DATA SHEET
MOS INTEGRATED CIRCUIT
μ
PD8882
(10680 + 10680) PIXELS
×
3 COLOR CCD LINEAR IMAGE SENSOR
DESCRIPTION
The
μ
PD8882 is a color CCD (Charge Coupled Device) linear image sensor which changes optical images to
electrical signal and has the function of color separation.
The
μ
PD8882 has 3 rows of (10680 + 10680) staggered pixels, and each row has a dual-sided readout-type charge
transfer register. And it has reset feed-through level clamp circuits and voltage amplifiers. Therefore, it is suitable for
2400 dpi/A4 color image scanners.
FEATURES
•
Valid photocell
•
Photocell’s size
•
Line spacing
•
Color filter
•
Resolution
: (10680 + 10680) staggered pixels
×
3
: 2.7
μ
m
×
5.4
μ
m
: 86.4
μ
m (16 lines) Red line - Green line, Green line - Blue line
43.2
μ
m (8 lines) Odd line - Even line (for each color)
: Primary colors (red, green and blue), pigment filter (with light resistance 10 lx•hour)
: 96 dot/mm A4 (210
×
297 mm) size (shorter side)
2400 dpi US letter (8.5”
×
11”) size (shorter side)
•
Drive clock level : CMOS output under 5 V operation
•
Data rate
•
Power supply
•
On-chip circuits
: Built-in amplifiers : 10.0 MHz Max. CCD transfer : 4.5 MHz Max./each CCD
: +12 V
: Reset feed-through level clamp circuits
Voltage amplifiers
7
ORDERING INFORMATION
Part Number
Package
CCD linear image sensor 22-pin plastic DIP (10.16 mm (400))
μ
PD8882CY-A
Remark
The
μ
PD8882CY-A
is a lead-free product.
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all products and/or types are available in every country. Please check with an NEC Electronics
sales representative for availability and additional information.
Document No. S17085EJ2V0DS00 (2nd edition)
Date Published May 2005 NS CP (K)
Printed in Japan
The mark
shows major revised points.
2004
μ
PD8882
BLOCK DIAGRAM
V
OD
GND GND
φ
RB
20
V
OD
7
2
11
3
CCD analog shift register
Transfer gate
Photocell (Blue-odd)
Transfer gate
CCD analog shift register
φ
2
φ
1
14
15
13
φ
TG1
V
OUT
1 21
CCD analog shift register
Transfer gate
Photocell (Blue-even)
Transfer gate
CCD analog shift register
CCD analog shift register
Transfer gate
Photocell (Green-odd)
Transfer gate
CCD analog shift register
12
φ
TG2
V
OUT
2 22
CCD analog shift register
Transfer gate
Photocell (Green-even)
Transfer gate
CCD analog shift register
CCD analog shift register
Transfer gate
Photocell (Red-odd)
Transfer gate
CCD analog shift register
10
φ
TG3
V
OUT
3
1
CCD analog shift register
Transfer gate
Photocell (Red-even)
Transfer gate
CCD analog shift register
4
19
9
8
φ
CLB
φ
SEL
φ
4
φ
3
2
Data Sheet S17085EJ2V0DS
μ
PD8882
PIN CONFIGURATION (Top View)
CCD linear image sensor 22-pin plastic DIP (10.16 mm (400))
•
μ
PD8882CY-A
Output signal 3 (Red)
Ground
Reset gate clock
Reset feed-through level clamp clock
No connection
No connection
Output drain voltage
Shift register clock 3
Shift register clock 4
Transfer gate clock 3
(for Red)
Ground
V
OUT
3
GND
1
2
22
21
V
OUT
2
V
OUT
1
V
OD
Output signal 2 (Green)
Output signal 1 (Blue)
Output drain voltage
Dpi selector
No connection
No connection
No connection
Shift register clock 1
Shift register clock 2
Transfer gate clock 1
(for Blue)
Transfer gate clock 2
(for Green)
1
1
φ
RB
φ
CLB
NC
NC
V
OD
3
4
5
6
7
8
9
10
11
1
20
19
18
17
16
15
14
13
12
φ
SEL
NC
NC
NC
Green
φ
3
φ
4
Blue
Red
φ
1
φ
2
φ
TG1
φ
TG2
21360
21360
GND
Caution Connect the No connection pins (NC) to GND.
21360
φ
TG3
Data Sheet S17085EJ2V0DS
3
μ
PD8882
PHOTOCELL STRUCTURE DIAGRAM
2.0
μ
m
0.7
μ
m
5.4
μ
m
Channel stopper
Aluminum
shield
PHOTOCELL ARRAY STRUCTURE DIAGRAM-1 (Line spacing)
5.4
μ
m
Blue odd photocell array
8 lines
(43.2
μ
m)
16 lines
(86.4
μ
m)
5.4
μ
m
Blue even photocell array
8 lines
(43.2
μ
m)
5.4
μ
m
Green odd photocell array
8 lines
(43.2
μ
m)
16 lines
(86.4
μ
m)
5.4
μ
m
Green even photocell array
8 lines
(43.2
μ
m)
5.4
μ
m
Red odd photocell array
8 lines
(43.2
μ
m)
5.4
μ
m
Red even photocell array
4
Data Sheet S17085EJ2V0DS
μ
PD8882
PHOTOCELL ARRAY STRUCTURE DIAGRAM-2 (Odd-even pixel)
1
3
5
7
5.4
μ
m
43.2
μ
m
(8 lines)
1.35
μ
m
37.8
μ
m
2
4
6
8
5.4
μ
m
2.0
μ
m
0.7
μ
m
PHOTOCELL ARRAY STRUCTURE DIAGRAM-3 (Dummy, OB, for each color)
Dummy
(56 pixels)
1
55
57
Optical black
(96 pixels)
Invalid photocell
(8 pixels)
151 153 155 157 159 161 163
Valid photocell
(21360 pixels)
21517 21519
Invalid photocell
(4 pixels)
2
56
58
152 154 156 158 160 162 164
21518 21520
Data Sheet S17085EJ2V0DS
5
