LUXEON CoB
High uniformity and high efficiency array
Introduction
Philips Lumileds’ high uniformity array solution is a new breakthrough in efficacy for arrays.
Due to its industry leading small Light Emitting Surfaces (LES), the CoB array is very easy to
work with and will enable easier and less expensive designs.
All LUXEON CoBs are available in a single 3-step as well as a single 5-step MacAdam
Ellipse, ensuring uniform optical performance in the application. Next to that, LUXEON
CoB’s are all hot-tested at 85°C—real world operating conditions— which means that
luminaire design is simplified and testing can be minimized.
This document contains the performance data needed to design and engineer LUXEON
CoB based applications.
Features
Efficacy: >100 lm/W hot at Tj = 85°C , 36V
Lumen packages from 1000-6000lm
Industry smallest LES (Light Emitting Surface)
Best luminous and color uniformity
Binned within 3-step or 5-step MacAdam Ellipse
Tested at Tj = 85°C
Robust MCPCB solution
Mouse-bites available for M2-M3 screws
Supported by a comprehensive optical,
mechanical, and electrical Eco-System.
Benefits
Breakthrough in LED efficacy
Enabling halogen and CDM replacement
Enables smaller and cheaper reflectors
More uniform and crisp light beams
Enabling luminaire to luminaire consistency
Real world application testing
Easy to handle in manufacturing and operations
Easy to screw down the arrays
Drivers, holders and optics readily available
DS120 v0.1
March 2013
Table of Contents
Introduction ............................................................................................................................................................. 1
Product Nomenclature ............................................................................................................................................ 3
Average Lumen Maintenance Characteristics ........................................................................................................ 3
Environmental Compliance ..................................................................................................................................... 3
Product Performance and Characterization Guide ................................................................................................. 4
Absolute Maximum Ratings .................................................................................................................................... 5
Mechanical Dimensions .......................................................................................................................................... 6
LUXEON CoB: LHC1 – xxxx – 1203
LUXEON CoB: LHC1 – xxxx – 1205
LUXEON CoB: LHC1 – xxxx – 1204 ................................................... 6
LUXEON CoB: LHC1 – xxxx – 1208 ................................................... 6
Characteristic Curves ............................................................................................................................................. 7
Relative Spectral Distribution vs. Wavelength .................................................................................................. 7
Relative Light Output Characteristics over Temperature .................................................................................. 7
Typical Forward Current Characteristics........................................................................................................... 8
Typical Relative Luminous Flux vs. Forward Current ....................................................................................... 9
Typical Radiation ............................................................................................................................................ 10
Flux Binning .......................................................................................................................................................... 12
Package Info and Dimensions .............................................................................................................................. 13
LUXEON CoB LHC1 – xxxx - 1203................................................................................................................. 13
LUXEON CoB LHC1 – xxxx – 1204, -1205 and -1208 ................................................................................... 13
2
Philips Lumileds Preliminary Datasheet LUXEON CoB V0.1 (2013-03-19)
Product Nomenclature
LUXEON CoB is tested and binned hot at Tj = 85ºC with a current pulse duration of 20ms.
The part number designation is explained as follow:
LHCA–BBCC–DDEE
Where:
A
– designates the generation of the product family
BB
— designates ANSI color point (e.g. 30 for 3000K)
C C
— designates minimum CRI level (e.g. 80 for minimum 80 CRI)
D D E E
— designates color product configuration (e.g. 1203 for the 1000-2000lm package)
Therefore 3000K, 80 CRI LUXEON CoB product will be:
LXCB–3080–1203
Average Lumen Maintenance Characteristics
Lumen maintenance for solid-state lighting devices (LEDs) is typically defined in terms of the percentage of
initial light output remaining after a specified period of time. Operating
conditions will be further validated and
disclosed at the time of product launch.
Observation of design limits included in this data sheet is required in
order to achieve this projected lumen maintenance.
Environmental Compliance
Philips Lumileds is committed to providing environmentally friendly products to the solid-state lighting market.
LUXEON CoB is compliant to the European Union directives on the restriction of hazardous substances in
electronic equipment, namely the RoHS and REACH directives. Philips Lumileds will not intentionally add the
following restricted material to the LUXEON CoB: lead, mercury, cadmium, hexavalent chromium,
polybrominated biphenyls (PBB) or polybrominated diphenyl ethers (PBDE).
3
Philips Lumileds Preliminary Datasheet LUXEON CoB V0.1 (2013-03-19)
Product Performance and Characterization Guide
Junction Temperature = 85ºC
Table 1. Performance and Electrical Characteristics
Nominal
CCT
3000K
3000K
3000K
3000K
Part
Number
LHC1-3080-1203
LHC1-3080-1204
LHC1-3080-1205
LHC1-3080-1208
Test Current If
(mA)
300
450
600
900
Luminous Flux
Typical (lm)
1150
1725
2300
3450
[1]
CRI
[1]
Efficacy
Typical (lm/W)
105
105
105
105
LES
[2]
Minimum
>80
>80
>80
>80
(mm)
9
13
13
15
Notes for Table 1:
1.
Philips Lumileds maintains a tolerance of ±6.5% on luminous flux, ±2 on CRI, ±2 on R9 measurements
2.
Light Emitting Surface (LES) is the inner diameter (phosphor area) inside the dam
Table 2. Optical Characteristics
Nominal
CCT
LHC1 - xxxx - xxxx
Typical Total Included Angle (degrees)
θ
0.90V
125
[1]
Typical Viewing Angle (degrees)
2θ ½
100
[2]
Notes for Table 2:
1.
Total angle at which 90% of total luminous flux is captured
2.
Viewing angle is the off axis angle from lamp centerline where the luminous intensity is ½ of the peak value
Table 3. Electrical Characteristics at Test Current
Nominal
CCT
Part
Number
Forward Voltage V,
85˚C (V)
Min.
3000K
3000K
3000K
3000K
LHC1-3080-1203
LHC1-3080-1204
LHC1-3080-1205
LHC1-3080-1208
Typ.
36.0
36.0
36.0
36.0
Max.
Typical Temperature Coefficient of
[1]
Forward Voltage (mV/˚C)
V
f
/T
J
-16
-16
-16
-16
Typical Thermal Resistance
Junction to case (˚C/W)
Rθ
J-C
0.9
0.7
0.5
0.3
Notes for Table 3:
1.
Measured between Tj = 25˚C and Tj = 105˚C at test current
4
Philips Lumileds Preliminary Datasheet LUXEON CoB V0.1 (2013-03-19)
Absolute Maximum Ratings
Table 4. Operating Condition and Ratings
Parameter
DC Forward Current
ESD Sensitivity
Storage Temperature
LED Junction Temperature
[1]
Maximum Performance
TBD - 2x test current
[2]
< 8000V Human Body Model (HBM) Class 3A JESD22-A114-E
< 400V Machine Model (MM) Class B JESD22-A115-B
-40˚C - 120˚C
125˚C
-40˚C - 105˚C
LUXEON CoB is not designed to be driven in reverse bias
Operating Case Temperature at nominal current
Reverse Voltage
Notes for Table 4:
1.
Proper current derating must be observed to maintain junction temperature below the maximum, please see preliminary application brief
for additional information on thermal measurement guidelines
2.
Residual periodic variations due to power conversion from alternating current (AC) to direct current (DC), also called “ripple’, with
frequencies
≥
100 Hz and amplitude ±20% are acceptable, assuming the average current throughout each cycle does not exceed 2x test If
5
Philips Lumileds Preliminary Datasheet LUXEON CoB V0.1 (2013-03-19)
