This document was generated on 01/19/2018
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0761555805
Active
Impact Backplane Connector and Cable Assembly System
Impact 100 Ohm 4 Pair Vertical Backplane Header, Right Guided, Open Endwall, 8
Columns, 96 Circuits, Pin Length 5.50mm, Plated Through Hole Dimension 0.46mm,
Lead-Free
Documents:
3D Model
Drawing (PDF)
Product Specification PS-76060-999-001 (PDF)
Product Specification TS-76160-0001-001 (PDF)
Application Specification AS-76060-990-001 (PDF)
Agency Certification
UL
General
Product Family
Series
Application
Application Tooling Documents
Component Type
Overview
Product Name
UPC
Physical
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Flammability
Guide to Mating Part
Keying to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Columns
Number of Pairs
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Polarized to PCB
Stackable
Temperature Range - Operating
Application Specification AS-76060-994-001 (PDF)
Application Specification AS-76060-9999-001 (PDF)
Packaging Specification PK-70873-757 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
EU ELV
Not Reviewed
E29179
Backplane Connectors
76155
Conventional
TM-622018799
PCB Header
Impact Backplane Connector and Cable Assembly
System
Impact
883906417499
96
96
Black
200
No
94V-0
Yes
None
High Performance Alloy (HPA)
Gold
Tin
High Temperature Thermoplastic
5.363/g
8
4
12
Vertical
1.40mm
No
Yes
1.00mm
Tray
1.90mm
1.90mm
0.762µm
Yes
No
-55°C to +85°C
EU RoHS
China RoHS
Not Reviewed
REACH SVHC
Not Reviewed
Halogen-Free
Status
Not Reviewed
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Not Reviewed
Not Reviewed
Not Reviewed
Search Parts in this Series
76155 Series
Mates With
76160 Impact 100 Ohm Daughtercard
Termination Interface: Style
Electrical
Current - Maximum per Contact
Data Rate
Impedance
Shield Type
Shielded
Voltage - Maximum
Material Info
Reference - Drawing Numbers
Application Specification
Packaging Specification
Product Specification
Sales Drawing
Symbol/Footprint Data
Through Hole - Compliant Pin
0.75A
25.0 Gbps
100Ω
N/A
No
30V AC (RMS)/DC
AS-76060-990-001, AS-76060-994-001,
AS-76060-9999-001
PK-70873-757
PS-76060-999-001, TS-76160-0001-001
SD-76155-003-001
SYM-76155-5805
