard of DIN VDE0884
■
Features
1. 4pin DIP package
2. Double transfer mold package (Ideal for Flow Solder-
ing)
3. High collector-emitter voltage (V
CEO
: 350V)
4. Durlington phototransistor output (CTR : MIN. 1 000%
at I
F
=1mA, V
CE
=2V)
5. Large collector power disspation :
PC853XJ0000F
(P
C
: 300mW)
6. High isolation voltage between input and output
(V
iso(rms)
: 5kV)
7. Lead-free and RoHS directive compliant
■
Applications
1. Telephone line interface/isolation
2. Interface to power supply circuit
3. Controller for SSRs, DC motors
Notice The content of data sheet is subject to change without prior notice.
In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment using any SHARP
devices shown in catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before using any SHARP device.
