CLM-DS08 Rev 11e
Product family data sheet
Cree
®
LMH2 LED Modules Family
LMH2 Light
source with
Flat Lens
LMH2 Light
source with
Dome Lens
ProDuCt DEsCriPtion
Cree LeD modules provide lighting
designers
simple,
solutions
and
that
manufacturers
LeD
and
LMH2
reduce
time
Cree
with
easy-to-adopt
lighting
luminaire
speed
family
FEaturEs
•
Industry-leading light-source
efficacy (steady state) of up to
97 lm/W for 850‑3000 lm, 108 lm/W
for 4000 lm, 85 lm/W for 6000
& 8000 lm LMH2, 125 lm/W for
1250‑3000 lm LMH2+, all available
in WhiteLight dimming
• 850‑4000 lm available in 2700 K,
3000 K, 3500 K and 4000 K CCT
• 4000 lm & 6000 lm available in
5000 K
• 6000 lm & 8000 lm available in
3000 K, 3500 K and 4000 K CCT
•
Sunset dimming available for
850‑3000 lm modules (dim from
2700 K down to 1800 K)
•
> 90 CRI for all CCTs
• Minimum 95 CRI available for
3500 K at 3000 lm
• Industry‑leading 5‑year warranty
• Designed to last 50,000 hours at L
70
•
No Uv in light output
•
No mercury in light source
tabLE oF ContEnts
LMH2 Characteristics ‑ WhiteLight
Dimming ........................................................2
LMH2 Order Codes - 90 CRI Minimum
WhiteLight Dimming
.....................................3
LMH2 Order Code ‑ 95 CRI Minimum
WhiteLight Dimming
.....................................3
LMH2+ Characteristics ‑ WhiteLight
Dimming ........................................................4
LMH2+ Order Codes ‑ WhiteLight
Dimming ........................................................5
LMH2 Characteristics - Sunset Dimming ....6
LMH2 Order Codes - Sunset Dimming.........6
Thermal Management Guidelines................7
Relative Spectral Power Distribution ...........8
Relative Luminous Flux vs. Case
Temperature ................................................10
Typical voltage vs. Case Temperature ......12
Relative Luminous Flux vs. Current............14
Photometry ..................................................15
Performance Groups - Chromaticity ..........18
Chromaticity Bins Plotted on the 1931
CIe Color Space...........................................19
Mechanical Dimensions ............................20
Notes ...........................................................21
Packaging ....................................................21
development
time-to-market.
LeD modules are the ideal choice for
enabling rapid luminaire development
where bright, beautiful, long-life lighting
is required. The ease of use of the
LMH family enables this versatile LeD
lighting module to jump-start the design
process
for
recessed
downlights,
wall sconces or pendant lights in
demanding end markets such as retail,
museums and studio lighting. The
sunset dimming option allows further
application penetration into hospitality
and restaurant environments.
WWW.CREE.Com/moDULES
E337484
Copyright © 2011-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and the Cree
TrueWhite Technology logo are registered trademarks and the Cree logo is a trademark of Cree, Inc. ENERGY STAR
®
is a registered trademark of the
U.S. Environmental Protection Agency. The UR logo is a registered trademark of UL LLC.
Cree, Inc.
4600 Silicon Drive
Durham, NC 27703
USA Tel: +1.919.313.5300
LMH2 FaMiLy LED MoDuLEs
LMH2 CHaraCtEristiCs - WHitELigHt DiMMing* (tc
= 55 °C)
Characteristics
Viewing angle (FWHM) ‑ 850‑ & 1250‑lm flat lens
Viewing angle (FWHM) ‑ 850‑ & 1250‑lm dome lens
Viewing angle (FWHM) ‑ 2000‑ & 3000‑lm flat lens
Viewing angle (FWHM) ‑ 2000‑ & 3000‑lm dome lens
Viewing angle (FWHM) ‑ 4000‑lm flat lens
Viewing angle (FWHM) ‑ 4000‑lm dome lens
Viewing angle (FWHM) ‑ 6000‑lm flat lens
Viewing angle (FWHM) ‑ 6000‑lm dome lens
Viewing angle (FWHM) ‑ 8000‑lm flat lens
Viewing angle (FWHM) ‑ 8000‑lm dome lens
DC forward current ‑ 850 & 1250 lm
DC forward current ‑ 2000 & 3000 lm
DC forward current ‑ 4000 lm
DC forward current ‑ 6000 lm
DC forward current ‑ 8000 lm
Forward voltage ‑ 850 lm (@ 440 mA, 55 °C)
Forward voltage ‑ 1250 lm (@ 440 mA, 55 °C)
Forward voltage ‑ 2000 lm (@ 900 mA, 55 °C)
Forward voltage ‑ 3000 lm (@ 900 mA, 55 °C)
Forward voltage ‑ 4000 lm (@ 940 mA, 55 °C)
Forward voltage ‑ 6000 lm (@ 1700 mA, 55 °C)
Forward voltage ‑ 8000 lm (@ 2000 mA, 55 °C)
Luminous flux ‑ 850‑lm (@ 440 mA, 55 °C)
Luminous flux ‑ 1250‑lm (@ 440 mA, 55 °C)
Luminous flux ‑ 2000‑lm (@ 900 mA, 55 °C)
Luminous flux ‑ 3000‑lm (@ 900 mA, 55 °C)
Luminous flux ‑ 4000‑lm (@ 940 mA, 55 °C)
Luminous flux ‑ 6000‑lm (@ 1700 mA, 55 °C)
Luminous flux ‑ 8000‑lm (@ 2000 mA, 55 °C)
LED module case temperature (Tc)
CRI - 90 CRI
CRI ‑ 95 CRI
unit
degrees
degrees
degrees
degrees
degrees
degrees
degrees
degrees
degrees
degrees
mA
mA
mA
mA
mA
v
v
v
v
v
v
v
lm
lm
lm
lm
lm
lm
lm
°C
100-point scale
100-point scale
790
1163
1860
2790
3720
5580
7440
0
90
95
92
400
810
850
1530
1800
Minimum
typical
82
96
82
105
85
105
86
110
84
110
440
900
940
1700
2000
19
29
22
33
35.5
38
46.2
850
1250
2000
3000
4000
6000
8000
480
990
1030
1870
2100
23
34
26
38
43
46
52
909
1337
2140
3210
4280
6420
8560
70
Maximum
Notes:
•
•
•
•
*
LMH2 modules are not designed for reverse bias operation.
Cree maintains a tolerance of ±7% on flux measurements, ±10% on power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and a
tolerance of ±2 on CRI measurements.
55 °C measured at case temperature (Tc) point shown on page 20.
Luminous flux values for the dome lens LMH2 LED module can be up to 3% higher.
WhiteLight dimming provides consistent color across the entire dimming range.
Copyright © 2011-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and the Cree TrueWhite Technology logo are registered trademarks and the
Cree logo is a trademark of Cree, Inc. ENERGY STAR
®
is a registered trademark of the U.S. Environmental Protection Agency. The UR logo is a registered trademark of UL LLC.
2
LMH2 FaMiLy LED MoDuLEs
LMH2 orDEr CoDEs - 90 Cri MiniMuM WHitELigHt DiMMing
typical Luminous Flux
(lm)
typical Light
source Efficacy
(lm/W)
CCt
(K)
4000
850
97
3500
3000
2700
4000
1250
97
3500
3000
2700
4000
2000
97
3500
3000
2700
4000
3000
97
3500
3000
2700
5000
4000
4000
108
3500
3000
2700
5000
6000
85
4000
3500
3000
4000
8000
85
3500
3000
order Code
Flat Lens
LMH020‑0850‑40G9‑00000TW
LMH020‑0850‑35G9‑00000TW
LMH020‑0850‑30G9‑00000TW
LMH020‑0850‑27G9‑00000TW
LMH020‑1250‑40G9‑00000TW
LMH020‑1250‑35G9‑00000TW
LMH020‑1250‑30G9‑00000TW
LMH020‑1250‑27G9‑00000TW
LMH020‑2000‑40G9‑00000TW
LMH020‑2000‑35G9‑00000TW
LMH020‑2000‑30G9‑00000TW
LMH020‑2000‑27G9‑00000TW
LMH020‑3000‑40G9‑00000TW
LMH020‑3000‑35G9‑00000TW
LMH020‑3000‑30G9‑00000TW
LMH020‑3000‑27G9‑00000TW
LMH020‑4000‑50G9‑00000TW
LMH020‑4000‑40G9‑00000TW
LMH020‑4000‑35G9‑00000TW
LMH020‑4000‑30G9‑00000TW
LMH020‑4000‑27G9‑00000TW
LMH020‑6000‑50G9‑00000TW
LMH020‑6000‑40G9‑00000TW
LMH020‑6000‑35G9‑00000TW
LMH020‑6000‑30G9‑00000TW
LMH020‑8000‑40G9‑00000TW
LMH020‑8000‑35G9‑00000TW
LMH020‑8000‑30G9‑00000TW
Dome Lens
LMH020‑0850‑40G9‑00001TW
LMH020‑0850‑35G9‑00001TW
LMH020‑0850‑30G9‑00001TW
LMH020‑0850‑27G9‑00001TW
LMH020‑1250‑40G9‑00001TW
LMH020‑1250‑35G9‑00001TW
LMH020‑1250‑30G9‑00001TW
LMH020‑1250‑27G9‑00001TW
LMH020‑2000‑40G9‑00001TW
LMH020‑2000‑35G9‑00001TW
LMH020‑2000‑30G9‑00001TW
LMH020‑2000‑27G9‑00001TW
LMH020‑3000‑40G9‑00001TW
LMH020‑3000‑35G9‑00001TW
LMH020‑3000‑30G9‑00001TW
LMH020‑3000‑27G9‑00001TW
LMH020‑4000‑50G9‑00001TW
LMH020‑4000‑40G9‑00001TW
LMH020‑4000‑35G9‑00001TW
LMH020‑4000‑30G9‑00001TW
LMH020‑4000‑27G9‑00001TW
LMH020‑6000‑50G9‑00001TW
LMH020‑6000‑40G9‑00001TW
LMH020‑6000‑35G9‑00001TW
LMH020‑6000‑30G9‑00001TW
LMH020‑8000‑40G9‑00001TW
LMH020‑8000‑35G9‑00001TW
LMH020‑8000‑30G9‑00001TW
LMH2 orDEr CoDE - 95 Cri MiniMuM WHitELigHt DiMMing
typical Luminous Flux
(lm)
3000
typical Light
source Efficacy
(lm/W)
97
CCt
(K)
3500
order Code
Flat Lens
LMH020‑3000‑35GS‑00000TW
Copyright © 2011-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and the Cree TrueWhite Technology logo are registered trademarks and the
Cree logo is a trademark of Cree, Inc. ENERGY STAR
®
is a registered trademark of the U.S. Environmental Protection Agency. The UR logo is a registered trademark of UL LLC.
3
LMH2 FaMiLy LED MoDuLEs
LMH2+ CHaraCtEristiCs - WHitELigHt DiMMing* (tc
= 55 °C)
Characteristics
Viewing angle (FWHM) ‑ 1250‑lm flat lens
Viewing angle (FWHM) ‑ 1250‑lm dome lens
Viewing angle (FWHM) ‑ 2000‑lm flat lens
Viewing angle (FWHM) ‑ 2000‑lm dome lens
Viewing angle (FWHM) ‑ 3000‑lm flat lens
Viewing angle (FWHM) ‑ 3000‑lm dome lens
DC forward current ‑ 1250 lm
DC forward current ‑ 2000 lm
DC forward current ‑ 3000 lm
Forward voltage ‑ 1250 lm (@ 450 mA, 55 °C)
Forward voltage ‑ 2000 lm (@ 450 mA, 55 °C)
Forward voltage ‑ 3000 lm (@ 600 mA, 55 °C)
Luminous flux ‑ 1250‑lm (@ 450 mA, 55 °C)
Luminous flux ‑ 2000‑lm (@ 450 mA, 55 °C)
Luminous flux ‑ 3000‑lm (@ 600 mA, 55 °C)
LED module case temperature (Tc)
CRI
unit
degrees
degrees
degrees
degrees
degrees
degrees
mA
mA
mA
v
v
v
lm
lm
lm
°C
100-point scale
1163
1860
2790
0
90
92
Minimum
typical
82
96
82
105
82
105
450
450
600
22.5
35
40
1250
2000
3000
750
940
1000
25
38.5
44
1337.5
2140
3210
70
Maximum
Notes:
•
•
•
•
*
LMH2+ modules are not designed for reverse bias operation.
Cree maintains a tolerance of ±7% on flux measurements, ±10% on power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and a
tolerance of ±2 on CRI measurements.
55 °C measured at case temperature (Tc) point shown on page 20.
Luminous flux values for the dome lens LMH2+ LED module can be up to 3% higher.
WhiteLight dimming provides consistent color across the entire dimming range.
Copyright © 2011-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and the Cree TrueWhite Technology logo are registered trademarks and the
Cree logo is a trademark of Cree, Inc. ENERGY STAR
®
is a registered trademark of the U.S. Environmental Protection Agency. The UR logo is a registered trademark of UL LLC.
4
LMH2 FaMiLy LED MoDuLEs
LMH2+ orDEr CoDEs - WHitELigHt DiMMing
typical Luminous Flux
(lm)
typical Light
source Efficacy
(lm/W)
CCt
(K)
4000
1250
125
3500
3000
2700
4000
2000
125
3500
3000
2700
4000
3000
125
3500
3000
2700
order Code
Flat Lens
LMH02B‑1250‑40G9‑00000TW
LMH02B‑1250‑35G9‑00000TW
LMH02B‑1250‑30G9‑00000TW
LMH02B‑1250‑27G9‑00000TW
LMH02B‑2000‑40G9‑00000TW
LMH02B‑2000‑35G9‑00000TW
LMH02B‑2000‑30G9‑00000TW
LMH02B‑2000‑27G9‑00000TW
LMH02B‑3000‑40G9‑00000TW
LMH02B‑3000‑35G9‑00000TW
LMH02B‑3000‑30G9‑00000TW
LMH02B‑3000‑27G9‑00000TW
Dome Lens
LMH02B‑1250‑40G9‑00001TW
LMH02B‑1250‑35G9‑00001TW
LMH02B‑1250‑30G9‑00001TW
LMH02B‑1250‑27G9‑00001TW
LMH02B‑2000‑40G9‑00001TW
LMH02B‑2000‑35G9‑00001TW
LMH02B‑2000‑30G9‑00001TW
LMH02B‑2000‑27G9‑00001TW
LMH02B‑3000‑40G9‑00001TW
LMH02B‑3000‑35G9‑00001TW
LMH02B‑3000‑30G9‑00001TW
LMH02B‑3000‑27G9‑00001TW
Copyright © 2011-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and the Cree TrueWhite Technology logo are registered trademarks and the
Cree logo is a trademark of Cree, Inc. ENERGY STAR
®
is a registered trademark of the U.S. Environmental Protection Agency. The UR logo is a registered trademark of UL LLC.
5
NXP MCU
京公网安备 11010802033920号
EEWORLD
